PRODUCT FEATURES

• Activ Matrix TFT

• High contrast ratio

• Spac saving d sign

• 2x BNC composit inputs with loop

through outputs

• S-Vid o in/out*

• VGA for PC input

• VESA compatibl for v rsatil mounting

• Built-in sp ak rs

• Gradual volum incr as

• R mot control

ACCESSORIES

• PRMK08 - rack mount kit for PLCD8C

• PLCDRMK - rack mount kit for PLCD15V

and PLCD20P monitors

DESCRIPTION

Th “PLCD” S ri s off rs Activ Matrix TFT with ov r 16 million

colors d liv ring robust color r production and xc ptional clarity

and d tail. Th PLCD42HD and PLCD24HD boast high d finition

r solution, 16:9 asp ct ratio and includ a DVI and HDMI input.

All fiv LCD monitors includ two built-in sp ak rs with gradual

volum incr as for ff ctiv audio. Th s LCD displays ar

d sign d to provid long r lif than conv ntional CRTs with

significant n rgy savings and a small r physical footprint.

All fiv mod ls ar VESA compatibl for asy mounting.

PLCD15V

PLCD8C

PLCD20P

PLCD42HD

PLCD24HD

PLCD8C

PLCD15V

PLCD20P

PLCD24HD

PLCD42HD

*d p nds on mod l

PLCD8C

PLCD15V

PLCD20P

PLCD24HD

PLCD42HD

1-877-733-3689

panasonic.com/secu ity

DISTRIBUTED BY:

Specification PLCD8C* PLCD15V* PLCD20P* PLCD24HD* PLCD42HD*

Scr n Siz 8" 15" 20" 24" 42”

Pix l Typ Activ Matrix TFT Activ Matrix TFT Activ Matrix TFT Activ Matrix TFT Activ Matrix TFT

Max. R solution 800 x 600 1024 x 768 1600 x 1200 1920 x 1200 1920 x 1080

Brightn ss 250cd/m² 250cd/m² 300cd/m² 400cd/m² 500cd/m²

Contrast Ratio 500:1 600:1 800:1 1000:1 1300:1

Asp ct Ratio 4:3 4:3 4:3 16:9 16:9

Vi wing Angl (H/V) 140˚/120˚ 160˚/160˚ 178˚/178˚ 160˚/160˚ 178˚/178˚

Display Color .26 million 16.7 million 16.7 million 16.7 million 16.7 million

R spons Tim 25ms (typ.) < 8ms (typ.) < 16ms (typ.) < 15ms (typ.) 5ms (gray to gray)

Sp ak rs 1W x 2 2W x 2 2W x 2 2W x 2 2W x 2

Gradual Volum Incr as Y s Y s Y s Y s Y s

Vid o In/Out (BNC) 2 / 2 2 / 2 2 / 2 2 / 2 2 / 2

S-Vid o In/Out 1 / 0 1 / 1 1 / 1 1 / 1 1 / 1

RGB In (15Pin D-Sub) 11 1 11

Compon nt ~~ 1 11

DVI In / HDMI In N/A N/A 1 / 1 1 / 1 1 / 1

Audio In/Out (RCA) N/A 1 S t (L+R)/No Output 2 / 2 2 / 2 2 / 1

PC St r o In 11 1 11

Multi Display N/A N/A PIP / PBP1 / PBP2 PIP / PBP1 / PBP2

Filt r Typ 3D Combfilt r/ RGB V rtical Strip 3D Combfilt r/ 3D Combfilt r/ 3D Combfilt r/

D int rlac Color Filt r D int rlac D int rlac D int rlac

Outlin Dim nsion 8.47" x 7.25" x 1.55" 13.82" x 13.7" x 7.87" 18.12"x15.55"x3.19" 22.45"x15.31"x3.7" 41.85" x 28.45" 12.0"

(215.3 x 184.3 x 39.4mm) (351 x 348 x 200mm) (460.4x395.1 x 81mm) (570.4 x 389x94mm) (1063 x 725 x 305mm)

Gross W ight 4.9 lbs (2.25kg) 12.57 lbs (5.7kg) 23.1 lbs (10.5kg) 26.46 lbs (12kg) 77.2 lbs (35kg)

Consumption <21W <36W <70W <110W 250W

El ctrical Ratings AC100~240V (50/60Hz) AC100~ 240V (50/60Hz), AC100~ 240V (50/60Hz), AC100~240V (50/60Hz) AC100~240V (50/60Hz)

DC 12V / 3A DC 12V / 5.83A

*OEM partnership

Product sp cifications ar subj ct to chang without notic . 7/09
