COMSPHERE3800Plus

SERIES MODEMS

MODELS 3810Plus and 3811Plus

QUICK REFERENCE

Document No. 3980-A2-GL10-10

Printed in U.S.A.

Notice

This publication is protected by federal copyright law. No part of this publication may be

copied or distributed, transmitted, transcribed, stored in a retrieval system, or translated

into any human or computer language in any form or by any means, electronic,

mechanical, magnetic, manual or otherwise, or disclosed to third parties without the

express written permission of Paradyne Corporation, 8545 126th Ave. N., Largo,

FL 33773.

Paradyne Corporation makes no representation or warranties with respect to the

contents hereof and specifically disclaims any implied warranties of merchantability or

fitness for a particular purpose. Further, Paradyne Corporation reserves the right to

revise this publication and to make changes from time to time in the contents hereof

without obligation of Paradyne Corporation to notify any person of such revision or

changes.

Changes and enhancements to the product and to the information herein will be

documented and issued as a new release to this manual.

Warranty, Sales, and Service Information

Contact your local sales representative, service representative, or distributor directly for

any help needed. For additional information concerning warranty, sales, service, repair,

installation, documentation, training, distributor locations, or Paradyne worldwide office

locations, use one of the following methods:

HVia the Internet: Visit the Paradyne World Wide Web site at www.paradyne.com.

HVia Telephone: Call our automated system to receive current information via

fax or to speak with a company representative.

— Within the U.S.A., call 1-800-870-2221

— Outside the U.S.A., call 1-727-530-2340

Trademarks

COMSPHERE is a registered trademark of Paradyne Corporation. All other products

and services mentioned herein are the trademarks, service marks, registered

trademarks, or registered service marks of their respective owners.

Document Feedback

We welcome your comments and suggestions about this document. Please mail them

to Technical Publications, Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773,

or send e-mail to [email protected]. Include the number and title of this

document in your correspondence. Please include your name and phone number if you

are willing to provide additional clarification.

COMSPHERE 3800Plus Series Modems

Models 3810Plus and 3811Plus

Quick Reference

Document Number 3980-A2-GL10-10

February 2002

Product Documentation on the World Wide Web

Complete documentation for this product is available at www.paradyne.com.

Select Library →Technical Manuals →Business Class Analog Modems.

Select the following document:

3980-A2-GB30

COMSPHERE 3800Plus Series Modems User’s Guide

To request a paper copy of a Paradyne document:

HWithin the U.S.A., call 1-800-PARADYNE (1-800-727-2396)

HOutside the U.S.A., call 1-727-530-8623

Before installing your modem, read the Important Safety Instructions on page 23.

Package Checklist

After opening the modem’s package, check for damage and verify that the following

items are present:

H3810Plus modem

HPower supply

HOne 6-position modular cord (in selected models)

HOne 8-position modular cord (in selected models)

Model 3810Plus Installation

DTE Connection

Use the following procedure to connect the RS-232D cable from the modem to the

DTE:

1. Make sure the modem’s rear panel power switch is Off.

2. Connect the DB-25-P (male) connector on the cable to the DB-25-S (female)

connector labeled DTE 1 on the modem’s rear panel. Use a small screwdriver to

fasten the cable to the modem.

3. Connect the DB-25-P connector on the cable to the DB-25-S connector on the

DTE. Use a small screwdriver to fasten the cable to the DTE.

98-14677-03

DATA

TERMINAL

EQUIPMENT

DB-25-P

CONNECTOR

SUB-MINIATURE

4-POSITION

PLUG FOR

NETWORK

MANAGEMENT

SYSTEM

OPERATION

POWER

SUPPLY

DIAL NETWORK

6-POSITION PLUG

LEASED-LINE

NETWORK

8-POSITION

PLUG

OFF

DIAL

LEASED DTE 1 NMS PWR ON

HUBBING

DEVICE

3810Plus Rear Panel

Dial-Line Connection

Use the following procedure to connect the 3810Plus modem to the dial network

interface:

1. Insert the 6-position, 4-conductor modular plug into the jack labeled

DIAL/LEASED.

