Thank you for purchasing a new Panasonic digital cordless phone.

Please read this installation manual before using the unit and

save it for future reference.

For assistance, visit our website:

http://www.panasonic.com/help

for customers in the U.S.A. or

Puerto Rico.

This unit is an additional handset compatible with the following

series of Panasonic Digital Cordless Phone:

KX-TG4321

You must register this handset with your base unit before it can

be used. This installation manual describes only the steps

needed to register and begin using the handset. Please read

the base unit’s operating instructions for further details.

Charge the batteries for about 7 hours before initial use.

5.8 GHz Additional Digital Cordless Handset

Model No. KX-TGA430

Installation Manual

PNQX1002YA DC1107PW1127

TGA430(e).fm Page 1 Wednesday, December 12, 2007 5:17 PM

2For assistance, please visit http://www.panasonic.com/help

Supplied accessories

*1 Please read the base unit's operating instructions for replacement

battery information.

*2 The handset cover comes attached to the handset.

Note:

LPlease read the base unit’s operating instructions for additional/

replacement accessories.

Sales and support information

LTo order additional/replacement accessories, call 1-800-332-5368.

LTTY users (hearing or speech impaired users) can call 1-866-605-

1277.

Connection

Note:

LUse only the supplied Panasonic AC adaptor PQLV209.

LThe AC adaptor must remain connected at all times. (It is normal for

the adaptor to feel warm during use.)

Accessory item/Order number Quantity

Charger/PNLC1001ZB 1

AC adaptor for charger/PQLV209T 1

Rechargeable batteries*1 2

Handset cover*2/PNYNTGA430BR 1

Hooks

(120 V AC,

60 Hz)

TGA430(e).fm Page 2 Wednesday, December 12, 2007 5:17 PM

For assistance, please visit http://www.panasonic.com/help 3

Battery installation and battery charge

Important:

LUse the supplied rechargeable batteries (Part No. HHR-65AAABU).

LWhen installing the batteries:

– Wipe the battery ends (S, T) with a dry cloth.

– Avoid touching the battery ends (S, T) or the unit contacts.

– Ensure correct polarities (S, T).

LWhen replacing the batteries:

– USE ONLY rechargeable Ni-MH batteries AAA (R03) size.

– Do NOT use Alkaline/Manganese/Ni-Cd batteries.

– We recommend using the Panasonic rechargeable batteries noted

in the base unit’s operating instructions for replacement battery

information.

1Press the notch on the handset cover firmly, and slide it in the

direction of the arrow.

2Insert the batteries negative (T) end first. Close the handset cover.

3Place the handset on the charger for about 7 hours before initial

use.

Note:

LIf the batteries are fully charged, but the operating time seems to be

shorter, clean the battery ends (S, T) and the charge contacts with a

dry cloth.

TGA430(e).fm Page 3 Wednesday, December 12, 2007 5:17 PM

4For assistance, please visit http://www.panasonic.com/help

Attention:

Registering a handset to a base unit

1Base unit:

Press and hold {LOCATOR}for 4 seconds until the registration tone

sounds.

LIf all registered handsets start ringing, press the same button to

stop. Then repeat this step.

LThe next step should be completed within 90 seconds.

2Handset:

Press {OK}, then wait until a long beep sounds.

Note:

LWhile registering, “Base registering”is displayed on all

registered handsets.

Display language

1{MENU}i{#}{1}{1}{0}

2{V}/{^}: Select the desired setting.

3Press the right soft key to save. i{OFF}

A nickel metal hydride battery that is

recyclable powers the product you

have purchased.

Please call 1-800-8-BATTERY (1-

800-822-8837) for information on how

to recycle this battery.

TGA430(e).fm Page 4 Wednesday, December 12, 2007 5:17 PM

For assistance, please visit http://www.panasonic.com/help 5

Wall mounting

1Drive the screws (not included) into the wall.

2Mount the charger (A), then slide it down (B) and to the right (C)

until it is secure.

25.4 mm

(1 inch)

Screws

(120 V AC, 60 Hz)

TGA430(e).fm Page 5 Wednesday, December 12, 2007 5:17 PM

6For assistance, please visit http://www.panasonic.com/help

For your safety

To prevent severe injury and loss of life/property, read this section

carefully before using the product to ensure proper and safe operation of

your product.

