Panasonic PT-LB51NTE Manuale utente

Wireless Function Edition

(PT-LB51NTE)

(PT-LB51NTU)

※The projectors illustrated as examples are PT-LB51NTE.

Macintosh

TQBH0188-4 (E/U)

Contents

Selecting the connection method ………………… 15

Software Licensing Agreement …………………… 3

Notes on Using Wireless Connection …………… 4

What you can do with Wireless Manager mobile edition 4.5

…6

Check your computer ……………………………… 7

Useful Functions …………………………………… 21 Shutter function …………………………………………………… 21

Setting options ……………………………………… 22

Setting option window …………………………………………… 22

Transmission……………………………………………………… 22

Key setting………………………………………………………… 23

Other ……………………………………………………………… 24

Version information ……………………………………………… 24

Network setting of the projector ………………… 25

Displaying the Wireless Menu ………………………………… 25

Changing the network number ………………………………… 26

[User] settings …………………………………………………… 26

IP address settings ……………………………………………… 26

Wireless settings ………………………………………………… 27

Default settings of [USER1]-[USER3] ………………………… 28

Changing the projector name…………………………………… 29

Password setting ………………………………………………… 29

Live mode cut-in…………………………………………………… 30

Verifying settings ………………………………………………… 31

Returning to the Initial Settings ………………………………… 31

Software Installation ………………………………… 8

System requirements ……………………………………………… 8

Contents on Provided CD-ROM …………………………………… 9

Wireless Manager ME 4.5 ………………………………………… 9

Connect………………………………………………… 10

Easy Wireless Set Up …………………………………………… 10

Detailed settings ………………………………………………… 10

Connection error messages …………………………………… 13

Connecting through the access point ………………………… 14

Other operations for connection ………………… 16

Operations when password entry is required for connection

…16

Adding and deleting connections ……………………………… 16

Searching by projector’s ID …………………………………… 17

Canceling the connection ……………………………………… 18

Various projection methods ……………………… 19

Menu description ………………………………………………… 19

Live mode…………………………………………………………… 20

Using WebBrowser ………………………………… 32

Before using the WebBrowser control ………………………… 32

Accessing from the WebBrowser ……………………………… 33

Monitor information window …………………………………… 34

Projector control window………………………………………… 35

Detailed settings window ……………………………………… 36

Software Uninstall …………………………………… 38 Wireless Manager ME 4.5………………………………………… 38

Glossary ……………………………………………… 39 Frequently Asked Questions ……………………… 41

Please note the following.

• Panasonic cannot be held liable for any direct or indirect damages resulting from the use or malfunction of this projector.

• Panasonic cannot be held liable for damages arising from data corruption or loss as a result of using this projector.

Use of this Software is governed by the terms defined in this Software Licensing Agreement.

Article 1 License

Licensee is granted the right to use this software, including the information recorded or described on the CD-ROM and in the

instruction manual and any other media provided to the Licensee (collectively “Software”), but all applicable rights to copyright

or intellectual property in the Software are not transferable to the Licensee.

Article 2 Use by a Third Party

Licensee may not transfer or allow any third party, to use or copy the Software, whether free of charge or not.

Article 3 Restrictions on Copying the Software

Licensee may make a single copy of the Software in whole or in part solely for backup purposes.

However this excludes those copied using this software.

Article 4 Computer

Licensee may install and use the Software on more than one computer owned or managed by Licensee. However, such use

is restricted to only applications involving the projector.

Article 5 Reverse Engineering, Decompiling or Disassembly

Licensee may not reverse engineer, decompile or disassemble the Software. Matsushita shall not be bound by warranty for

any defects in the Software caused by Licensee’s reverse engineering, decompiling or disassembly of the Software.

Furthermore, Matsushita or its distributors or dealers will not be responsible for any damage to the Licensee caused by

Licensee’s reverse engineering, decompiling or disassembly of the Software.

Article 6 After-sales Service

If a problem should occur with the Software while Licensee is using the Software, Licensee should notify Matsushita of the

problem by telephone or letter. Matsushita shall undertake to notify Licensee of whether the problem is a known error in the

program (“bug”), or whether the way in which the Software is to be used should be modified.

Furthermore, the Software is subject to revision without prior notice.

Article 7 Indemnification

Matsushita’s liability with respect to this Software is limited to the conditions defined in Article 6 herein.

Matsushita or any of its distributors or dealers shall not be liable for any damage suffered by Licensee, either directly or

through claims from a third party, arising from or in connection with Licensee’s use of the Software.

Furthermore, Matsushita makes absolutely no warranty for the use of this Software for any purpose other than for applications

associated with the projector with which this Software is bundled.

