Panasonic ES-LV5E Manuale utente

Operating Instructions

(Household) AC/Rechargeable Shaver

Model No. ES‑LV5E

English�� 3

中文 �� 21

한글 �� 35

English

Operating Instructions

(Household use) AC/Rechargeable Shaver

Model No. ES‑LV5E

Thank you for purchasing this Panasonic product.

Before operating this unit, please read these instructions completely and save them for future use�

Safety precautions..................... 4

Important information ��9

Parts identication ��10

Preparation��10

How to use �� 11

Cleaning the shaver ��14

Replacing the system outer foil and

the inner blades��16

FAQ ��16

Troubleshooting ��17

Battery life��19

Removing the built-in rechargeable

battery��19

Specications ��20

Contents

English

Safety precautions

To reduce the risk of injury, loss of life, electric shock,

re, and damage to property, always observe the

following safety precautions.

Explanation of symbols

The following symbols are used to classify and

describe the level of hazard, injury, and property

damage caused when the denotation is disregarded

and improper use is performed.

DANGER

Denotes a potential

hazard that will result

in serious injury or

death.

WARNING

Denotes a potential

hazard that could

result in serious

injury or death.

CAUTION

Denotes a hazard

that could result in

minor injury or

property damage.

The following symbols are used to classify and

describe the type of instructions to be observed.

This symbol is used to alert users to a specic

operating procedure that must not be performed.

This symbol is used to alert users to a specic

operating procedure that must be followed in

order to operate the unit safely.

WARNING

►This product

Do not use the appliance for wet shaving�

‑ Doing so may cause electric shock or re due

to a short circuit.

This product has a built-in rechargeable battery�

Do not throw into re, apply heat, or charge,

use, or leave in a high temperature

environment�

‑ Doing so may cause overheating, ignition, or

explosion.

Do not modify or repair�

‑ Doing so may cause re, electric shock, or

injury.

Contact an authorized service center for repair

(battery change etc).

Never disassemble except when disposing of

the product�

‑

Doing so may cause re, electric shock, or

injury.

English

WARNING

►In case of an abnormality or malfunction

Immediately stop using and remove the

adaptor if there is an abnormality or

malfunction�

‑ Failure to do so may cause re, electric shock,

or injury.

• The main unit, adaptor or cord is deformed

or abnormally hot�

•

The main unit, adaptor or cord smells of

burning�

• There is an abnormal sound during use or

charging of the main unit, adaptor or cord�

‑ Immediately request inspection or repair at an

authorized service center.

►Power supply

Do not connect or disconnect the adaptor to

a household outlet with a wet hand�

‑ Doing so may cause electric shock or injury.

Do not immerse the AC adaptor in water or

wash with water�

Do not place the AC adaptor over or near

water lled sink or bathtub.

Never use the appliance if the AC adaptor is

damaged or if the power plug ts loosely in a

household outlet�

Do not damage the cord or the power plug�

•

Do not deface, modify, forcefully bend or pull

the cord or the power plug� Also, do not

place anything heavy on, twist or pinch the

cord�

‑ Doing so may cause electric shock or re due

to a short circuit.

Do not use in a way exceeding the rating of

the household outlet or the wiring�

‑ Exceeding the rating by connecting too many

plugs to one household outlet may cause re

due to overheating.

Do not use anything other than the supplied

AC adaptor for any purpose� Also, do not use

any other product with the supplied AC

adaptor� (See page 10�)

‑

Doing so may cause burn or re due to a short

circuit.

English

WARNING

Always ensure the appliance is operated on

an electric power source matched to the

rated voltage indicated on the AC adaptor�

Fully insert the adaptor�

‑ Failure to do so may cause re or electric

shock.

Disconnect the AC adaptor when cleaning the

main body with water�

‑

Failure to do so may cause electric shock or

injury.

Regularly clean the power plug and the

appliance plug to prevent dust from

accumulating�

‑ Failure to do so may cause re due to insulation

failure caused by humidity.

