Parkside 302787 Manuale utente
BATTERY PAP 20 A3
IAN 302787
AKKU
Bedienungsanleitung
BATTERY
Operating instructions
GB Operating instructions Page 1
DE/AT / CH Bedienungsanleitung Seite 21
Before reading, unfold the page containing the illustra-
tions and familiarise yourself with all functions of the
device.
Klappen Sie vor dem Lesen die Seite mit den Abbildun-
gen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
A
All Parkside tools of the X20V Team series are com-
patible with the PAP 20 A1 / PAP 20 A2 / PAP 20 A3
battery pack.
20V max.
18V
PAP 20 A3 GB │ 1 ■
Contents
Introduction........................2
Intended use............................. 2
Features ................................ 3
Package contents ......................... 3
Technical data ........................... 3
General Power Tool Safety Warnings ..5
Extended safety guidelines.................. 7
Charging the battery pack (see fig. A) ..8
Checking the battery charge level ............ 9
Maintenance and storage ...........10
Kompernass Handels GmbH warranty 11
Service ................................14
Importer ............................... 14
Disposal..........................15
Notes concerning the EC
Declaration of Conformity ...........17
Ordering a replacement battery......18
Online ordering ......................... 18
Telephone ordering ......................20
IB_302787_PAP20A3_LB6.indb 1 06.03.18 08:24
PAP 20 A3■ 2 │ GB
Introduction
Congratulations on the purchase of your new appli-
ance. You have chosen a high-quality product. The
operating instructions are part of this product. They
contain important information about safety, usage and
disposal. Before using the product, please familiarise
yourself with all operating and safety instructions.
Use the product only as described and for the range
of applications specified. Please also pass these
operating instructions on to any future owner.
Intended use
This rechargeable battery is suitable for:
This rechargeable battery is not intended for com-
mercial use. Any other usage of or modification to
the appliance is deemed to be improper and carries
a significant risk of accidents. The manufacturer
accepts no responsibility for damage(s) attributable
to misuse.
IB_302787_PAP20A3_LB6.indb 2 06.03.18 08:24
PAP 20 A3 GB │ 3 ■
Features
Battery pack
Battery charge level button
Battery display LED
High-speed charger (not supplied)
Red charge control LED
Green charge control LED
Package contents
1 battery
1 set of operating instructions
Technical data
Battery: PAP 20 A3
Type: LITHIUM ION
Rated voltage: 20 V (DC)
Capacity: 4.0 Ah
Cells: 10
IB_302787_PAP20A3_LB6.indb 3 06.03.18 08:24
PAP 20 A3■ 4 │ GB
To charge the battery pack, use only the
following high-speed battery charger:
X20V Team Serie
(not supplied)
PLG 20 A2:
INPUT:
Rated voltage: 230–240 V ∼, 50 Hz
(AC)
Rated power
consumption: 85 W
Fuse (internal): 3.15 A
T3.15A
OUTPUT:
Rated voltage: 21.5 V (DC)
Rated current: 3.5 A
Charging time: approx. 80 min
Protection class: II/ (double insulation)
IB_302787_PAP20A3_LB6.indb 4 06.03.18 08:24
PAP 20 A3 GB │ 5 ■
General Power Tool
Safety Warnings
WARNING!
■Read all safety warnings and all instructions.
Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for
future reference.
a) Charge a rechargeable battery unit using only
the charger recommended by the manufacturer.
Chargers are often designed for a particular type
of rechargeable battery unit. There is the danger
of fire if other types of rechargeable battery units
are used.
b) Only the rechargeable battery units supplied
are to be used with an electrical power tool.
The use of other rechargeable battery units may
lead to the danger of injury or fire.
IB_302787_PAP20A3_LB6.indb 5 06.03.18 08:24
PAP 20 A3■ 6 │ GB
c) When they are not being used, store recharge-
able battery units away from paperclips, coins,
keys, nails, screws or other small metal objects
that could cause the contacts to be bridged.
Short-circuiting the contacts of a rechargeable
battery unit may result in heat damage or fire.
d) Fluids may leak out of rechargeable battery
units if they are misused. If this happens, avoid
contact with the fluid. If contact occurs, flush
the affected area with water. Seek additional
medical help if any of the fluid gets into your
eyes. Escaping battery fluid may cause skin
irritation or burns.
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable
batteries!
Protect the rechargeable battery from
heat, for example from continuous
exposure to sunlight, fire, water and
moisture.
There is a risk of explosion.
IB_302787_PAP20A3_LB6.indb 6 06.03.18 08:24
