the new fw430 series

with flexibility built-in

Panasonic

Pt-fw430u

Panasonic

Pt-fx400u

LCD Panel

Brightness 3,500 lm 4,000 lm

Contrast 600:1 (full on/full off)

Resolution 1,280 x 800 pixels 1,024 x 768 pixels

Panel Size

18.9 mm

(0.74 inches) diagonal

(16:10 aspect ratio)

20.3 mm

(0.8 inches) diagonal

(4:3 aspect ratio)

LCD Panel Transparent LCD panel (x3, R/G/B)

Reliability/

Stability

Lamp 250W UHM Lamp

Lamp Replacement

Cycle 6,000 hours

Air Filter Eco Filter (12,000-hour replacement cycle)

Basic

Function

Detail Clarity

Processor 3 Yes

Daylight View

Premium Yes

Eco Management

Functions Yes

Power Consumption 330W (standby mode Eco: 0.3W, Normal: 9W)

Audible Noise 33dB (lamp normal mode) / 29dB (lamp eco mode)

Installation

Vertical / Horizontal

Lens Shift Yes

Lens 2x Zoom Lens

Wireless with optional wireless module (ET-WM200U)

Side-by-Side Function Yes —

Terminal

HDMI 1 input (HDCP, Deep Color available)

DVI-I 1 input (digital / analog available)

Wired LAN (RJ-45) 1

Dimensions (W x H x D) 16-15/16" x 4-15/16" x 12-23/32"

(with legs at shortest position)

Weight 13.2 lbs.

Supplied Accessories

Power cord with security lock, wireless remote control

unit, batteries for remote control unit (AA/R6/LR6 type

x 2), lens cover, software CD-ROM (Logo Transfer

Software, Multi Projector Monitoring & Control Software

Ver. 2.5, Wireless Manager ME 5.5)

panasonic.com/business-solutions

you’ll find the fw430 series

extremely accommodating.

increased flexibility for easy installation and oPeration.

Panasonic’s new-generation FW430 Series projectors are easy to install, user-

friendly and reliable. With features such as a 2x zoom lens, horizontal/vertical lens

shift and HDMI / DVI-I digital input terminals, these high-performing projectors ﬁt

well within existing mounting positions and cablings, thereby eliminating the need

for potentially disruptive and costly construction. In new installations, the same

features easily accommodate a wide range of room sizes and shapes.

For complete freedom of use, the optional wireless module (ET-WM200U) enables

wireless operation from one or multiple laptops located anywhere in the room.

A wireless projection application is free and available on the App Store that makes

it possible to use the iPad®, iPhone®or iPod touch®with iOS 4.1 for wireless

presentations with the FW430 Series projectors.

imProved reliability

with easy maintenance

• An original lamp drive system enables a 6,000-hour lamp

replacement cycle,*1giving you more time for brilliant presentations.

• A dust-resistant cabinet and a new, reusable Eco Filter with a

12,000-hour replacement cycle*2protect the internal electronic

components from dust.

• The lamp is easily replaced from the rear and the lter is quickly

replaced through the side panel, even while the projector is mounted

on a ceiling.

Learn how Panasonic projectors can bring your presentations to life.

Visit panasonic.com/business-solutions.

suPerior image Quality

in any environment

• Panasonic’s Detail Clarity Processor 3 brings depth and clarity

to details.

• Daylight View Premium senses the ambient light and adjusts output

for sharp, clear images even in brightly lit rooms.

*1 This value is calculated by continuously turning the lamp on for 2 hours and off for 0.25 hours. The lamp replacement cycle will decrease if the lamp is

turned on/off more frequently, or if it is left on for longer intervals.

*2 The usage environment affects the duration of the ﬁlter.

Pt-fw430u and Pt-fx400u key features:
