Panasonic PI-DUA5MWA Manuale utente

Operating Instructions

English

Customer Care Number (Toll Free): 18004190373

E-mail: [email protected]

Information on hazardous constituents as specied in rule 16(1) in electrical

and electronic equipment.

Declaration of Conformity with the requirements of the E-waste

(Management) Amendment Rules 2022 with the rule 16(1) limits with

respect to lead, mercury, cadmium, hexavalent chromium, polybrominated,

biphenyls, polybrominated biphenyls, polybrominated diphenyl

ethers.

The content of hazardous substance with the exemption of the

applications listed in SCHEDULE II of the E-Waste (management)

Amendment Rules 2023.

1. Lead(Pb)- not over 0.1% by weight;

2. Cadmium(Cd)- not over 0.01% by weight;

3. Mercury(Hg)- not over 0.1% by weight;

4. Hexavalent chromium(Cr6+)- not over 0.1% by weight;

5. Polybrominated biphenyls(PBBs) - not over 0.1% by weight;

6. Polybrominated diphenyl ethers(PBDEs)- not over 0.1% by weight;

For the purpose of recycling to facilitate effective utilization of

Resources, please return this product to a nearby authorised

collection center, registered dismantler or recycler, or

Panasonic service center when disposing of this product.

Thank you for purchasing this Panasonic product.

Please read these instructions carefully before operating this

product and retain them for future reference.

The images shown in this manual are for illustrative purposes

only.

Dome IP Camera

Please see the Panasonic website for further information on collection

centers, etc. or call the customer care toll free number.

Website: https://www.panasonic.com/in/corporate/e-

waste-management.html

PI-DUA5MWA

Model No.:

Important Safeguards and Warnings

1. Please read these instructions carefully.

2. Please heed all warnings.

3. Please follow all instructions.

4. Do not use this apparatus near water.

5. Please clean only with dry cloth.

6. Do not block any ventilation openings, install in accordance with the

manufacturer’s instructions.

7. Do not install near any heat sources such as radiators, heat registers, stoves, or

other apparatus (including amplifiers) that produce heat.

8. Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other. A

grounding type plug has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If the provided plug does

not fit into your outlet, consult an electrician for replacement of the obsolete

outlet.

9. Protect the power cord from being walked on or pinched particularly

at plugs, convenience receptacles, and the point where they exit from the

apparatus.

10. Only use attachments/ accessories specified by the manufacturer.

11. Use with cart, stand, tripod, bracket, or table only as specified by the manufacturer

or sold with the apparatus. When a cart is used, use caution when moving the

cart/apparatus combination to avoid injury from tip-over.

12. Unplug this apparatus during lighting storms or when unused for long

periods of time.

13. Refer all servicing to qualified service personnel.

14. Do use a reliable and secure network connection to avoid interruptions in the

camera's feed.

15. Do ensure good Wi-Fi connectivity/ signal (2.4Ghz), in case camera is used in

Wi-Fi mode.

16. Don't tamper with the camera's internal components or modify its firmware

without proper knowledge or authorization.

Disclaimer

•

We strongly recommend you to set a difficult password immediately after the

first log in to ensure account security and don’t share it with unauthorized

personnel.

•

Password Characters: Password must contain at least 8 to 16 characters

comprising all three elements: alphabet, special character & digit.

•

The illustrations in this manual are for reference only and may vary

depending on the version or model. The screenshots in this manual may

have been customized to meet specific requirements and user preferences.

As a result, some of the examples and functions featured may differ from

those displayed on your screen / monitor.

•

We have put in our best efforts to verify the correctness and integrity of the

contents in this manual, but no statement, information / recommendation in

this manual shall constitute formal guarantee of any kind, expressed or

implied. We shall not be held responsible for any technical or typographical

errors in this manual.

•

Video and audio surveillance can be regulated by laws that vary from country

to country. Check the law in your local region before using this product for

surveillance purposes. We shall not be held responsible for any consequences

resulting from illegal operations of the device.

•

Use of this product, the manual and the subsequent result shall be entirely

the user's own responsibility. In no event shall Panasonic be liable for any

special, consequential, incidental, or indirect damages, including, among

others, damages for loss of business profits, business interruption, or loss of

data or documentation, or product malfunction or information leakage

caused by cyber-attack, hacking or virus in connection with the use of his

product.

•

The contents of this manual are subject to change without prior notice.

Regular updates can be added to the new version of this manual.

•

Due to uncertainties such as physical environment, discrepancy may exist

between the actual values and reference values provided in this manual. The

ultimate right to interpretation resides with our company.

Contents

Part I Product Introduction ...........................................................................1

Product Funcon .......................................................................................1

Recommended PC Specicaons..............................................................2

Accessories ................................................................................................3

Appearance................................................................................................4

Installaon Precauons.............................................................................5

Installaon Instrucons ............................................................................6

Part II Local Network Access .........................................................................7

Powering and Networking ........................................................................7

2. Active X Installation Procedure ................................................................8

Install Acve-x ...........................................................................................8

3. Camera Configuration & Setup ...............................................................10

4. About the Live Page & Icons ...................................................................13

5. About Playback........................................................................................14

6. About Config............................................................................................15

Local Cong..............................................................................................15

Encode .....................................................................................................16

Network ...................................................................................................25

Record ......................................................................................................29

Alarm

........................................................................................................30

System Conguraon ..............................................................................36

Security ....................................................................................................39

System Tool..............................................................................................40

System Informaon .................................................................................43

Do’s & Don’ts ...............................................................................................45

Troubleshooting Points ...............................................................................46

TECHNICAL SPECIFICATIONS .......................................................................48

Part I Product Introduction

Product Function

1. For Indoor & Outdoor use.

2. PoE enabled.

3. Encode codec (H.264, H.265 & H.265+)

4. Full HD Video Quality (2880x1620) 5M.

5. Built-in microphone.

6. Built-in Wi-Fi. (2.4Ghz)

7. ONVIF Compliance.

8. Dual-Streaming.

9. Supports IR.

10. Supports Privacy masking. (4 Zone)

11. This IP camera can display videos in different resolutions and qualities.

12. When an event occurs, the related text notification is sent to the email

address registered by a user.

13. Web Browser-based Monitoring using the Internet web browser to display the

image in a local network environment.

14. User can access this IP camera on mobile application & desktop application

(VMS).

15. Tampering Detection - Detects tempering attempts on video monitoring.

16. Motion Detection - Detects motion from the camera’s video input.

17. Video Blind Detection –Detect if camera lens is covered/blocked more than

60%.

18. Abnormality Detection –Detects abnormality alarms like IP Address Conflict,

Network disconnect etc.

19. Sound Detection –Detects abnormal sound from the camera video input.

20. Human Detection –Detects human movement from the camera video input.

21. Analytic –Detect area intrusion & line crossing event in the defined region.

Recommended PC Specifications

1. CPU: Intel Core i5 2.8 GHz or higher

2. RAM: 4GB or higher

3. Supported OS: Windows 10 & above.

4. Supported Browser: Microsoft Internet Explorer. (Fully supported for all

functionalities)

5. Mozilla Firefox & Google Chrome supported with limited functionality.

6. Apple Safari is supported with limited functionality.

Accessories

RJ45 Cap with sealing Ring

Screw & Wall Plug (x3)

Mounng Scker

Warranty Card

Quick Installaon Guide

Antenna
