Panasonic DBS 576 Section 300 Manuale utente
Section 770
Voice Recognition
Phone
User Guide
Issued 3/23/98
543X02401
Technical Manual
®
3DQDVRQLF
3DQDVRQLF7HOHSKRQH6\VWHPV
www.voicesonic.com
Phone 877-289-2829
The contents of this manual are subject to change without notice and do not constitute a
commitment on the part of Panasonic Telecommunication Systems Company (PTSC). Every effort
has been made to ensure the accuracy of this document. However, due to ongoing product
improvements and revisions, Panasonic cannot guarantee the accuracy of printed material after the
date of publication, nor can it accept responsibility for errors or omissions. Panasonic will update
and revise this document as needed.
The software and hardware described in this document may be used or copied only in accordance
with the terms of the license pertaining to the said software or hardware.
© 1998 by Panasonic Telecommunication Systems Company (PTSC)
All rights reserved.
576-10-770 DBS 576 - Issued 3/23/98 3
Contents
Introduction ...................................................................5
Names and Functions of Parts ....................................6
Chapter 1.Making an Outside Call (or an Internal Call) .8
Chapter 2.Adding a Phonebook Entry.......................10
Chapter 3.Modifying a Phonebook Entry..................14
Modifying Names ......................................................................................................................14
Modifying a Telephone Number................................................................................................17
Chapter 4.Deleting a Phonebook Entry.....................21
Deleting Individual Phonebook Entries.....................................................................................21
Deleting All Phonebook Entries ................................................................................................24
Chapter 5.Tuning the Commands to Your Voice......26
Chapter 6.Resetting the System ................................30
4DBS 576 - Issued 3/23/98 576-10-770
576-10-770 DBS 576 - Issued 3/23/98 5
Introduction
The incorporation of a voice recognition unit (VB-44101) in a soft-key
telephone (VB-44224) allows you to choose between voice-activated dialing
or normal keying in. You can simply speak names stored in the Phonebook to
initiate a call to that destination.
This manual describes how to use voice-activated dialing and how to record
names, etc. See the Operation Instruction (Section 700) for details of normal
key operations.
This manual consists of the following chapters:
•We recommend storing your spoken commands in your own voice in
the system to improve the performance of voice recognition.
Chapter Content Reference page
1. Making outside call
(or Internal call)
Describes how to make calls to exchange (or in-
ternal) numbers by speaking names recorded in
the Phonebook
8
2. Adding a Phonebook
Entry
Describes how to record names and phone num-
bers in the Phonebook 10
3. Modifying a Phone-
book Entry
Describes how to change names and phone num-
bers recorded in the Phonebook 14
4. Deleting a Phonebook
Entry
Describes how to delete names and phone num-
bers from the Phonebook 21
5. Tuning the commands
to Your Voice
Describes how you, as user, store your spoken
commands in the system for use as a reference. 26
6. Resetting The System Describes how to reset the system to its state
when shipped (The original non-specific "user"
voice is restored and the contents of the Phone-
book deleted.)
30
CAUTION:
•If the system cannot recognize your spoken commands, operate by
keys. There is no key equipped on the telephone corresponding to
"Repeat" command.
•Your spoken command can be recognized only during Large LED
(Message LED) lights Red.
•When a spoken command is not recognized, an error tone is gener-
ated. At this point, make sure your spoken command is valid and
try again.
•Once entering the voice recognition made, to turn to the OFF-
HOOK Monitor mode is not available. To use OFF-HOOK Moni-
tor mode, lift the handset and press ON/OFF Key, then press
START Key.
6DBS 576 - Issued 3/23/98 576-10-770
Names and Functions of Parts
1) Handset
The receiver for speaking into.
2) Cancel Key (Soft Key [MODE])
Cancels an operation and returns execution to the TOP MENU.
3) Soft Key [END]
Press if, during operation, the following voiced commands are not
recognized.
(Number, System, Call)
4) Soft Key [EXEC 1]
Press if, during operation, the following voiced commands are not
recognized.
(Yes, Complete, Change, List, Name, Delete All, Train)
5) Soft Key [EXEC 2]
Press if, during operation, the following voiced commands are not
recognized.
(Go Back, No, Program, Add, Back Space, Delete, Reset)
6) START/END Key (FF 12 Key)
Press to start and end voice operations.
