Panasonic CZ-RWS3 Manuale utente

Operating Instructions

Infrared Remote Controller

Model No. CZ-RWS3

Panasonic Corporation

1006 Kadoma, Kadoma City, Osaka, Japan

Installation Instructions Separately Attached.

English

Before operating the unit, read these operating instructions thoroughly and keep them for future

reference.

• Use this unit with the receiver that is separately sold.

TIMEROPERATION

STANDBY

Receiver

Infrared Remote Controller

2(EN)

Safety Precautions

Do not use this appliance in a potentially explosive

atmosphere.

In case of malfunction of this appliance, do not repair

by yourself. Contact the sales or service dealer for

repair and disposal.

In case of emergency, remove the power plug

from the socket or switch off the circuit breaker

or the means by which the system is isolated

from the mains power.

WARNING CAUTION

This symbol refers to a hazard

or unsafe practice which can

result in severe personal injury

or death.

This symbol refers to a hazard

or unsafe practice which can

result in personal injury or

product or property damage.

Matters to be observed Prohibited matters

WARNING

ENGLISH

(EN)

This appliance is intended to be used by expert or

trained users in shops, in light industry and on farms, or

for commercial use by lay persons.

This appliance is not intended for use by persons

(including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction

concerning use of the appliance by a person responsible

for their safety. Children should be supervised to ensure

that they do not play with the appliance.

This appliance can be used by children aged from

8 years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way

and understand the hazards involved. Children shall not

play with the appliance. Cleaning and user maintenance

shall not be made by children without supervision.

• Do not operate with wet hands.

• Do not wash with water.

• Do not allow infants and small children to prevent

them from accidentally swallowing the batteries.

CAUTION

4(EN)

●ReadtheOperatingInstructionscarefullyforsafeuse.This manual

describes the Operating Instructions of the infrared remote controller. Read

this manual as well as operating instructions supplied with indoor units and

outdoor units.

●Be sure to read the “Safety Precautions” (P.2, 3) before using.

●Keepthismanualwithoperatinginstructionssuppliedwithindoorunitsand

outdoor units in a safe place.

● Be sure to keep this manual in a place easily accessible by users. In the

case of user change, be sure to give this manual to the new user.

NOTICE

The English text is the original instructions.

Other languages are translation of the original instructions.

Operating Precautions

●Donotlocateinthefollowingtypesofplaces.

• Where there is moisture, oil, or vibration/In direct sunlight/Near heat sources/

Where condensation forms (These can cause malfunctions.)

• Wherethereisrapidstartuorescentlightingorinverterlightsnearthereceiver

(This can cause incorrect operation.)

●Donotcleanwithbenzeneorthinnersorwipewithchemicalcloths.(This

can cause discolouration or malfunction.)

• When the unit is very dirty, dampen a cloth in water or warm water, wring

thoroughly, and wipe.

ENGLISH

(EN)

Information for Users on Collection and Disposal of Old Equipment and

Used Batteries

These symbols on the products, packaging, and/or accompanying

documents mean that used electrical and electronic products and

batteries should not be mixed with general household waste.

For proper treatment, recovery and recycling of old products and used

batteries, please take them to applicable collection points, in accordance

with your national legislation and the Directives 2002/96/EC and

2006/66/EC.

By disposing of these products and batteries correctly, you will help to

save valuable resources and prevent any potential negative effects on

human health and the environment which could otherwise arise from

inappropriate waste handling.

For more information about collection and recycling of old products and

batteries, please contact your local municipality, your waste disposal

service or the point of sale where you purchased the items.

Penalties may be applicable for incorrect disposal of this waste, in

accordance with national legislation.

For business users in the European Union

If you wish to discard electrical and electronic equipment, please contact

your dealer or supplier for further information.

[Information on Disposal in other Countries outside the European

Union]

These symbols are only valid in the European Union. If you wish to

discard these items, please contact your local authorities or dealer and

ask for the correct method of disposal.

Note for the battery symbol (bottom two symbol examples):

This symbol might be used in combination with a chemical symbol. In

this case it complies with the requirement set by the Directive for the

chemical involved.

6(EN)

Contents

Safety Precautions ................................................................................2

Operating Precautions...........................................................................4

Supported Functions .............................................................................7

Names and Operations..........................................................................8

Installing Batteries ...............................................................................12

Setting the Current Time......................................................................14

Using the Remote Controller ...............................................................14

Paring Addresses ................................................................................16

Operation.............................................................................................18

Lock Individual Flap.............................................................................20

nanoe™ X Setting ...............................................................................21

ECONAVI Setting ................................................................................22

Ventilation Setting................................................................................23

Energy Saving Setting.........................................................................23

Temperature Automatic Return............................................................24

Timer Operation...................................................................................26

Operating Multiple In/Outdoor Units Simultaneously

(Group control)...............................................................................28

Miscellaneous Settings........................................................................28

Button Control......................................................................................30

Troubleshooting...................................................................................31

Specications ......................................................................................32

ENGLISH

(EN)

Supported Functions

Available functions vary depending on the model of the indoor unit and the

combination of the optional equipment.

Also functions may vary even between indoor units of the same type if their

capacities or manufactured years are different.

See the operating instructions of the indoor unit for the settable functions.

Some functions are not supported by the following receivers.

See the following table for the cases you have made an attempt to use the

unsupported function.

e.g. CZ-RWSU3 CZ-RWSU2N CZ-RWSC3 CZ-RWSD2

CZ-RWST3N CZ-RWSL2N CZ-RWSK2

Unsupported

function

Buzzer from the

receiver Result

Setting the fan speed

in 5 levels. Beeps

You can set fan speed to level 1, 3,

or 5.

