Paradox Grafica Manuale utente

User’s Quick Reference Guide

*The User Menu options may vary according to your user profile.

Method 1: Using Your Code Method 2: Using One-Touch Options

1) From the System Status screen,

enter your code # (PIN).

2) Use the Scroll Keys to navigate the

User Menu* and highlight an option.

3) Press the center action key (OK).

4) Follow the on-screen instructions.

1) From the System Status screen, press

the right action key (Menu).

2) Use the Scroll Keys to navigate the

User Menu* and highlight an option.

3) Press the center action key (OK) to

enable the option.

One-Touch Options must be enabled on

all displayed partitions otherwise you will

be prompted to enter your code # (PIN).

TM

Action Keys

Scroll Keys

AC LIGHT

ON = AC power

OFF = Power failure

Fire Auxiliary Emergency

Panic Keys (press and hold)

Use the Action Keys to

select an option shown

above the Action Key on

the screen.

Navigate the User Menu

with the Scroll Keys.

How To Use Grafica

Grafica-EQ01.fm Page 1 Tuesday, November 26, 2002 3:36 PM

Some features in this Quick Start need to be activated by your installer.

We recommend that you test your system on a weekly basis. Please refer to the appropriate user manual.

© 2002 Paradox Security Systems Ltd.

Grafica is a trademark of Paradox Security Systems.

Arm System: Arms entire area when all zones are closed.

Disarm: Disarms entire area.

Stay Arm: Arms area’s perimeter only, which allows you

to remain in the protected area.

Force Arm: Arms entire area without waiting for all zones

to close.

Instant Arm: Same as Stay arming, except that an alarm

occurs instantly if any armed zones are

opened, including entry delay zones.

Alarm Memory: Displays a record of recently triggered alarms.

Trouble: Displays a list of system troubles.

Bypass: Deactivates specific zones the next time the

system is armed.

View Status: View floor plans and the status of zones,

events and areas.

Programming: Program user codes, user profiles, timed

auto-arming and send test reports.

Alarm Clock: Set the alarm clock.

Keypad Settings: Set the system tones, LCD contrast, backlight

and more.
