Pantech Pursuit II Manuale utente

User Guide

Some of the contents in this manual may differ from your phone depending on the software of the phone. Actual color may

vary.

Your phone is designed to make it easy for you to access a wide variety of content. For your protection, we want you to

be aware that some applications that you enable may involve the location of your phone being shared. For applications

available through AT&T, we offer privacy controls that let you decide how an application may use the location of your phone

and other phones on your account. However, the AT&T privacy tools do not apply to applications available outside of AT&T.

Please review the terms and conditions and the associated privacy policy for each location-based service to learn how

location information will be used and protected. In addition, your AT&T phone may be used to access the internet and to

download, and/or purchase goods, applications, and services from AT&T or elsewhere from third parties. AT&T provides

tools for you to control access to the Internet and certain Internet content. These controls may not be available for certain

devices which bypass AT&T controls.

other AT&T marks contained herein are trademarks of AT&T Intellectual Property and/or AT&T affiliated companies. All other

marks contained herein are the property of their respective owners.

Specifications

Design

Touch QWERTY Slider

Displays

• 260k colors TFT with 2.8” display

• 240*320 (QVGA) pixels in resolution

Melodies

MP3, AAC, AAC+, eAAC+ and WMA.

Camera

Integrated 2M CMOS Camera

• Resolution up to 1600 x 1200 (1,920,000 pixels)

• Mpeg4 Video recording/playing up to 15f/s(QVGA size)

• Self-timer function (Off, 3, 5 or 10 seconds)

• Picture album and video album

Dimensions & Weight

• Weight: 127g/4.48oz. (with standard battery)

• Dimensions: 101 X 61 X 15mm

3.98” X 2.40” X 0.59”

Power Management (Performance)

Battery Type Capacity Standby

Time

Talk Time

Standard

Lithium-Ion

(Li-ion)

1000 mAh Up to 250

hours

Up to 3

hours

Operating Frequency

• GSM/GPRS/EDGE 850/900/1800/1900 MHz, UMTS/

HSDPA 850/1900 MHz networks in North America,

South America, Europe, Africa, and Asia-Pacific where

these networks are supported.

• Automatic band switching.

Phone overview

Touch mode view

Camera

Volume key

Adjust the volume

Charging /

Data jack

Hold Key

Lock the touch

screen

Camera Key

Go to camera

mode

Speaker

Internal antenna

area

Earpiece

Back key

Go back to

the previous

Proximity

sensor

Microphone

Send key

Make or

answer a

call

Power/End key

Turn the phone

on/off.

End a call or

exit the current

note: If you use metal accessories (stickers) on the phone or hold

the device by the internal antenna area while exchanging data or

talking on the phone, sound quality may be affected.

Correct Incorrect

Keys Functions

Go back to the previous menu.

Access Recent Calls or dial the last

number if pressed twice.

End the current call. Turn on/off the

phone if pressed and held.

Cancel user input and return to main

screen while in Menu mode.

Lock the touch screen.

Take pictures and record movies.

Adjust the earpiece volume while making

a call.

Adjust ringtone volume, and control

vibrate or standby mode.

Mute the ringtone of an incoming call.

QWERTY mode view

CAPS key

Enter capital letters

Function key

Enter numbers or symbols

Vibrate key

Delete key

Delete a character/symbol

Enter key

Move to the next row

Symbol key

Enter a special symbol

Space key

Insert a space

note: To use the QWERTY keypad, slide the screen up.

Your phone has a QWERTY keypad which provides a

superior typing experience on a small handheld device

for easy and comfortable texting. You can use all of the

phone functions with the QWERTY keypad.

Keys Functions

Press to change Abc ABC abc modes on

the text editing screen b c d (first

letter caps/all caps/lowercase).

To enter symbols and numbers

continually, press twice 'Fn' until _ is

displayed.

^Press to enter a space in text input mode.

\Move to the next row in text input mode.

]Delete a character to the left of the text

cursor in the text editing screen.

ZPress to enter a special character that is

not on the keypad.

iQuickly connect to the voice mail server if

pressed and held while in standby mode.

Keys Functions

j~k

Enter numbers, letters or special

characters.

Go to the dial screen if pressed in standby

mode.

lActivate or deactivate vibrate mode if

pressed and held in standby mode.

mEnter an international dialing prefix if

pressed in standby mode.

Menu overview

Address Book

Contacts

Groups

Favorites

My Settings

Fixed Dial Numbers

My Phone Number

Service Numbers

RKDDADFGAFGA

ADFDFHDGJKLK;’KJHGFDSFSDSFG

FHJGHKJFHSSERYTUTYJFGHKKDFY

RSYGHJDGHJFGHJDGJDGHDFGJHG

SDFHGJFGJHDGF

RSY

GJFG

Messages

Create Message

Delete

Templates

Voice mail

Settings

Memory

IM My AT&T

S SIM dependent N Network dependent

App Center App Manager AT&T GPS

AT&T Navigator

AT&T FamilyMap

Web

Home

Bookmarks

Feed

Enter Address

History

Manage

YPmobile Mobile Email Facebook AT&T Social Net
