Paradox Alarm
SP5500 & SP6000
K10V LED Keypad
User Guide
> Support IPC UPnP, 4PoE
ports
> Support IPC UPnP, 4PoE
ports
Crimewatch Security © 2021 - 1300 928 241
> Support IPC UPnP, 4PoE
ports
Initial Setup
Step 1: Initial Setup
• Locate the Alarm Panel (this will be located in a Cupboard or WIR).
• Open the panel and connect the battery, there will be a black and red lead loose, connect the black
cable to black terminal on battery and red cable to red terminal.
• Remove any booklets left in the panel and close door.
• Turn on the power point beside the alarm panel and proceed to the Keypad within your home.
• On the keypad the [TBL] button should now be illuminated RED.
Paradox Alarm K10V LED Keypad User Guide
1
Step 2: Setting the Date & Time
• Press the [TBL]button. ( [TBL]will flash)
• Press the number [8]button. ( [ARM] & [TBL] will flash in unison)
• Enter the time as HH:MM. (If HH is more than 13, skip next step)
• Press 1 for 24 hour clock. ( [SLEEP]& [TBL] will flash in unison)
• Enter the year as YYYY. ( [Stay] & [TBL] will flash in unison)
• Enter the month as MM. ( [OFF] & [TBL] will flash in unison)
• Enter the day as DD. ( [TBL] will flash)
• Press the [CLEAR] button to exit. ( [TBL] will stop flashing)
Step 3: Changing the Master Pin Code
• Press the [PWR] then 1234. ( [PWR] & [1]will flash in unison)
• Press 01. ( [ARM] will flash)
• Enter your new 4 digit PIN. ( [SLEEP] will flash)
• Re-Enter 4 digit PIN. ( [STAY] will flash)
• Press the [ENTER] button. ( [PWR]and [2]will flash in unison)
• Press the [CLEAR] button to exit.
Step 4: Arming & Disarming of your system
• Leaving home – Enter your 4 digit PIN Code to arm alarm.
• Returning home – Enter your 4 digit PIN code to disarm alarm.
Step 5: Adding additional users
• Press the [PWR]then your MASTER CODE. ( [PWR] & [1]will flash in unison)
• Select a user by entering a 2-digit user number (02 to 32).( [ARM] will flash)
• Enter your new 4 digit PIN. ( [SLEEP] will flash)
• Re-Enter 4 digit PIN. ( [STAY] will flash)
• Press the [ENTER] button. ( [PWR]and a number will flash in unison)
• Press the [CLEAR] button to exit.
> Support IPC UPnP, 4PoE
ports
Paradox Alarm K10V LED Keypad User Guide
2
Bypass Programming
Bypassing a zone allows you to ignore (deactivate) specified zones
the next time the system is armed.
• Press the [BYP] key.
• Enter your 4 digit PIN Code
• Enter the Zone you wish to bypass. (2-Digit Zone number)
• Press [Enter] to save and exit.
• Arm the Alarm System.
*** Once the Alarm System is disarmed, the Bypass will be
cleared and must be entered again if required. Bypass clears
on each disarm.
Bypass Recall Feature
After disarming the system, bypass entries are erased.
The Bypass Recall feature reinstates the previous bypass entries
saved in memory. This eliminates the need to manually re-program
the bypass entries every time you arm your system.
• Press the [BYP] key.
• Enter your 4 digit PIN Code
• Press the [BYP] key.
• Press Enter to save and exit.
• Arm the Alarm System.
Alarm Display
If an alarm has occurred on a zone, the respective zone key will
flash, the [MEM] key will light up, and the zones will be stored in
memory.
• Press the [MEM] key. ( Triggered Zones will illuminate)
• Press the [CLEAR] key to exit.
*** The alarm memory will be erased when the next alarm
occurs and after a valid code is entered or upon full-arming
the system.
Additional Features
Deleting a User
• Press the [PWR] key.
• Enter your 4 digit MASTER PIN Code
• Select a user by entering a 2-digit user number (02 to 32). Press and hold the [SLEEP] key until
you hear the confirmation beep
• Press [CLEAR] to exit.
> Support IPC UPnP, 4PoE
ports
Paradox Alarm K10V LED Keypad User Guide
3
[PWR] (Flashing)
This error means that you need to replace the battery located in the alarm panel box.
[1] Wireless Zone Low Battery
The batteries for one of the system’s wireless devices needs to be replaced. (check to replace the
battery on the wireless sensor/remote)
[2] Power Trouble
The control panel has/is experiencing power trouble.
(check that the power supply beside alarm panel is plugged in. This error will also arise when power is
lost at the premises, but will clear upon restoral of power)
[3] Bell Trouble
There is a bell/siren disconnect on the control panel.
(Check to see if your external strobe and siren hasn’t been tampered with)
[4] Communication Trouble
An IP Module or GSM can no longer communicate with the App or monitoring station. ( If home is
monitored, call your monitoring provider to ensure communication has been restored. If you use an
App, reboot modem to re-establish internet connection and ensure your home internet is working)
[5] Tamper/Zone Wiring Failure
A wiring problem is occurring on one or more devices.
[6]Module Tamper Trouble
A device’s anti-tamper switch has been triggered.
[7]Fire Loop Trouble
One of the zones is in fire loop trouble.
[8]Timer Loss
Your alarm system’s clock must be reprogrammed.
(follow step 2 on page 2 to reset time and date)
[9]Wireless Zone Supervision Loss
One or more wireless zones are no longer communicating with the system.
[0]Module Supervision Loss
One or more modules are no longer communicating with the system.
[SLEEP] Keypad Fault
There is a problem with one of your system’s keypads
*** To correctly reboot the Alarm Panel, turn power off at the power point, disconnect one of
the battery leads inside the Alarm Panel. After 5 minutes reverse the process; reconnect the
battery terminal and then turn on the power at the power point.
Fault Finding
Trouble Display
In the event of a trouble appearing on your keypad, Press the [TBL] button on your Keypad to view the
trouble. The keypad numbers will light up corresponding to the problem detected. Refer to the list below.