►Preventing accidents

Do not place within reach of children or

infants� Do not let them use it�

‑ Putting parts or accessories in the mouth may

cause an accident or injury.

If oil is consumed accidentally, do not induce

vomiting, drink a large amount of water and

contact a physician�

If oil comes into contact with eyes, wash

immediately and thoroughly with running

water and contact a physician�

‑ Failure to follow these instructions may result in

physical problems.

►Note the following precautions

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been given supervision or

instruction concerning use of the appliance

by a person responsible for their safety�

Children should be supervised to ensure that

they do not play with the appliance�

‑ Failure to do so may cause an accident or

injury.

The supply cord cannot be replaced� If the cord

is damaged, the AC adaptor should be

scrapped�

‑ Failure to do so may cause an accident or

injury.

English

CAUTION

►Protecting the skin

Do not use excessive pressure to apply the

system outer foil to your lip or other part of

your face�

Do not apply the system outer foil directly to

blemishes or injured skin.

Do not touch the blade section (metallic

section) of the inner blade�

‑ Doing so may cause injury to skin or hand.

Do not forcefully press the system outer foil�

Also, do not touch the system outer foil with

ngers or nails when in use.

Do not use this product for hair on head or

any other part of the body�

‑ Doing so may cause injury to skin or reduce the

life of the system outer foil.

Check the system outer foil for cracks or

deformations before use�

‑ Failure to do so may cause injury to the skin.

Be sure to place the protective cap on the

shaver when carrying around or storing�

‑ Failure to do so may cause injury to skin or

reduce the life of the system outer foil.

►Note the following precautions

Do not wrap the cord around the adaptor

when storing�

‑ Doing so may cause the wire in the cord to

break with the load, and may cause re due to

a short circuit.

Do not allow metal objects or trash to adhere

to the power plug or the appliance plug�

‑ Doing so may cause electric shock or re due

to a short circuit.

Do not disconnect the adaptor or the

appliance plug by holding onto the cord�

‑ Doing so may cause electric shock or injury.

Do not share your shaver with your family or

other people�

‑ Doing so may result in infection or inammation.

Do not drop or hit against other objects�

‑ Doing so may cause injury.

Disconnect the adaptor from the household

outlet when not using�

‑ Failure to do so may cause electric shock or re

due to electrical leakage resulting from

insulation deterioration.

English

Handling of the removed battery when disposing

DANGER

• The rechargeable battery is exclusively for

use with this appliance� Do not use the

battery with other products�

• Do not charge the battery after it has been

removed from the product�

• Do not throw into re or apply heat.

• Do not hit, disassemble, modify, or puncture

with a nail�

• Do not let the positive and negative

terminals of the battery get in contact with

each other through metallic objects�

• Do not carry or store the battery together

with metallic jewellery such as necklaces

and hairpins�

• Do not use or leave the battery where it will

be exposed to high temperatures, such as

under direct sunlight or near other sources

of heat�

• Never peel off the tube�

‑ Doing so may cause overheating, ignition, or

explosion.

WARNING

After removing the rechargeable battery, do

not keep it within reach of children and

infants�

‑ The battery will harm the body if accidentally

swallowed.

If this happens, consult a physician

immediately.

If the battery uid leaks out and comes in

contact with the eyes, do not rub the eyes,

and thoroughly rinse with clean water, such

as tap water�

‑ Failure to do so may cause eye injury.

Consult a physician immediately.

CAUTION

If the battery uid leaks out and comes in

contact with the skin or clothes, rinse off with

clean water, such as tap water�

‑ Failure to do so may cause inammation.

English

Important information

• Do not bring the system outer foil into contact with

hard objects.

Doing so may damage the blades as they are very

thin and deform easily.

• Do not dry the main unit with a dryer or a fan heater.

Doing so may cause malfunction or deformation of the

parts.

• Do not leave the shaver exposed to direct sunlight

with the foil frame detached.

Doing so may deteriorate the waterproof rubber and

degrade waterproof function, which may cause to

malfunction.

• Store the shaver in a place with low humidity after

use.