WARNING

Power connection

LCompletely insert the AC adaptor/power plug into the power outlet.

Failure to do so may cause electric shock and/or excessive heat

resulting in a fire.

LRegularly remove any dust, etc. from the AC adaptor/power plug by

pulling it from the power outlet, then wiping with a dry cloth.

Accumulated dust may cause an insulation defect from moisture, etc.

resulting in a fire.

LUnplug the product from power outlets if it emits smoke, an abnormal

smell, or makes an unusual noise. These conditions can cause fire or

electric shock. Confirm that smoke has stopped emitting and contact

the Panasonic Call Center at 1-800-211- PANA (1-800-211-7262).

Installation

LTo prevent the risk of fire or electrical shock, do not expose the product

to rain or any type of moisture.

LDo not place or use this product near automatically controlled devices

such as automatic doors and fire alarms. Radio waves emitted from

this product may cause such devices to malfunction resulting in an

accident.

CAUTION

Installation and relocation

LThe AC adaptor is used as the main disconnect device. Ensure that

the AC outlet is installed near the product and is easily accessible.

TGA430(e).fm Page 6 Wednesday, December 12, 2007 5:17 PM

For assistance, please visit http://www.panasonic.com/help 7

Battery

LWe recommend using the supplied batteries or additional/replacement

batteries noted in the base unit's operating instructions for

replacement battery information. USE ONLY rechargeable Ni-MH

batteries AAA (R03) size.

LDo not mix old and new batteries.

LDo not open or mutilate the batteries. Released electrolyte from the

batteries is corrosive and may cause burns or injury to the eyes or skin.

The electrolyte may be toxic if swallowed.

LExercise care when handling the batteries. Do not allow conductive

materials such as rings, bracelets or keys to touch the batteries,

otherwise a short circuit may cause the batteries and/or the conductive

material to overheat and cause burns.

LCharge the batteries provided with or identified for use with this

product only, in accordance with the instructions and limitations

specified in this manual.

LOnly use a compatible base unit (or charger) to charge the batteries.

Do not tamper with the base unit (or charger). Failure to follow these

instructions may cause the batteries to swell or explode.

Other information

LOperating the product near electrical appliances may cause

interference. Move away from the electrical appliances.

LUse only the power cord and batteries indicated in this manual. Do not

dispose of batteries in a fire. They may explode. Check with local

codes for possible special disposal instructions.

Routine care

LWipe the outer surface of the product with a soft moist cloth.

LDo not use benzine, thinner, or any abrasive powder.

Notice for product disposal, transfer, or return

LThis product can store your private/confidential information. To protect

your privacy/confidentiality, we recommend that you erase the

TGA430(e).fm Page 7 Wednesday, December 12, 2007 5:17 PM

8For assistance, please visit http://www.panasonic.com/help

information such as phonebook or caller list entries from the memory

before you dispose of, transfer, or return the product.

FCC and other information

This equipment is hearing aid compatible as defined by the FCC in 47

CFR Section 68.316.

When you hold the phone to your ear, noise might be heard in your

Hearing Aid. Some Hearing Aids are not adequately shielded from

external RF (radio frequency) energy. If noise occurs, use the

speakerphone option (if applicable) when using this phone. Consult with

your audiologist or Hearing Aid manufacturer about the availability of

Hearing Aids which provide adequate shielding to RF energy commonly

emitted by digital devices.

WHEN PROGRAMMING EMERGENCY NUMBERS AND(OR) MAKING

TEST CALLS TO EMERGENCY NUMBERS:

1) Remain on the line and briefly explain to the dispatcher the reason for

the call.

2) Perform such activities in the off-peak hours, such as early morning or

late evenings.

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may

cause undesired operation.

Privacy of communications may not be ensured when using this phone.

CAUTION:

Any changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate this

device.

TGA430(e).fm Page 8 Wednesday, December 12, 2007 5:17 PM

For assistance, please visit http://www.panasonic.com/help 9

NOTE:

This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following

measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

FCC RF Exposure Warning:

LThis product complies with FCC radiation exposure limits set forth for

an uncontrolled environment.

LThis handset may not be collocated or operated in conjunction with

any other antenna or transmitter.

LFor body-worn operation, the handset must be used only with a non-

metallic accessory. Use of other accessories may not ensure

compliance with FCC RF exposure requirements.