This operation is available only for Handset communication.
1. Handset
6. START/END Key
7. REDIAL Key
8. Telephone number button
9. VOLUME Key
4. Soft Key [EXEC 1]
2. (Soft Key [Mode])
3. Soft Key [END]
5. Soft Key [EXEC 2]
TOP MENU
READY CALL
PROGRAM CHANGE
Section 770 Voice Recognition Telephone
576-10-770 DBS 576 - Issued 3/23/98 7
Note 1: Even if some feature access code is assigned on FF12 Key, (there is
no error tone when storing some feature on it.) this key can work as
START/END Key only, when the Voice Recognition Adapter is
attached on the phone.
2: "Initializing •••••" is displayed and FF12 Key blinks Green when
initializing the system. During this period, to enter the voice
recognition mode is not available even if the FF12 Key is pressed.
3: After entering the Voice Recognition mode by pressing FF12 Key,
the LED of other FF keys go OFF even if the COs are in use or
some features registered on are activated.
Once getting off this mode, LEDs return to the original status.
7) REDIAL Key
Use this key to insert a pause when recording a phone number.
8) Telephone number button
Use these buttons for entering telephone numbers when recording and
modifying entries.
9) VOLUME Key
The volume can be adjusted in 5 steps. Press the button to increase the
volume, or the button to decrease the volume. When you replace the
handset, the volume is reset to the medium value.
Page 8 DBS 576 - Issued 3/23/98 576-10-770
Chapter 1. Making an Outside Call
(or an Internal Call)
You can call a number simply by speaking a name stored in the Phonebook.
This Chapter describes the procedure.
Notes: •The name and number must be stored in the Phonebook. (See
Chapter 2, "Making a Phonebook Entry" on page 10.)
1. Lift the handset and listen for the dial tone.
2. Press the START/END Key (FF12 Key)
The dial tone stops and Voice Guidance asks "Call Who?"
Note: If no names or telephone numbers have been stored in the
Phonebook, the TOP MENU is displayed. When you say "call" at
this point, "Phonebook Empty" will be heard. This is your cue to
store names and telephone numbers in the Phonebook. (See page
10.)
3. After confirming the Large LED (Message LED) lights Red,
speak the name of the person you wish to call.
The system searches the Phonebook for the name closest to the
one you have spoken, and Voice Guidance then asks "mm"
Right?" to confirm the selection (mm). The telephone number is
displayed on the 1st display.
Note: Speak the name using the same voice you used to store the
name in the Phonebook. Using a different tone of voice may result
in the name not being retrieved.
Example:To call "Panasonic"
Say "Panasonic."ÕVoice Guidance responds with the
question '"Panasonic" Right?'
Note: Your voice will not be recognized if you call the name before
the Large LED lights RED.
4. If the name spoken by Voice Guidance is correct, say "Yes." If
not, say "No."
•"Yes"
The Splash tone sounds and the telephone number is dialed.
Start talking when the phone is answered.
NAME TO CALL ?
GO BACK
(FF12)
TOP MENU
READY CALL
PROGRAM CHANGE
01045939
NO YES
01045939
Chapter 1. Making an Outside Call (or an Internal Call) Section 770 Voice Recognition Telephone
576-10-770 DBS 576 - Issued 3/23/98 Page 9
•"No"
The search continues to the next closest name in the Phonebook.
Voice Guidance then asks "" Right?" to confirm the
selection (). The telephone number is displayed on the 1st
display. If this is not the desired number, say "No" to repeat the
search one more time. If there is no registration close to your
pronunciation, an error tone will be issued. If, on the 3rd
attempt, the correct number is not found, operation returns to
"Call Who?". One possibility is that you are saying the name
using a different tone or in a different manner from that
originally used to record it in the Phonebook. Try saying the
name again.
Notes: •If the search fails to find a candidate, Voice Guidance says
"No other choices." You may have spoken the name using
a different tone or a different manner from that originally
used to record it in the Phonebook, or a name that is not in
the Phonebook. Replace the handset to cancel the call,
check the contents of the Phonebook, then try to place the
call again. At most three candidates are presented. They
are the names in the Phonebook that are the closest the
names you spoke. If ambient sounds, etc., result in the
spoken words sounding totally different from any
candidates in the Phonebook, the search is cancelled
before the 3rd try.
