Panasonic KX-TGW420 Manuale utente

PNQW5779ZA PP1119MU0

Printed in Malaysia

Connecting the AC adaptor/corded handset

1Connect the AC adaptor to the unit by pressing the plug firmly.

2Connect the AC adaptor to the power outlet.

3Fasten the AC adaptor cord by hooking it.

4Connect the corded handset cord to the corded handset and the base unit until you hear a click.

LUse only the supplied AC adaptor KSAS0050750080VUD.

Connecting the telephone line cord

NTo connect to four single-line telephone jacks

1Connect the 4-wire telephone line cords to each

ports.

2Connect the single-line telephone jacks (RJ11C)

until you hear a click.

1 1 1 1

Model No. KX-TGW420

Quick Guide

TGW420_(en-en)_QG.fm 1 ページ２０１９年１２月１２日　木曜日　午後５時３９分

– 2 –

NTo connect to two 2-line telephone jacks

1Connect the 4-wire telephone line cords to LINE1/2

and LINE 3/4 port.

2Connectthe2-linetelephonejacks(RJ14C) until you

hear a click.

Operating tips

Soft keys

By pressing a soft key, you can select the feature shown directly above it on

thedisplay.Pay attention to the display to see whatfunctions the soft keys are

assigned during operation.

Navigator key

−{^}, {V}, {<}, or {>}: Scroll through various lists and items.

Date and time

1{Menu}

2{r}: “Phone Settings”s{Select}

3{r}: “Date & Time”s{Select}

4Enter the current year. s{V}

5Enter the current month and date. s{V}

6{34}: Select the clock format (“12hr”or “24hr”). s{V}

7Enter the current hour and minute. s{V}

8{34}: Select the time adjustment setting.*1

9{Save}

10 Press {Back}or {Home}repeatedly to return to standby mode.

*1 This feature allows the unit to automatically adjust the date and time each time caller information

including date and time is received. To turn this feature on, select “On”. To turn this feature off, select

“Off”. (Caller ID subscribers only).

Connecting the telephone line cord

1 1

If you subscribe to a DSL/ADSLservice, attach a DSL/ADSL filter to the telephone line between the base

unit and each telephone line jack.

Calls Ph.Book Menu

{V}

{^}

{}

TGW420_(en-en)_QG.fm 2 ページ２０１９年１２月１２日　木曜日　午後５時３９分

– 3 –

Recording your greeting message of the answering system

You can record your own greeting message instead of using a pre-recorded greeting message.

1{Menu}

2{r}: “Answering System”s{Select}

3{r}: “General Greeting”or “Announce Only”s{Select}

4{r}: “Record Greeting”or “Record Announce Only”s{Select}

5Record a greeting message. s{Save}

LThe greeting message is played back. To stop playback, press {Stop}.

6Press {Back}or {Home}repeatedly to return to standby mode.

Basic operations

Making/Answering calls

Making calls Dial the phone number. sLift the corded handset, or press {s}.

Answering calls Lift the corded handset, or press {s}.

To hang up Place the corded handset on the cradle. When the speakerphone

is used, press {s}.

To adjust the receiver or speaker

volume Press {+} or {-} repeatedly while talking.

To adjust the ringer volume Press {+} or {-} repeatedly to select the desired volume while

ringing.

Phonebook

Adding entries 1{Ph.Book}s{New}

2Enter the party’s name (16 characters max.). s{Select}

3Enter the party’s phone number (32 digits max.). s{Save}

4Press {Back}or {Home}repeatedly to return to standby mode.

Making calls 1{Ph.Book}

2{r}: Select the desired entry. s{View}

3Lift the corded handset or press {s}.

Answering system

Answering on/off 1{F}

2{r}: “General MB: On/Off”s{Select}

3{r}: “On”, “Off”or “Announce Only”s{Select}

4Press {Back}to return to standby mode.

Listening to messages 1{F}

2{r}: “Play Messages”s{Select}

3When finished, press {Stop}.

4Press {Back}to return to standby mode.

TGW420_(en-en)_QG.fm 3 ページ２０１９年１２月１２日　木曜日　午後５時３９分

– 4 –

Digital Receptionist

Digital Receptionist on/off 1{Menu}

2{r}: “Digital Receptionist”s{Select}

3{r}: “D.R.: On/Off”s{Select}

4{r}: Select the desired line which you want to activate/

deactivate the digital receptionist.

5{34}: Select the desired setting. s{Select}

6Press {Back}or {Home}repeatedly to return to standby mode.

Recordingyourgreetingmessagefor

Digital Receptionist 1{Menu}

2{r}: “Digital Receptionist”s{Select}

3{r}: “Day Greeting”, “Night Greeting”or “Auxiliary

Greeting”. s{Select}

4{r}: “Record Greeting”s{Select}

5Afterabeepsounds,speak clearly about 20 cm (8 inches) away

from the microphone.

6Press {Save}to stop recording.

LThe greeting message is played back. To stop playback,

press {Stop}.

7Press {Back}or {Home}repeatedly to return to standby mode.

Frequently asked questions

Question Cause/solution

How can I increase the base unit

volume level? LPress {+} repeatedly while talking.

Can I add another accessory unit to

my base unit? LYes, you can add up to 9 desk phones/cordless handsets to a

single base unit.

LTo purchase additional accessory unit(s) (KX-TGWA40/KX-

TGWA41),

please visit: http://shop.panasonic.com/support

TTY users (hearing or speech impaired users) can call 1-877-833-

8855.

How can I answer a call waiting call

(2nd call)? LPress {Flash}when you hear the call waiting tone.

Basic operations

TGW420_(en-en)_QG.fm 4 ページ２０１９年１２月１２日　木曜日　午後５時３９分