Article 8 Export Control

Licensee agrees not to export or re-export the Software to any county other than the country of purchase of the projector in

any form without the appropriate export licenses under the regulations of the country where Licensee resides or of any other

country as may be required by such export or re-export.

Wireless Manager uses the following software:

Portion of this software are based in part on the work of the Independent JPEG Group

Software Licensing Agreement

Wireless connection function of the projector uses radio waves in the 2.4 GHz band.

A radio station license is not required, but be sure to read and fully understand the following items before use.

Do not use near other wireless equipment.

The following equipment may use radio waves in the same band as the projector.

When the projector is used near these devices, radio wave interference may make communication impossible, or the

communication speed may become slower.

• Microwave ovens, etc.

• Industrial, chemical and medical equipment, etc.

• In-plant radio stations for identifying moving objects such as those used in factory manufacturing lines, etc.

• Designated low-power radio stations

If at all possible, avoid the use of cellular phones, TV sets or radios near the projector.

Cellular phones, TV sets, radios and similar devices use different radio bands from

the projector, so there is no effect on

wireless communication or the transmission and reception of these devices. However, radio waves from the projector may produce

audio or video noise.

Wireless communication radio waves cannot penetrate steel reinforcements, metal, concrete,

etc.

Communication is possible through walls and floors made from materials such as wood and glass (except glass containing

wire mesh), but not through walls and floors made from steel reinforcements, metal, concrete, etc.

Avoid using the projector in locations prone to static electricity.

If the projector is used in a location prone to static electricity, such as on a carpet, the wireless LAN connection may be lost.

If this happens, eliminate the source of static electricity or electromagnetic noise and reconnect to the wireless LAN.

In rare cases static electricity or electromagnetic noise may make it impossible to establish a connection to the LAN.

If this happens, press the power button on the remote control or on the projector to power off the projector temporarily.

After the cooling fan stops operating (after the power monitor on the projector changes from orange to red), power on the

projector and reconnect to the LAN.

Using the projector outside the country

It is forbidden to take the projector outside the country or region where you purchased it, so use it only in the said country or

region. Also, note that depending on countries or regions there are restrictions on the channels and frequencies at which you

can use the wireless LAN.

Notes on Using Wireless Connection

Notes on Using Wireless Connection (cont.)

Channels that can be used

The channels (frequency range) that can be used differ according to the country or region. Refer to the table below.

Country or region Standard Channels used Frequency band

(Center frequency)

Japan ARIB STD-T66

1 - 13 2,412 MHz -

2,472 MHz

China SRRC

England, Germany, France, Spain,

Italy, Belgium, Austria, Sweden, Norway,

Denmark, Switzerland, Holland, Finland,

Portugal, Greece, Thailand, South Korea

ETSI 300.328

Singapore IDA

Australia,

New Zealand C-Tick

Malaysia SIRIM

United States FCC part 15

1 - 11 2,412 MHz -

2,462 MHz

Taiwan DGT

What you can do with Wireless Manager mobile edition 4.5

Network Transmission

You can connect the projector to a computer via the wireless LAN and send moving and still images.

Refer to page 10 for details on how to connect.

<Live mode> (See page 20)

Used for normal presentations.

<WebBrowser control> (See page 32)

The following operations are possible when using WebBrowser control.

• Setting and adjusting the projector

• Displaying the projector status

<One-click Connection> (See page 24)

You can connect to the projector by double-clicking or using drag-and-drop.

<Live mode cut-in function> (See page 30)

During the live mode, a different computer can interrupt and project images in the live mode.

Check your computer

• First, check your computer to see whether or not it has a built-in wireless LAN※function. ※LAN : “Glossary” (See page 39)

• Before connecting the projector to the computer, be sure to check the following settings.

• Operation is not guaranteed for all wireless LAN cards and built-in wireless LAN adapters.

Check 1 Wireless LAN settings

• Is your wireless LAN switched on?

Check 2 Logon user’s settings

• Have you logged in as the [Admin (administrator)]?

Check 3 Computer’s settings

•

When security (firewall) software and utilities for network cards are installed, these may prevent connection of the projector.

Necessary environment for computers to be connected

Software Installation

The computer must meet the following requirements in order to use the supplied software.

OS: Mac OS X v10.4

Mac OS X v10.5※

CPU: 800 MHz PowerPC G4 or faster, or 1.8 GHz Intel Core processor or faster

RAM: 256 MB or more (512 MB or more recommended)

Empty hard disk capacity:

60 MB or more

Hardware conditions:

CD or DVD drive (for software installation and viewing the user’s manual)

An 802.11 b/g built-in wireless LAN adapter must be installed and running properly.

However, some 802.11 b/g wireless LAN may not allow a 802.11 g connection to projectors.