•If you do not hear any Voice Guidance after saying "Yes"
(or "No"), press the Soft Key [EXEC].
5. On completion of the call, replace the handset.
Notes: •If you cannot catch the message spoken by Voice Guidance, say
"Repeat" to repeat the message.
•To abort the call at any point before saying "Yes," simply replace
the handset.
•You can say "Cancel" (or press the Cancel Key) at any point to
display the TOP MENU, allowing you to store new entries or edit or
delete existing entries. This function can be useful if you want to
check the contents of the Phonebook while making a call, or add (or
delete) an entry after completing a call, etc.
•If you do not speak or press any keys for three minutes, the Voice
Recognition mode is ended.
10:00 SAT JAN 10
-EXT100 100
Section 770 Voice Recognition Telephone Chapter 2. Adding a Phonebook Entry
10 DBS 576 - Issued 3/23/98 576-10-770
Chapter 2. Adding a Phonebook Entry
This Chapter describes how to record names and telephone numbers in the
Phonebook.
Store your voice in a quiet surroundings as much as possible.
You can store entries for up to 100 seconds in the Phonebook. (For example,
if each name takes 2 seconds to speak, you can store 50 entries. The
maximum recording time for each entry is 2.5 seconds.)
Note: If you do not hear Voice Guidance in response to saying "Go Back",
"Program," "Add," "Yes," "Back Space," or "Complete," press the Soft Key
[EXEC] next to the characters on the screen.
1. Lift the handset and listen for the dial tone.
2. After confirming the Large LED (Message LED) lights RED,
press the START/END (FF12 Key).
The dial tone stops and Voice Guidance asks "Call Who?"
Note: If no names or telephone numbers have been stored in the
Phonebook, the TOP MENU is displayed.
3. Say "Go Back."
The TOP MENU is displayed and Voice Guidance responds
with "Ready."
4. Say "Program."
Voice Guidance responds with "Which mode?"
5. Say "Add."
Voice Guidance responds with "Name please."
•If the Phonebook memory is full
The following message is displayed on the screen and Voice
Guidance says "Phonebook Full sorry." Replace the handset and
cancel recording. If you want to add another entry to the
Phonebook, you must first delete any unwanted entries. (See
Chapter 4, "Deleting Phonebook Entry" (page 21).)
6. Say the name of the person or company, etc., for which you are
making an entry in the Phonebook.
NAME TO CALL ?
GO BACK
(FF12)
READY CALL
PROGRAM CHANGE
PROGRAM SYSTEM
ADD DELETE ALL
NAME TO ADD ? #1
GO BACK
PHONEBOOK FULL
Altri manuali per DBS 576 Section 300
11
Questo manuale è adatto per i seguenti modelli
3
Indice
Altri manuali Panasonic Telefono
Panasonic
Panasonic NS700 Manuale di installazione
Panasonic
Panasonic KX-NS1000 Manuale del proprietario
Panasonic
Panasonic KX-TG6521NZ Manuale utente
Panasonic
Panasonic KX-T7636 Manuale utente
Panasonic
Panasonic KX-TGD590C Manuale utente
Panasonic
Panasonic KX-TGFA30 Manuale utente
Panasonic
Panasonic KX-TC1201BXB Manuale utente
Panasonic
Panasonic KX-UT113 Manuale utente
Panasonic
Panasonic KX-TD500 Manuale utente
Panasonic
Panasonic PanaVoice Courier Manuale utente
Panasonic
Panasonic EASA-PHONE KX-T2365A Manuale utente
Panasonic
Panasonic T7436 - KX - Corded Phone Manuale utente
Panasonic
Panasonic KX-TC1713B Manuale utente
Panasonic
Panasonic KX-TA1232 Scheda tecnica
Panasonic
Panasonic KX-TS600CB Manuale utente
Panasonic
Panasonic KX-TVP150 Manuale utente
Panasonic
Panasonic KX-TC1503B - 900 MHz Digital Cordless Phone Manuale utente
Panasonic
Panasonic KX-TG2257S - 2.4 GHz Digital Cordless... Manuale utente
Panasonic
Panasonic KX-TG1061M - Cordless Phone Base Station Manuale utente
Panasonic
Panasonic KX-TCA151AXM Manuale utente