(If you specify level 2, the fan speed

will be set to level 1)

(If you specify level 4, the fan speed

will be set to level 3)

ECONAVI setting/

nanoe™ X setting/

Energy saving setting

Beeps Setting is not applied.

Lockindividualap/

Temperature automatic

return

Does not beep Setting is not applied.

• It is possible to check whether the receivers support the functions above

with the buzzer sound that is produced when

ADR is pressed.

• Supported: 2 short beeps

• Unsupported: 1 short beep

8(EN)

Names and Operations

REMOTE CONTROLLER

ENGLISH

(EN)

1 remote controller can control a group of up to 8 indoor units.

(See page 28)

1. Operation Display

Displays the operation status.

(Thegureshowsallthe

statuses.)

2. Start/Stop button

Pressing this button once starts

and pressing again stops the

operation.

3. Fan speed button

Press to change the fan speed.

4. Flap button

Presstochangetheapdirection.

5. ECONAVI button

ECONAVI

Press to set ECONAVI.

6. nanoe™ X button

nanoeX

Press to set nanoe™ X.

7. Ventilation button

Use this when connected to an

aftermarket fan.

8. Clock button

Use this to set the clock.

9. Cover

Press at the top center and then

slide down.

10.Transmitter

11.Temperature setting buttons

raises the temperature

setting 1 °C at a time.

lowers the temperature

setting 1 °C at a time.

12.Mode select button

Press to switch the operation

mode.

13.Energy saving button

Press to enable or disable energy

saving.

14.Filter button

Presstoturnoffthelterlampon

the receiver.

15.Timer setting buttons

/ / / / /

Use for operating with a timer.

16.RC reset button

RESET

Use this button after changing the

batteries.

17.RC address button

ADR

Press to set addresses.

From this page, the names of

remote controller’s buttons will be

indicated with the above

illustrations.

E.g.: Start/Stop button 

10 (EN)

Names and Operations (Cont.)

Receiver

1543

CZ-RWRD3

CZ-RWSD2

CZ-RWSU2NCZ-RWRU3

CZ-RWRU3W

CZ-RWSU3

345

CZ-RWRC3

CZ-RWSC3

CZ-RWRL3

CZ-RWSL2N

TIMEROPERATION

STANDBY

Build-in receiver on indoor unit

(Wall mounted type /

4-Way Cassette 60 × 60 type)

1543

CZ-RWRT3

CZ-RWST3N

3 4 5

Operation Panel

Display

Altri manuali per CZ-RWS3

Indice

Altri manuali Panasonic Telecomando

Panasonic

Panasonic EUR7502XB0 - REMOTE GUIDE-SAHE200K Manuale utente

Panasonic

Panasonic EUR7702KE0 Manuale utente

Panasonic

Panasonic CZ-01RT11P Manuale utente

Panasonic

Panasonic AKHRP200 Manuale utente

Panasonic

Panasonic CZ-RWSU2 Manuale utente

Panasonic

Panasonic EUR511111 Manuale utente

Panasonic

Panasonic AK-HRP1015G Manuale utente

Panasonic

Panasonic CZ-RTC6 Manuale utente

Panasonic

Panasonic AK-HRP200G Manuale utente

Panasonic

Panasonic AW-RP150G Manuale utente

Panasonic

Panasonic CZ-RWS3 Manuale utente

Panasonic

Panasonic AK-HRP1015G Manuale utente

Panasonic

Panasonic CZ-RD52CP Manuale utente

Panasonic

Panasonic 060-2331 Manuale utente

Panasonic

Panasonic EUR7722X90 Manuale utente

Panasonic

Panasonic CZ-RTC5A Manuale utente

Panasonic

Panasonic KX-HNK102C Manuale utente

Panasonic

Panasonic AWCB400N - REMOTE OPERATION PANEL Manuale utente

Panasonic

Panasonic EUR511163 Manuale utente

Panasonic

Panasonic CZ-RWSU2N Manuale utente

Panasonic

Panasonic EUR7722KN0 Manuale utente

Panasonic

Panasonic WVCU650 - SYSTEM CONTROLLER ADDENDUM Manuale utente

Panasonic

Panasonic EUR501371 Manuale d'uso e manutenzione

Panasonic

Panasonic CZ-RTC3 Manuale utente

Manuali Telecomando popolari di altre marche

Bang & Olufsen

Bang & Olufsen Beo4 Manuale utente

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuale utente

Multiplex

Multiplex PROFI TX 9 Manuale utente

One Remote

One Remote RMB4 Manuale utente

FUTABA

FUTABA 9ZAP - PART2 Manuale utente

HR Matic

HR Matic HR MULTI 3 Manuale utente

Yamaha

Yamaha ACC-GNRST-30-20 Manuale utente

EisSound

EisSound KBSOUND Manuale utente

Marantz

Marantz RC101 Manuale utente

Conrad

Conrad FS20 TC6 Manuale utente

Anritsu

Anritsu MP1777A Manuale utente

Niles

Niles WVC100 Guida alla risoluzione dei problemi

RCA

RCA RCU1300 Manuale utente

Bang & Olufsen

Bang & Olufsen BEO6 Manuale utente

GE 94901 Manuale utente

Onbon

Onbon YQ1-75 Manuale utente

FUTABA

FUTABA R7108SB Istruzioni per l'installazione

Invacare

Invacare G91S Manuale utente