Notice

LFCC ID can be found inside the battery compartment or on the bottom

of the unit.

TGA430(e).fm Page 9 Wednesday, December 12, 2007 5:17 PM

10 For assistance, please visit http://www.panasonic.com/help

Notice

Lߎߩ⵾ຠߪޔᣣᧄ࿖ᄖߢߩ૶↪ࠍ⋡⊛ߣߒߡ⸳⸘ߐࠇߡ߅ࠅޔᣣᧄ

࿖ౝߢߩ૶↪ߪᴺᓞ㆑෻ߣߥࠅ߹ߔޕᓥߞߡޔᒰ␠ߢߪᣣᧄ࿖ౝߦ

߅޿ߡߪේೣߣߒߡୃℂߥߤߩࠨ࡯ࡆࠬߪ⥌ߒ߆ߨ߹ߔޕ

Lҏ౰ࠢட࣏୽ٺҢՄ೩Ȅӵڏт୽ড়᎛୵ܖٺҢȂџ૖ོႂІ࿋

ӴݲٽȄ

LThis product is designed for use in the United States of America.

Sale or use of this product in other countries may violate local laws.

LCet appareil est conçu pour être utilisé aux États-Unis d’Amérique.

La vente ou l’emploi de cet appareil dans certains autres pays peut

constituer une infraction à la législation locale.

LEste producto está diseñado para usarse en los Estados Unidos de

América.

La venta o el empleo de este producto en ciertos países puede

constituir violación de la legislación local.

TGA430(e).fm Page 10 Wednesday, December 12, 2007 5:17 PM

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Panasonic Cornetta

Panasonic

Panasonic KX-TGA930C Manuale utente

Panasonic

Panasonic KX-PD503UD Manuale utente

Panasonic

Panasonic KXTGA750E Manuale utente

Panasonic

Panasonic KX-PRWA13C Manuale utente

Panasonic

Panasonic KX-TGP500 Manuale utente

Panasonic

Panasonic KX-TGA850EX Manuale utente

Panasonic

Panasonic KX-TGA830E Manuale utente

Panasonic

Panasonic KX-TGMA44 Manuale utente

Panasonic

Panasonic KX-TGA470 Manuale utente

Panasonic

Panasonic KX-TGA106M - Cordless Extension Handset Manuale utente

Panasonic

Panasonic TGP600 Manuale utente

Panasonic

Panasonic KX-TGA550C Manuale utente

Panasonic

Panasonic KX-TGA648E Manuale utente

Panasonic

Panasonic KX-TGEA40 Manuale utente

Panasonic

Panasonic KX-TGA651B Manuale di istruzioni

Panasonic

Panasonic VL-WD613 Manuale utente

Panasonic

Panasonic KX-TGDA50 Manuale utente

Panasonic

Panasonic KX-TGA410 Manuale utente

Panasonic

Panasonic KX-TGFA30C Manuale utente

Panasonic

Panasonic KX-TGA572S Manuale utente

Panasonic

Panasonic KX-TGA786HK Manuale utente

Panasonic

Panasonic EBPH55S - CELL PHONE Manuale utente

Panasonic

Panasonic KX-TGA641E Manuale utente

Panasonic

Panasonic KX-TGFA61 Manuale utente

Manuali Cornetta popolari di altre marche

Swissvoice

Swissvoice ePure HD Manuale utente

Philips

Philips TD6736/BH051P Manuale utente

ASCOM

ASCOM I62 - Manuale utente

LG-Ericsson

LG-Ericsson LIP-9010 Manuale utente

GE 1583 Manuale utente

iiNet

iiNet Handset Manuale utente

ASCOM

ASCOM 9p23 Manuale utente

AT&T

AT&T DLP70110 Manuale utente

AirCell

AirCell ST 3100 Manuale utente

Eaton

Eaton HHIR-LCD-PROG Istruzioni per il montaggio

Mitel

Mitel 112 Manuale utente

SBC

SBC SBC-381H Manuale utente

Mitel

Mitel 5602 Manuale utente

ASCOM

ASCOM d81 Messenger Istruzioni per l'installazione

SpectraLink

SpectraLink 7522 Manuale utente

Avaya

Avaya L100 Series Come usare

ooma

ooma HD2 Handset Manuale utente

Yealink

Yealink IPW56 Manuale utente
