Panasonic KX-UT123 Manuale

Panasonic KX-UT13X

Admin Guide

Schmooze Com Inc.

Panasonic

ABC

DEF

GHI

CONFERENCE

REDIAL

MESSAGE

HOLD

MUTE

AUTO

ANSWER

TRANSFER

CANCEL

SP-PHONE/

HEADSET

FLASH/

RECALL

PQRS

JKL

TUV

OPER

MNO

WXYZ

KX-UT136

DO NOT DISTURB

FORWARD/

23 JAN. 04:38PM MON

4703:UT136

ENTER

KX-UT123, KX-UT133 & KX-UT136

How To Find IP Address and MAC Address

Quick Steps

1. Press the “Setting” button.

2. Select “Information Display”.

3. Scroll down to see either the IP address or the MAC address.

How To Set the Configuration Server

Quick Steps

1. Log into the Web Admin GUI of the phone.

2. Select the “Maintenance” tab at the top right.

3. Next select “Provisioning Maintenance”.

4. You can now specify the provisioning server information. In our example we are using

tftp://10.10.0.1/Config{MAC}.cfg (Reference the screen above).

How To Factory Default

Quick Steps

1.Log into the Web Admin GUI of the phone

2. Next select the “Maintenance” tab at the top right.

3. Now select “Reset to Defaults” on the left navigation menu.

4. Finally click the “Reset Web Settings” button to complete the reset.

Panasonic

KX-UT136

11 Jan. 01:36PM FRI

4702:UT136

Setting Call Log

Panasonic

KX-UT136

Back Enter

Key Click Tone

FWD/DND Setting

Language

Date and Time

Information Display

Panasonic

KX-UT136

Back

MAC Address

000000000000

Panasonic

KX-UT136

Back

IP Address

10. 4. 0.163

How To Find IP Address and MAC Address

Quick Steps

1. Press the “Setting” button.

2. Select “Information Display”.

3. Scroll down to see either the IP address or the MAC address.

How To Set the Configuration Server

Quick Steps

1. Log into the Web Admin GUI of the phone.

2. Select the “Maintenance” tab at the top right.

3. Next select “Provisioning Maintenance”.

4. You can now specify the provisioning server information. In our example we are using

tftp://10.10.0.1/Config{MAC}.cfg (Reference the screen above).

How To Factory Default

Quick Steps

1.Log into the Web Admin GUI of the phone

2. Next select the “Maintenance” tab at the top right.

3. Now select “Reset to Defaults” on the left navigation menu.

4. Finally click the “Reset Web Settings” button to complete the reset.

KX-UT136 Status Network System VoIP Telephone Maintenance

Web Port Close

Status

Version Information

Network Status

VoIP Status

Version Information

Model KX-TGP550T04

Operating BANK Bank2

IPL Version 01.02

Bank1: 12.12

Firmware Version Bank2: 12.12

Web Port Close

Maintenance

Firmware Maintenance

Provisioning Maintenance

Reset to Defaults

Restart

Provisioning Maintenance

Enable Provisioning Yes No

Standard File URL http://10.10.0.1:2004/Conﬁg{MAC}.cfg

Product File URL

Master File URL

Cyclic Auto Resync Yes No

Resync Interval 10080 minute(s) [1-40320]

Header Value for

Resync Event check-sync

Save Cancel

KX-UT136 Status Network System VoIP Telephone Maintenance

How To Find IP Address and MAC Address

Quick Steps

1. Press the “Setting” button.

2. Select “Information Display”.

3. Scroll down to see either the IP address or the MAC address.

How To Set the Configuration Server

Quick Steps

1. Log into the Web Admin GUI of the phone.

2. Select the “Maintenance” tab at the top right.

3. Next select “Provisioning Maintenance”.

4. You can now specify the provisioning server information. In our example we are using

tftp://10.10.0.1/Config{MAC}.cfg (Reference the screen above).

How To Factory Default

Quick Steps

1.Log into the Web Admin GUI of the phone

2. Next select the “Maintenance” tab at the top right.

3. Now select “Reset to Defaults” on the left navigation menu.

4. Finally click the “Reset Web Settings” button to complete the reset.

KX-UT136 Status Network System VoIP Telephone Maintenance

Web Port Close

Status

Version Information

Network Status

VoIP Status

Version Information

Model KX-TGP550T04

Operating BANK Bank2

IPL Version 01.02

Bank1: 12.12

Firmware Version Bank2: 12.12

Web Port Close

Maintenance

Firmware Maintenance

Provisioning Maintenance

Reset to Defaults

Restart

Reset to Defaults

Reset Web Data

KX-UT136 Status Network System VoIP Telephone Maintenance

The Web data for this unit will be reset to it’s default values when you click [Reset Web Settings].

Reset Web Settings

Web Port Close

Maintenance

Firmware Maintenance

Provisioning Maintenance

Reset to Defaults

Restart

Provisioning Maintenance

Enable Provisioning Yes No

Standard File URL http://10.10.0.1:2004/Conﬁg{MAC}.cfg

Product File URL

Master File URL

Cyclic Auto Resync Yes No

Resync Interval 10080 minute(s) [1-40320]

Header Value for

Resync Event check-sync

Save Cancel

KX-UT136 Status Network System VoIP Telephone Maintenance

Schmooze Com Inc.

http://schmoozecom.com

(920) 886-8130
