Paxar TC6021OH Manuale di servizio
Pathfinder™
Scout Peripheral Printer
TC6021OH Rev. A 3/92 ©1992 Monarch Marking Systems, Inc. All rights reserved.
Operator’s Handbook
Each product and program carries a respective written warranty, the
only warranty on which the customer can rely. Monarch reserves the
right to make changes in the product and the programs and their
availability at any time and without notice. Although Monarch has
made every effort to provide complete and accurate information in
this manual, Monarch shall not be liable for any omissions or
inaccuracies. Any update will be incorporated in a later edition of
this manual.
WARNING
This equipment can interfere with radio communication if not
installed and used in accordance with the instruction manual. It
has been tested and found to comply with the limits for a
Class A computing device pursuant to FCC Rules, Part 15,
Subpart B, which provide reasonable protection against such
interference when operated in a commercial environment.
Operation in a residential area is likely to cause interference
which the user must correct at their own expense.
CANADIAN D.O.C. WARNING
This digital apparatus does not exceed the Class A limits for
radio noise emissions from digital apparatus set out in the
Radio Interference Regulations of the Canadian Department of
Communications.
Le présent appareil numérique n’émet pas de bruits
radioélectriques dépassant les limites applicables aux appareils
numériques de la classe A prescrites dans le Réglement sur le
brouillage radioélectrique édicte par le ministère des
Communications du Canada.
Trademarks
MONARCH is a registered trademark of Monarch Marking Systems, Inc.
Paxar is a trademark of Paxar Corporation
6010, 6021, 6090, 6092, 6094, 6095, 6096, and Pathfinder are trademarks of
Monarch Marking Systems, Inc.
-
Preface
This manual contains general information about:
•the features and functions of the 6020™Online Series
printers.
•the general operation of the printer.
•the maintenance of the printer.
Models such as the 6021-WP have offline printing capabilities.
Refer to the
Offline Features Manual
for additional information.
A Format Design Kit is available for information about
designing format and label data records. The kit is used
primarily by the specialist creating the formats and label data
records. The kit contains the manuals listed below:
•
Programmer’s Manual
•
Format Reference
i
Terms to know
Programming
specialist
A programmer or individual with
programming experience. The specialist
will provide the operator format and label
data records which will be sent to the
printer.
Host system
Any mainframe, minicomputer, data
terminal, or personal computer.
download (send)
Transmitting data from your host system
to your printer.
Offlineprinter
Printer with offline printing capabilities.
Cursor
Tells which keypad mode you are in:
Regular mode cursor is a solid underline.
Shift mode cursor is a blinking rectangle.
Enter or enter
Tells you to input data or information.
-
Represents the
-
key on the keypad.
Press this key to complete an action or
to send data to memory.
Format records
Contains a specific label design for
printing data.
Label records
The data containg the format number
and the actual data to be printed on a
label.
=
Represents the
=
key on the keypad.
Press this key to use the functions
located on numeric keys.
default
Refers to the value already set when you
receive the printer. See Chapter 4,
about the special operating functions.
Operator’s Handbook
ii
How This Manual Is Organized
Chapter 1 Gives a basic overview about your printer.
Chapter 2 Tells you what you need to do and know before
using the printer.
Describes how to operate the printer to
receive records and print labels.
Chapter 3 It also describes data entry features available
in your model.
Chapter 4 Provides procedures for using special
operatingfunctions.
Chapter 5 Provides information about the care maintenance
of your printer.
Chapter 6 Contains error messages you may see while
using your printer and troubleshooting
suggestions.
Chapter 7 Provides specifications about your printer. It
also has a listing of accessories you may use
with your printer.
Audience
Operator is the individual printing and applying labels.
Chapters 1, 2, 3, 5, 6, and 7 are for the Operator.
Chapter 4 is for the supervisor setting the options of the printer.
Preface
iii
Operator’s Handbook
iv
Table of Contents
1. Overview..............................................................................1
2. Getting Started ...................................................................3
About the Handle...........................................................4
Charging Time...................................................4
Low Battery........................................................5
Factors Affecting a Charge ...............................5
Charging the Handles....................................................6
Loading and Removing a Handle..................................7
Loading and Removing Supplies ..................................8
LoadingSupplies...............................................8
Removing Supplies .........................................12
The Display..................................................................13
The Cursor ......................................................13
Using Alphanumeric Mode..........................................13
Using the Keypad........................................................14
Using the Function Keys .............................................15
3. Printing a Label ...............................................................17
Receiving Records......................................................18
Receiving Label Data Records........................19
Receiving Formats Records............................19
Error Messages...............................................20
Duplicate Formats...........................................20
SequentialCounting....................................................21
Sequential Count Multiples..........................................22
Helpful Reminders.......................................................24
v
4. Special Operating Features ............................................25
Setting the Communication Parameters.....................26
Date and Time Feature...............................................27
Setting the Date and Time ..............................27
Disabling/Enabling Date and Time Display..... 29
Changing Date and Time Styles.....................30
Date Format Samples.....................................33
Time Format Samples.....................................33
Displaying the Revision Level.....................................34
Sequential Count Multiples .........................................35
OnlineInterface...........................................................36
CurrencySelection......................................................37
Creating a Check Digit Routine...................................38
5. Care and Maintenance......................................................41
Clearing the Supply and Backing Paper Tracks......... 41
Checking the Label Chute for Stuck Labels................43
Cleaning the Print Head and Platen Roller.................44
6. Messages and Troubleshooting......................................47
Messages....................................................................47
Error Messages...........................................................49
Troubleshooting..........................................................50
7. Specifications and Accessories......................................53
Specifications..............................................................53
Accessories.................................................................53
Operator’s Handbook
vi
1. Overview
If you requested custom formats for your printer at the time
your printer was ordered, your printer already has formats
stored in memory.
If custom formats were ordered, see your management for
procedures about using your formats.
If you did not request custom formats, the programming
specialist in your company must design formats to be sent to
your printer. These formats must be sent to the printer’s
memory before you begin to print labels.
First, read Chapter 2 for general installation and operating
procedures.
1
Operator’s Handbook
