Panasonic PT-D4000E Manuale utente

PT-D4000E

DLP Projector

1600:1 Contrast Ratio

1-Chip DLP (TM) Technologie

1024 x 768 Resolution

4000 ANSI-Lumen

DLP Device

Device DLP™ chip x 1, DLP™ system, 0.7˝ diagonal (4:3 aspect ratio)

Pixels 786,432 (1,024 x 768) x 1, total of 786,432 pixels

Lens

Type Powered zoom/focus lenses (4:3 aspect ratio: 1.8 –2.4:1)

F1.7–2.0

f25.6–33.8 mm

Lamp

Type 210 W UHM™ lamps (x 2) (dual lamp system)

Screen

Size [mm]

Minimum 1270.0

Maximum 15240.0

Projection Distance [m]

Minimum 1.9

Maximum 29.3

Aspect Ratio 4:3

Colour System 7 standards (NTSC/NTSC4.43/PAL/PAL-N/PAL-M/SECAM/PAL60)

Brightness (lumens) 4000.0

Contrast (high mode) 1600:1

Resolution

Native 1024 x 768 pixels

Maximum 1600 x 1200 pixels compatible, compression mode

Features

HD Ready no

Native 16:9 Capable yes

Keystone Correction yes

Lensshift yes

24/7 Operation no

Daylight View yes

Lamp Protection no

Programmable Remote Control no

Flexible Angle Setting no

WLAN Picture and Sound no

Multi-Index Window no

Speed Start no

Auto Setup yes

Liquid Cooling System no

Dustproof Design no

Dual Lamp System yes

Edge Blending no

Changeable Lens yes

Portable no

Anti-theft Protection yes

Changeable Input Board no

Smooth Screen no

Picture in Picture no

Colour Correction yes

Wired LAN Connection yes

Terminals

DVI-D yes

HDMI no

RGB In yes

RGB Out no

Composite Video yes

S-Video yes

SCART no

Audio In no

Audio Out no

LAN yes

RS232 In yes

RS232 Out yes

Remote In yes

USB Mouse no

Component Video (YPbPr) yes

Keystone Correction Range Vertical: ±30°

Centre-to-corner uniformity ratio 0.9

Scanning Frequency

RGB Horizontal: 15–91 kHz, Vertical: 50–85 Hz, Dot clock: 150 MHz or lower

YPaPr 480i:fH15.75kHz;fV59.94Hz, 576i:fH15.63kHz;fV50Hz, 480p:

fH31.50kHz;fV 59.94Hz, 576p:fH31.25kHz;fV50Hz, 720/60p:fH45kHz;

fV60Hz, 720/50p:fH 37.5kHz;fV50Hz, 1035/60i:fH33.75kHz;fV60Hz,

1080/60i:fH33.75kHz;fV60Hz, 1080/50i:fH28.13kHz;fV50Hz, 1080/60p:

fH67.5kHz;fV60Hz, 1080/50p:fH 56.25kHz;fV50Hz

S-Video / Video Horizontal: 15.75/15.63 kHz, Vertical: 50/60 Hz,(NTSC, NTSC4.43,

PAL, PAL60, PAL-N, PAL-M, SECAM)

Optical Axis Shift Horizontal (manual) and vertical (powered), Horizontal: ±10%, verti-

cal: +50%

On-screen menu 9 languages: English, French, German, Spanish, Italian, Russian, Ko-

rean, Chinese, and Japanese

Installation Ceiling/floor, front/rear

General

Power Supply 220–240 V AC, 50/60 Hz

Power Cord Length [m] 3.0

Cabinet Material Molded plastic

Dimensions [mm]

Width 530.0

Height 167.0

Depth 441.0

Weight [kg] 13.7

Amps 2.7

Operating Environment

Temperature 0°-45°C

Humidity 20%–80% (no condensation)

Remote Control Unit

Power Supply 3 V DC (AA battery x 2)

Operation Range

Approx. 30 m (98.4 feet) when operated from directly in front of the si-

gnal receptor

Dimensions [mm]

Width 51.0

Height 176.0

Depth 22.5

Weight [g] 134.0

Standard Accessories Power cord

Wireless/wired remote control unit

Batteries for remote control (x 2)

Wire rope

Optional Accessories Replacement lamp unit: ET-LAD40

Ceiling mount bracket for high ceilings: ET-PKD56H

Ceiling mount bracket for low ceilings: ET-PKD55S

Zoom lens (1.3-1.8:1) ET-DLE100

Zoom lens (2.4-4.0:1) ET-DLE200

Zoom lens (3.8-6.0:1) ET-DLE300

Zoom lens (5.8-8.1:1) ET-DLE400

Fixed-focus lens (0.8:1) ET-DLE050

Diagonal [mm]

Base Diagonal 1270.0

Maximum Diagonal 15420.0