2. Insert the other end of the modular cord into the dial network interface.

3810Plus 4-Wire/2-Wire Leased-Line Network Connection

Use the following procedure to connect a 3810Plus modem to the leased-line network

interface:

1. Insert the 8-position, 8-conductor modular plug into the jack labeled LEASED

(3810Plus).

2. Insert the other end of the modular cord into the leased-line network interface.

3. If you intend to use dial backup, follow steps listed in Dial-Line Connection section.

AC Power Supply Connection

!WARNING:

Power supplies from other modems may fit into the POWER connector, but

connecting the wrong power supply can cause damage to the modem or the

power supply.

Use the following procedure to connect the modem to an ac power outlet:

1. Make sure the modem’s power switch is in the Off position.

2. Insert the power transformer’s cylindrical connector into the modem’s rear panel

power receptacle.

3. If the modem is provided with a tabletop power supply, connect the power cord to

the power supply module.

4. Connect the power supply to a grounded ac power outlet.

Network Management System Connection

For the 3810Plus modem, use the following procedure to connect the modem to the

network management system interface:

1. Insert the subminiature 4-position, 4-conductor modular plug of the 3600 Hubbing

Device into the jack labeled NMS.

2. Connect the 3600 Hubbing Device to the network management system.

Refer to the 3600 Hubbing Device, Feature Number 3600-F3-300, Installation

Instructions for more information. Installation for the 3810Plus modem is the same as

for the 3610 DSU.

3000HUBBING DEVICE

MODEL #3000-F3-300

8-Pin

Modular

Jacks

6 Inches

Overall

4-Pin

Modular

Plug

496-13775-03

Numbers

CC IN/DC OUT CC OUT/DC IN

CC IN/DC OUT

Hubbing Device

CC OUT/DC IN

3600 Hubbing Device

Model 3811Plus Installation

The COMSPHERE 3000 Series Carrier has 17 slots which can hold up to 16 modems

and one SDU. The SDU is required when the modems in the carrier are controlled by

an NMS, or when multiple carriers in a cabinet configuration are to be controlled by a

single SDCP. The SDCP of the COMSPHERE 3000 Series Carrier is the user interface

to the 3811Plus modem. A single SDCP can control modems in up to eight carriers.

To install a 3811Plus modem into the carrier, perform the following steps.

1. At the rear of the carrier, install the rear connector plate. Make sure the plate uses

the same slot position as that intended for the modem.

496-14906

V.35

(3600/3500)

RS366A/V.25

(3800)

EIA232/V.24

25-Pin

DTE Connectors

P21

Loosely fasten the plate. This allows for slight adjustments later when installing the

modem.

CAUTION:

Always use a ground strap when handling a modem. Always store a

3811Plus modem in an antistatic bag when it is removed from the carrier.

495-14797

2. At the front of the carrier, hold the modem vertically, with the latch on its faceplate

in the open position, and insert it into the top and bottom card guides of one of the

slots numbered 1–16.

Slide the modem into the slot, aligning the modem with the rear connector plate,

until the backplane connector and DTE connector seat firmly into the back of the

carrier. To lock the modem into the carrier, press the faceplate latch until a click is

heard.

3. Rotate the circuit pack lock(s) into the closed position, and tighten the screw.

Circuit

Card

Guides

Circuit

Pack

Lock

Latch

Open

(Unlocked)

Closed

(Locked)

495-14813

4. If the carrier is connected to power, the Power LED on the faceplate of the

3811Plus lights up. After several seconds the modem completes its power-up

self-test in which all faceplate LEDs light up.

If the modem fails, or an alarm condition exists, the Alrm LED on the faceplate

lights up or flashes. It may be possible to run a diagnostic self-test from the SDCP.

See Test Branch in the COMSPHERE 3800Plus Modems User’s Guide.

Return to the rear of the carrier and tighten the rear connector plate.

5. Connect an RS-232D DTE cable to the top connector of the rear connector plate.

(The bottom connector is unused.)

6. Connect the other end of the cable to your DTE.

Diagnostic Control Panel

The Diagnostic Control Panel (DCP) is the user interface to the modem. It provides a

2-line, 32-character liquid crystal display (LCD), a keypad, speaker grill, and status

indicators.

