HG-0040 Using the Panasonic Digital Camera Page 1 of 2

Background

A digital camera can add critical information to a telemedicine case. The Panasonic DMC-ZS8 Digital Camera is simple

to use and captures high quality images. Tips for deleting clinical images can be found on the back of this Handy Guide.

AFHCAN

www.afhcan.org

Handy

Guide Using the Panasonic Digital

Camera

2. Slide the REC/PLAY switch down (C) to

check for images on the camera. Delete any

existing images (see Deleting Images on the

back of this Handy Guide).

1. Turn the camera on by sliding the On/Off switch to

the right (A) and select the AUTO camera mode

(

)

3. Slide the REC/PLAY switch up to place the camera

in picture taking mode.

4. Take a picture by depressing the shutter button (D)

halfway down to set the autofocus (E). Depress the

shutter button all the way down to take the picture.

Taking Still Images

Reminder: Take several pictures of the

subject. Include close up view for detail and

far away view for perspective.

1. The Panasonic Camera should automatically switch to macro mode when

focused on an object closer than 22 inches.

a. If the macro function doesn’t preset automatically simply

depress the macro symbol on the selection wheel (F).

You should now see the macro icon in the viewfinder.

Using the Macro Function

The Panasonic Camera automatically adjusts the flash. If you feel the flash is causing your subject to become washed

out, you can manually turn the flash off:

The flash is now off and will remain off until you select a new flash setting.

Using the Flash Function

1. Depress the flash on the icon selection wheel (G)

2. Use the selection wheel to highlight no flash on the

screen/viewfinder

ess

NU/S

but

F G

HG-0040 Using the Panasonic Digital Camera Page 2 of 2

Adding Images to a Telemedicine Case

If you are using tConsult Cart

1. With the camera on attach the USB cable

2. Select the “Digital Camera” button from the “Add to Case”

screen.

3. You will see images being loaded to your case viewer.

4. Select, label and save desired images to your case.

5. Delete images from the camera when done.

If you are using tConsult Web

1. Connect the USB cable to your computer and the camera

2. With the camera power on select PC with the cursor Menu/SET

button

3. Select “Add an Image” from the “Add to Case” column

4. Browse to the Panasonic Camera folder on your computer

5. Select the image (s) you want to add to the case

Use selection

wheel button to

highlight

desired delete

option

1 2

View the

Delete

Screen

4 Depress the

MENU/SET

button to

delete

images

Press the

"Q.Menu"

button

Turn the

camera on

Select the

Review

Mode

Deleting Images

V 3 Cart V 4 Cart

3 4