Failure to do so may cause malfunction due to

condensation or rust.

• Keep both the inner blades inserted. If only one of the

inner blades is inserted, the shaver may be damaged.

• If you clean the shaver with water, do not use salt

water or hot water. Do not soak the shaver in water for

a long period of time.

• The following symbol indicates that a specic

detachable power supply unit is required for

connecting the electrical appliance to the supply

mains. The type reference of power supply unit is

marked near the symbol.

English

Parts identication





























Back













AMain body

1Protective cap

2 System outer foil

3 Foil frame

4 Smooth rollers

• They help to glide

over the skin more

easily.

5 Foil frame release

buttons

6 Power switch

7 Lamp display

a. Shaving sensor

lamp ( )

b. Battery capacity

lamp

c. Switch lock lamp

()

d. Charge status

lamp ( )

8Appliance socket

9Outer foil section

: System outer foil

release buttons

;Inner blades

< Trimmer

= Trimmer handle

BAC adaptor (RE7-87)

>Adaptor

? Power plug

@Cord

AAppliance plug

Accessories

CTravel case

DCleaning brush

EOil

Preparation

Charging the shaver

• Turn the shaver off.

• Wipe off any water droplets on the appliance socket.

1 Insert the appliance plug

into the shaver�

2 Plug the adaptor into a

household outlet�

• Check that the charge status

lamp ( ) is glowing.

• Charging is completed after

approx. 1 hour.

3 Disconnect the adaptor after charging is

completed�

Indice

Lingue:

Altri manuali Panasonic Rasoio elettrico

Panasonic

Panasonic ER-GB86 Manuale utente

Panasonic

Panasonic ER421KC Manuale utente

Panasonic

Panasonic ES-RW31 Manuale utente

Panasonic

Panasonic ER-GN30 Manuale utente

Panasonic

Panasonic ES-LV61-A Manuale utente

Panasonic

Panasonic ES-LF70 Manuale utente

Panasonic

Panasonic ER-407 Manuale utente

Panasonic

Panasonic ER-430 Manuale utente

Panasonic

Panasonic ER-121 Manuale utente

Panasonic

Panasonic ES-LV81 Manuale utente

Panasonic

Panasonic ES-8101 Manuale utente

Panasonic

Panasonic ES-LV5A Manuale utente

Panasonic

Panasonic ES2218 Manuale utente

Panasonic

Panasonic ER409SC Manuale utente

Panasonic

Panasonic ES-LV9A Manuale utente

Panasonic

Panasonic ES-8109 Manuale utente

Panasonic

Panasonic ER-GK81 Manuale utente

Panasonic

Panasonic ER2201 Manuale utente

Panasonic

Panasonic ES-LT31 Manuale utente

Panasonic

Panasonic ES8003W Manuale utente

Panasonic

Panasonic ES8017SC Manuale utente

Panasonic

Panasonic ES-7015 Manuale utente

Panasonic

Panasonic ES-LS9AX Manuale utente

Panasonic

Panasonic ES-881 Manuale utente

Manuali Rasoio elettrico popolari di altre marche

Philips

Philips MicroAction 4402LC Manuale utente

Philips

Philips HQ7740 Manuale utente

Philips

Philips Norelco BG2022 Bodygroom Manuale utente

Norelco

Norelco Quadra 7610X Manuale utente

Philips

Philips 7616X Manuale utente

Philips

Philips HQ802 Manuale utente

Philips

Philips HQ7363/17 Manuale utente

Braun

Braun WaterFlex WF2s Manuale utente

Philips

Philips NORELCO S7371 Manuale utente

Daga

Daga MT-400 Manuale

Philips

Philips RQ119x Manuale utente

Remington

Remington BHT100 Manuale utente

Philips

Philips Bodygroom BG2000 Manuale utente

Kompernass

Kompernass KH 5537 Manuale utente

Remington

Remington BHT6100 Manuale utente

Philips

Philips qc5365 Manuale utente

MIA

MIA Aqua Body Manuale utente

Philips

Philips NORELCO AT880 Manuale utente