A Shared DCP (SDCP) is used to manage carrier-mounted 3811Plus modems. The

Select key is used to connect the SDCP to a modem or other device in a specific

carrier and slot location. Press the Select key, then enter the modem carrier (1–8) and

slot (1–16) numbers. Once the modem is selected, operation of the SDCP is the same

as for the standalone DCP.

TXD

RXD

RTS

CTS

DSR

DTR

LSD

103

104

105

106

107

108

109

Pwr

Alrm

Test

Dial

Busy

Serv

Status

Front Panel

3811

Plus

142

125

Spkr

Moves up one level from the current display.

Moves cursor or display to the left or right.

Returns display to Top-Level menu.

Selects item displayed directly above the key.

F1, F2, F3

and

Direction and Function keys provide operator control.

Hidden Choice Indicators.

Indicates more LCD selections are available to the left or right of what is

currently displayed on the LCD.

Indicates more configuration options are available below what is currently

displayed. Also indicates selected configuration option.

Indicates last configuration option available for that group.

Nxt

End

Select

SDU12345678910111213141516

COMSPHERE 3000

SELECT

KEY

STATUS

INDICATORS

CARRIER SLOTS 1–16

F1 F2 F3

OK Alarm BckUp Test EC

NETWORK

DEVICE

ALARM DIAL

BACKUP TEST

MODE

ERROR

CORRECTION

OK Alarm BckUp Test EC

KEYPAD LCD

496-14487a

Altri manuali per COMSPHERE 3800PLUS

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Paradyne Modem

Paradyne

Paradyne COMSPHERE 3921PLUS Manuale utente

Paradyne

Paradyne 7984 Manuale utente

Paradyne

Paradyne Hotwire 7975 Manuale utente

Paradyne

Paradyne COMSPHERE 3810Plus Manuale operativo e di manutenzione

Paradyne

Paradyne COMSPHERE 3000 Series Manuale utente

Paradyne

Paradyne COMSPHERE 3825Plus Manuale utente

Paradyne

Paradyne Hotwire 7975 Manuale utente

Paradyne

Paradyne Hotwire 7976 Manuale utente

Paradyne

Paradyne COMSPHERE 3800PLUS Manuale di istruzioni

Paradyne

Paradyne COMSPHERE 3810 Istruzioni per il montaggio

Paradyne

Paradyne COMSPHERE 3821PLUS Manuale operativo e di manutenzione

Paradyne

Paradyne Hotwire ReachDSL 6350-A4 Manuale utente

Paradyne

Paradyne HOTWIRE 7925 Manuale utente

Paradyne

Paradyne COMSPHERE 3800 Series Manuale per l'uso e la cura

Paradyne

Paradyne StormPort 610 Manuale utente

Paradyne

Paradyne 7510 Manuale

Paradyne

Paradyne Comsphere 3400 Series Manuale utente

Paradyne

Paradyne COMSPHERE 3910 Manuale del proprietario

Paradyne

Paradyne HotWire 7915 Manuale utente

Paradyne

Paradyne COMSPHERE 3910 Manuale di istruzioni

Paradyne

Paradyne Hotwire 7976 Manuale utente

Paradyne

Paradyne FrameSaver FLEX 9123 Manuale utente

Paradyne

Paradyne COMSPHERE 3920PLUS Series Manuale utente

Paradyne

Paradyne 6310 MVLT Manuale utente

Manuali Modem popolari di altre marche

Davicom

Davicom DM562AP Manuale utente

EpiValley

EpiValley TATA indicom SXC-1080 Manuale utente

Zte

Zte WiMAX Manuale utente

Intelimax

Intelimax MA-2060 Manuale utente

SMC Networks

SMC Networks D3CM1604V Manuale per l'uso e la cura

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuale utente

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuale utente

Samsung

Samsung AceLink SAM-335A Manuale utente

Enfora

Enfora Enabler-G Guida rapida alla configurazione

iRZ

iRZ ATM2-232 Manuale utente

Zhone

Zhone 6310 Manuale utente

US Robotics

US Robotics 3453C Manuale utente

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuale utente

Zte

Zte MF823 Manuale utente

Four-Faith

Four-Faith F1403 Manuale utente

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuale utente

Gemtek

Gemtek WiMAX WIXFBR-103 Manuale utente

Zoom

Zoom 1070 Series Manuale utente