WebBrowser:

Safari 2.0 or later

System requirements

Operation is not guaranteed for all computers that meet the above

conditions.

※Only for MacBook and MacBook Pro computers with built-in Intel Core 2 Duo processor.

For the latest information, please see our Web site.

http://panasonic.co.jp/pavc/global/projector/

Set the provided CD-ROM into the CD/DVD-ROM drive.

Contents on Provided CD-ROM

• Quit all running programs. Otherwise, installation may not be possible.

• [Admin (administrator)] authority is required for installation.

This software is used to send screen images from a computer to the projector via a wireless LAN.

Set the provided CD-ROM into the CD/DVD-ROM drive of a computer.

Wireless Manager ME 4.5

Software Installation (cont.)

Double-click [WMmac4.5.dmg] in the CD/DVD-ROM drive.

[WMmac] appears on the desktop.

Double-click [Wireless Manager.pkg].

Installation begins.

Follow the instructions on the screen and install the software.

• When a window for inputting a [Name] and [Password] appears, input the [Admin (administrator)]’s name and password.

• Install Wireless Manager ME 4.5 in the [Applications] folder (./Applications).

The user’s manual (Index.pdf) is on the CD/DVD-ROM disc.

Double-click it to view it.

Connect

1Click the install target or [ ] in the Dock.

Detailed settings

Select the projector to connect from the computer.

• For details on how to connect, refer to page 15.

• Only the built-in adapter appears on the <Network Adapter Selection> window.

• You cannot connect this model to a computer via the wired LAN.

The following models are compatible with the wired LAN communication that can be used with this Software.

PT-F100NT, PT-FW100NT

When the <Network Adapter Selection> window appears

ヂSelect the adapter from the list and click [OK].

If the confirmation dialog box appears, click [Yes].

ッSet the icon and user name, and click [OK].

Easy Wireless Set Up

Altri manuali per PT-LB51NTE

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Panasonic Proiettore

Panasonic

Panasonic PT-LM2U Manuale utente

Panasonic

Panasonic PT-RZ470UW Manuale utente

Panasonic

Panasonic PT-EX12KU Manuale utente

Panasonic

Panasonic PT-LB51 Series Manuale utente

Panasonic

Panasonic PT-AX100U Manuale utente

Panasonic

Panasonic PT-FX400U Manuale utente

Panasonic

Panasonic PTL758U - LCD PROJECTOR Manuale utente

Panasonic

Panasonic PT-LB90NT Manuale utente

Panasonic

Panasonic PT-AE8000U Manuale utente

Panasonic

Panasonic PT-JX200GBE Manuale utente

Panasonic

Panasonic PT-LW375 Manuale utente

Panasonic

Panasonic PT-TW230EA Manuale utente

Panasonic

Panasonic PTL795U - LCD PROJECTION Manuale utente

Panasonic

Panasonic PTST10E - LCD PROJECTOR Manuale utente

Panasonic

Panasonic PTL711U - LCD PROJECTOR Manuale utente

Panasonic

Panasonic PT-DZ13KU Manuale utente

Panasonic

Panasonic PT-AX100 Manuale del sistema

Panasonic

Panasonic PT-LB10U - Mobile Projector XGA 2000 Lumens Manuale utente

Panasonic

Panasonic PT-DW7000 Manuale utente

Panasonic

Panasonic PTL557U - LCD PROJECTOR Manuale utente

Panasonic

Panasonic PT-LB30E Manuale utente

Panasonic

Panasonic PT-VW440U Istruzioni operative

Panasonic

Panasonic PT-AE4000E Manuale utente

Panasonic

Panasonic PTAE100U - LCD PROJECTOR Manuale utente

Manuali Proiettore popolari di altre marche

iEmmet

iEmmet MP-312 Manuale utente

Epson

Epson VS400 Manuale utente

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuale utente

Sony

Sony VPL-HW65ES Manuale di servizio

Toshiba

Toshiba TLP-791U Manuale utente

Philips

Philips LC1341 Guida di riferimento

NEC

NEC NP600S EDU Manuale utente

BenQ

BenQ SH753P Manuale utente

Eiki

Eiki EK-623U series Manuale utente

Epson

Epson PowerLite Pro Cinema 6020UB Manuale utente

Epson

Epson PowerLite Home Cinema 705HD Manuale utente

Christie

Christie LHD700 Manuale utente

Navitar

Navitar FX Manuale utente

InFocus

InFocus LitePro 560 Manuale utente

Sony

Sony SRX-R815P Manuale utente

Vivitar

Vivitar DP1500 X Manuale utente

Acer

Acer C20 Series Manuale utente

Asus

Asus ZenBeam Latte Manuale utente
