Paradox Crimewatch TM50 Manuale utente
Paradox Alarm
EVO192 - TM50/TM70
Touchscreen Keypad
User Guide
Crimewatch Security © 2022 - 1300 928 241
> Support IPC UPnP, 4PoE
ports
> Support IPC UPnP, 4PoE
ports
Initial Setup
Step 1: Initial Setup
• Locate the Alarm Panel (this will be located in a Cupboard or WIR).
• Open the panel and connect the battery, there will be a black and red lead loose, connect the black
cable to black terminal on battery and red cable to red terminal.
• Remove any booklets left in the panel and close door.
• Turn on the power point beside the alarm panel and proceed to the Keypad within your home.
Step 2: Setting the Date & Time
• Press the [Menu]button.
• Press the [System Settings]button.
• Press the [Time & Date]button.
• Enter the Master Pin Code (Default 1234)
• Press the Time & Date [>]button.
• Enter the time as HH:MM.
• Press the [Save] button.
• Press the Date [>]button.
• Enter the month.
• Enter the day.
• Enter the year.
• Press the [Save] button.
• Press the [Home] button.
Step 3: Changing the Master Pin Code
• Press the [Menu]button.
• Press the [User Codes]button.
• Enter the Master Pin Code (Default 1234)
• Press the [Edit]button for User 1.
• Press the Code [>]button.
• Enter your new 4 digit PIN Code.
• Press the [Save] button.
• Confirm your new 4 digit PIN Code.
• Press the [Save] button.
• Press the [Home] button.
> Support IPC UPnP, 4PoE
ports
Paradox Alarm EVO192 - TM50/TM70 Keypad User Guide
Adding additional users
• Press the [Menu]button.
• Press the [User Codes]button.
• Enter the Master Pin Code
• Press the [Add]button for selected user.
• Enter User Name or press [Skip].
• Enter their new 4 digit PIN Code.
• Press the [Next] button.
• Confirm their new 4 digit PIN Code.
• Press the [Next] button.
• Option to learn a remote keyfob in, press button on
remote or press [Skip].
• Press the [Skip] button for Access Control
• Press the [Done] button.
• Press the [Home] button.
Deleting Users
• Press the [Menu]button.
• Press the [User Codes]button.
• Enter the Master Pin Code
• Press the [Delete]button for selected user.
• Confirm your request.
• Press the [Home] button.
Arming the system
• Press the [Area 1]button.
• Enter your 4 digit PIN Code.
• Press the [Arm] button.
• Exit delay should start counting down
Disarming the system
• Press the [Area 1]button.
• Enter your 4 digit PIN Code.
Bypassing Zones
• Press the [Menu]button.
• Press the [Security Functions]button.
• Press the [Bypass Zones]button.
• Enter your 4 digit PIN Code.
• Select Zone/s to Bypass.
• Press the [Home] button.
• Arm the Alarm System.
> Support IPC UPnP, 4PoE
ports
Paradox Alarm EVO192 - TM50/TM70 Keypad User Guide
*** Once the Alarm System is disarmed, the Bypass will be cleared and must be entered again if required.
Bypass clears on each disarm.
> Support IPC UPnP, 4PoE
ports
3
Paradox Alarm EVO192 - TM50/TM70 Keypad User Guide
[1] Wireless Zone Low Battery
The batteries for one of the system’s wireless devices needs to be replaced. (check to replace the
battery on the wireless sensor/remote)
[2] Power Trouble
The control panel has/is experiencing power trouble.
(check that the power supply beside alarm panel is plugged in. This error will also arise when power is
lost at the premises, but will clear upon restoral of power)
[3] Bell Trouble
There is a bell/siren disconnect on the control panel.
(Check to see if your external strobe and siren hasn’t been tampered with)
[4] Communication Trouble
An IP Module or GSM can no longer communicate with the App or monitoring station. ( If home is
monitored, call your monitoring provider to ensure communication has been restored. If you use an
App, reboot modem to re-establish internet connection and ensure your home internet is working)
[5] Tamper/Zone Wiring Failure
A wiring problem is occurring on one or more devices.
[6]Module Tamper Trouble
A device’s anti-tamper switch has been triggered.
[7]Fire Loop Trouble
One of the zones is in fire loop trouble.
[8]Timer Loss
Your alarm system’s clock must be reprogrammed.
(follow step 2 on page 2 to reset time and date)
[9]Wireless Zone Supervision Loss
One or more wireless zones are no longer communicating with the system.
[0]Module Supervision Loss
One or more modules are no longer communicating with the system.
*** To correctly reboot the Alarm Panel, turn power off at the power point, disconnect one of
the battery leads inside the Alarm Panel. After 5 minutes reverse the process; reconnect the
battery terminal and then turn on the power at the power point.
Fault Finding
Trouble Display
