Pantech Link II Manuale utente

UserGuide

Some of the contents in this manual may differ from your phone depending on the software

of the phone. Actual color may vary.

Your phone is designed to make it easy for you to access a wide variety of content. For your

protection, we want you to be aware that some applications that you enable may involve

the location of your phone being shared. For applications available through AT&T, we

offer privacy controls that let you decide how an application may use the location of your

phone and other phones on your account. However, the AT&T privacy tools do not apply

to applications available outside of AT&T. Please review the terms and conditions and the

associated privacy policy for each location-based service to learn how location information

will be used and protected. In addition, your AT&T phone may be used to access the internet

andtodownload,and/orpurchasegoods,applications,andservicesfromAT&Torelsewhere

from third parties. AT&T provides tools for you to control access to the Internet and certain

Internet content. These controls may not be available for certain devices which bypass AT&T

controls.

reserved. AT&T, the AT&T logo and all other AT&T marks contained herein are trademarks

of AT&T Intellectual Property and/or AT&T afﬁliated companies. All other marks contained

herein are the property of their respective owners.

Specifications

Design

QWERTY bar

Displays

• 262kcolorsTFTLCDwith2.4”display

• 320*240resolution

• 5linesfortextinbasicmodewith16-pointfont

• Twosoftkeysandfour-wayscrollandOKkey

Melodies

.mp3,.midi,.iMelody,.wav

Camera

Integrated2MCMOSCamera

• Resolutionupto1600x1200(1,920,000pixels)

• Mpeg4Videorecording/playingupto15f/s(QVGAsize)

• Self-timerfunction(Off,3seconds,5secondsor10seconds)

• Photoalbumandvideoalbum

Dimensions&Weight

• Weight:3.3oz.(withstandardbattery)

• Dimensions:115.9mmx61mmx9.95mm

PowerManagement (Performance)

BatteryType Capacity Standby Time TalkTime

Standard

Lithium-Ion(Li-ion) 1000 mAh Minimum

10days(250hrs)

Minimum

3hrs

OperatingFrequency

• GSM/GPRS/EDGE850/900/1800/1900MHz,UMTS/HSDPA850/1900MHznetworksinNorth

America, South America, Europe, Africa, and Asia-Paciﬁc where these networks are supported.

• Automaticbandswitching.

Receiver

Display

Left/Right softkey

Perform the functions

shown at the bottom

line of the display.

Clearkey

Return to previous screen

or delete characters in

textmode.

Poweron&off/ Menuexit

key/ Endkey

Turn phone on/off, end

calls,exitmenus.

Deletekey

Press to delete a number

or letter.

Enterkey

Press to move to the

nextrow.

Spacekey

Press to enter a space.

Navigation

Up:WriteNewSMS

Down:Contacts

Left:Mobile Email

Right:YPmobile

Center:OK/Web

Speaker phone key

Sendkey

CAPS/Shiftkey

To type a single uppercase

letter, press this key then

a letter.

Functionkey

To enter a number or

a symbol, press the

function key, and press the

corresponding key.

Phoneoverview

Leftsidekey

Volumeupanddown

Chargerslot/Earmic

Camera

Camerakey

Internalantennaarea

Speaker

note: Holding the device by the internal antenna area might affect the quality of all calls.

Menuoverview

Messaging MobileEmail YPmobile

Web

Home

Bookmarks

Feed

Enter Address

History

Manage

AddressBook

Contacts

Groups

Favorites

LocalSearch

Settings

FixedDialNumbers

MyPhoneNumber

ServiceNumbers

AppCenter

AppManager

AT&T GPS

AT&TNavigator

AllSportGPS

Maps

AT&T Family Map

Tools

Recent Calls

Camera

VideoCamera

Media Player

Alarm Clock

Calendar

Notepad

VoiceMemo

World Time

Calculator

Tip Calculator

Converter

Stopwatch

Timer

MyStuff

App Manager

Games&Apps

Audio

Music


Video

Tools

my AT&T

CityID

ApplicationData

OtherFiles

Memory

AT&T Music

Music Player

Shop Music

AT&T Radio

Settings

Proﬁles

Display

nCall

Phone

Connectivity

SSecurity

nAT&T Software

Update

Reset

TTY

Phone Information

SSIM dependent NNetworkdependent

Quick&Easy

Keys Functions

<> Performs the functions shown at the bottom line of the display.

Scrolls through the menu options in Menu mode. In standby mode,

Left:AccessMobileEmailmenu

Right:AccessYPmobile menu

Up:AccessNew Message menu

Down:AccessContacts menu

WorksinWordsearchmodeifpressedinthePredictivetextinputmode.

Selects a menu function or store user-input information, such as names. Also

uses this key for conﬁrmation.

LaunchestheWeb directly if pressed in standby mode.

NTurns on the speaker mode.

CDeletescharactersfromthedisplay,orreturntopreviousmenu.

SSends or receives a call. Shows the recent call list in standby mode.

ECompletes the current call. Turns on/off the phone if pressed and held.

Cancels user input and return to main screen while in Menu mode.

1Quickly connects to the voice mail server if pressed and held in standby mode.

0~9Entersnumbers,lettersorspecialcharacters.Goestothedialscreenifpressed

in standby mode.

BEntersorexitsfromvibratemodeifpressedandheld.

qEntersaninternationaldialingprexifpressedinstandbymode.
