Installation Manual
KX-TGA786HK
Additional Digital Cordless Handset
Model No.
Thank you for purchasing a Panasonic product.
This unit is an additional handset compatible with the following series of
Panasonic Digital Cordless Phone:
KX-TG7851
(The corresponding models are subject to change without notice.)
You must register this handset with your base unit before it can be used. This
installation manual describes only the steps needed to register and begin using
the handset. Please read the base unit’s operating instructions for further details.
Please read this installation manual before using the unit and save it for future
reference.
Sole Agent for Hong Kong & Macau:
Block B, 9/F., Peninsula Centre 67 Mody Road Tsimshatsui East Kowloon,
Hong Kong
Tel: 2313 0888, Hotline: 2313 0666, Fax: 2368 8068
1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan
© Panasonic System Networks Co., Ltd. 2013
PNQX5901ZA TT0613YK0 (E)
TGA786HK(en-en)_0508_ver002.pdf 1 2013/05/08 18:13:34
Accessory information
Supplied accessories
Accessory item/Part number Quantity
Charger 1
AC adaptor/PNLV233E 1
Rechargeable batteries*1 2
Handset cover*2 1
*1 Please read the base unit’s operating instructions for replacement battery
information.
*2 The handset cover comes attached to the handset.
Note:
RPlease read the base unit’s operating instructions for additional/replacement
accessories.
2
Installation
TGA786HK(en-en)_0508_ver002.pdf 2 2013/05/08 18:13:34
Setting up
Connections
To power outlet
“Click”
Note:
RUse only the supplied Panasonic AC adaptor PNLV233E.
RThe AC adaptor must remain connected at all times. (It is normal for the adaptor
to feel warm during use.)
Battery installation/Battery charging
Important:
RUse the supplied rechargeable batteries. For replacement, we recommend using
the Panasonic rechargeable batteries noted in the base unit’s operating
instructions.
RWipe the battery ends ( , ) with a dry cloth.
RAvoid touching the battery ends ( , ) or the unit contacts.
RConfirm correct polarities ( , ).
RUSE ONLY Ni-MH batteries AAA (R03) size.
RDo NOT use Alkaline/Manganese/Ni-Cd batteries.
3
Installation
TGA786HK(en-en)_0508_ver002.pdf 3 2013/05/08 18:13:34
Charge for about 7 hours.
RWhen the batteries are fully charged, “Fully charged” is displayed.
Confirm “Charging”
is displayed.
Rechargeable Ni-MH
ONLY
Note:
RThe handset display may show “Please wait for 1 minute.” when the
handset is placed on the charger if it is not registered to the base unit.
RIf the batteries are fully charged, but the operating time seems to be shorter,
clean the battery ends ( , ) and the charge contacts with a dry cloth and
charge again.
RTo maximise battery life, it is recommended that the handset batteries be fully
discharged (used) until flashes once every few months.
Registering the handset to the base unit
Ensure that the handset is switched on. If it is not on, press and hold MeN for
few seconds to turn the handset on.
1Handset:
Lift the handset and press MeN.
2Base unit:
Press and hold MN for about 5 seconds.
RDepending on the base unit, a registration tone sounds.
RIf all registered handsets start ringing, press MN again to stop, then repeat
this step.
3Handset:
Place the handset on the base unit or charger.
RContinue the operation even when the handset display shows “Please
wait for 1 minute.”.
4With the handset still on the base unit or charger, wait until a confirmation tone
sounds and is displayed.
4
Installation
TGA786HK(en-en)_0508_ver002.pdf 4 2013/05/08 18:13:34
Note:
RIf an error tone sounds, or if is displayed, register the handset according to
the base unit’s operating instructions.
For your safety
To prevent severe injury and loss of life/property, read this section carefully before
using the product to ensure proper and safe operation of your product.
WARNING
Power connection
RCompletely insert the AC adaptor/power plug into the power outlet. Failure to do
so may cause electric shock and/or excessive heat resulting in a fire.
RRegularly remove any dust, etc. from the AC adaptor/power plug by pulling it
from the power outlet, then wiping with a dry cloth. Accumulated dust may cause
an insulation defect from moisture, etc. resulting in a fire.
RUnplug the product from power outlets if it emits smoke, an abnormal smell, or
makes an unusual noise. These conditions can cause fire or electric shock.
Confirm that smoke has stopped emitting and contact an authorised service
centre.
Installation
RTo prevent the risk of fire or electrical shock, do not expose the product to rain
or any type of moisture.
RDo not place or use this product near automatically controlled devices such as
automatic doors and fire alarms. Radio waves emitted from this product may
cause such devices to malfunction resulting in an accident.
CAUTION
Installation and location
RThe AC adaptor is used as the main disconnect device. Ensure that the AC
outlet is installed near the product and is easily accessible.
Battery
RWe recommend using the supplied batteries or additional/replacement batteries
noted in the base unit’s operating instructions for replacement battery
information. USE ONLY rechargeable Ni-MH batteries AAA (R03) size.
RDo not mix old and new batteries.
5
Installation
TGA786HK(en-en)_0508_ver002.pdf 5 2013/05/08 18:13:34
RDo not open or mutilate the batteries. Released electrolyte from the batteries is
corrosive and may cause burns or injury to the eyes or skin. The electrolyte is
toxic and may be harmful if swallowed.
RExercise care when handling the batteries. Do not allow conductive materials
such as rings, bracelets, or keys to touch the batteries, otherwise a short circuit
may cause the batteries and/or the conductive material to overheat and cause
burns.
RCharge the batteries provided with or identified for use with this product only, in
accordance with the instructions and limitations specified in this manual.
ROnly use a compatible base unit (or charger) to charge the batteries. Do not
tamper with the base unit (or charger). Failure to follow these instructions may
cause the batteries to swell or explode.
Important safety instructions
When using your product, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, and injury to persons, including the following:
1. Do not use this product near water for example, near a bathtub, washbowl,
kitchen sink, or laundry tub, in a wet basement or near a swimming pool.
2. Do not use the telephone to report a gas leak in the vicinity of the leak.
3. Use only the power cord and batteries indicated in this manual. Do not dispose
of batteries in a fire. They may explode. Check with local codes for possible
special disposal instructions.
SAVE THESE INSTRUCTIONS
6
Installation
TGA786HK(en-en)_0508_ver002.pdf 6 2013/05/08 18:13:34
Other information
ROperating the product near electrical appliances may cause interference. Move
away from the electrical appliances.
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of
used batteries according to the instructions.
Routine care
RWipe the outer surface of the product with a soft moist cloth.
RDo not use benzine, thinner, or any abrasive powder.
Notice for product disposal, transfer, or return
RThis product can store your private/confidential information. To protect your
privacy/confidentiality, we recommend that you erase information such as
phonebook or caller list entries from the memory before you dispose of, transfer,
or return the product.
Information on Disposal in other Countries outside the European Union
These symbols are only valid in the European Union. If you wish to discard these
items, please contact your local authorities or dealer and ask for the correct
method of disposal.
7
Installation
TGA786HK(en-en)_0508_ver002.pdf 7 2013/05/08 18:13:34
