PcCom Discovery GO2780 Manuale utente
DCR READY
Dynamic Contrast Ratio Technology
Adaptive sync
27”
FLICKER FREE
CURVED
R1500 CURVEDLOW BLUE LIGHT 1MS MPRT
FHD
1920x1080
165
REFRESH RATE
Hz
GO2780
The terms HDMI and HDMI High-Denition Multimedia
Interface, and the HDMI Logo are trademarks or
registered trademark of HDMI Licensing Administrator,
Inc. in the United States and other countries.
WARRANTY
Dear customer:
Thank you for purchasing an PCCOM product. If you have any difculty installing or using
the product, we recommend you rstly consult the operating instructions before contacting
the after sales service.
We apologize if your product is not working as expected. In this case, PCCOM will arrange
for repair, replacement, refund or provide spare parts under the terms of the warranty.
Warranty period starts on the day of purchase of the product from an authorized dealer or
vie online and will ends after 24 MONTHS. The conditions of the warranty are:
• The guarantee is valid only on presentation of the product's purchase invoice.
• Damage caused during transportation; negligence or misuse; incorrect assembly or
installation, or external inuences, such as: atmospheric or electrical rays, ooding,
humidity, etc. are not covered by the warranty.
• Damage caused as a result of improper installation, power connection (electricity, water,
gas), drainage and disposal are also not covered by the warranty.
• Aesthetic damage (scratches, chips, etc.) cause by use are not covered by the warranty.
• This warranty ends when that the product is found to have been subjected to repairs,
alterations or interventions by any person not authorized.
• During reparation time, no amount will be paid for action damages for the time the
appliance is out of service.
• The warranty does not cover deciencies resulting from improper use and periodic
maintenance of the product as specied in the user manual.
• Accessories or consumable components are not covered by the warranty.
• Rubber components are excluded from the warranty.
• The product is not covered by the warranty if it lacks the corresponding identication
label. The user must inform the technical service of the data included on the identication
label when required.
To make use of the guarantee please contact our support department by the website,
https://www.pccomponentes.com/.
THE WARRANTY DOES NOT AFFECT THE LEGAL RIGHTS OF THE CONSUMER IN THE
EVENT OF NON-CONFORMITY OF THE PRODUCTS WITH THE CONTRACT.
GARANTÍA
Estimado cliente:
Gracias por comprar este producto PCCOM. Si tiene alguna dicultad para instalar o utilizar
el producto, le recomendamos que consulte primero las instrucciones de funcionamiento
antes de ponerse en contacto con el servicio técnico.
Le pedimos disculpas si su producto es defectuoso o tiene algún problema de fabricación.
En ese caso, por favor, póngase en contacto con PC Componentes para tramitar la
reparación, sustitución o reembolso según las condiciones de la garantía.
La garantía comienza el día de compra del producto en un distribuidor autorizado o a través
de compra on-line y naliza pasados 24 MESES. Las condiciones de la garantía son:
• La garantía es válida sólo con la presentación de la factura de compra del producto.
• No están cubiertos por la garantía los daños causados durante el transporte, negligencia
o mal uso, montaje o instalación incorrecta, así como las inuencias externas, tales
como: rayos atmosféricos o eléctricos, inundaciones, humedad, etc.
• Tampoco estarán cubiertos por la garantía los daños causados como consecuencia
de inadecuada instalación, conexión de alimentación (eléctrica, agua, gas), desagüe y
evacuación.
• No están cubiertos por la garantía los daños estéticos (como rasguños, desconchados,
etc) surgidos por el uso.
• Esta garantía termina cuando se descubre que han sido sometidas a reparaciones,
reformas o intervenciones por cualquier persona no autorizada.
• Durante el tiempo que pase entre el contacto con el servicio técnico y la reparación del
aparato, no se abonará importe alguno en concepto de daños y perjuicios por el tiempo
que el aparato esté fuera de servicio.
• La garantía no cubre aquellas deciencias derivadas de una incorrecta utilización
y mantenimiento periódico del producto, tal y como se especica en el manual de
instrucciones.
• No están cubiertos por la garantía los accesorios o componentes consumibles.
• Se excluyen de la garantía los componentes de goma.
• El producto no está cubierto por la garantía si carece de la placa identicativa
correspondiente. El usuario deberá comunicar al servicio técnico los datos incluídos en
la placa identicativa cuando así se requiera.
Para hacer uso de la garantía póngase en contacto con el centro de soporte a través de la
web https://www.pccomponentes.com/.
LA GARANTÍA NO AFECTA A LOS DERECHOS LEGALES DEL CONSUMIDOR ANTE LA
FALTA DE CONFORMIDAD DE LOS PRODUCTOS CON EL CONTRATO.
Product Description.............................................................................................
Product Overview................................................................................................
Stand Installation.................................................................................................
Wall Mounting......................................................................................................
Basic Operation...................................................................................................
Indicator Light......................................................................................................
OSD....................................................................................................................
ECO Modes and Gameplus Switching................................................................
Technical Specications of Product.....................................................................
04
05
06
07
08
08
09
12
13
Contents
Listado del producto............................................................................................
Descripción del producto.....................................................................................
Instalación del soporte.........................................................................................
Instalación en pared............................................................................................
Uso básico...........................................................................................................
Indicador de luz...................................................................................................
Menú en pantalla (OSD)......................................................................................
Función ECO y Gameplus...................................................................................
Especicaciones Técnicas..................................................................................
14
15
16
17
18
18
19
22
23
ÍNDICE
EN
8
IMPORTANT SAFETY PRECAUTIONS
Operation
Keep the monitor out of direct sunlight and away from stoves or any other heat source.
Keep the monitor out of water source.
Remove any object that could fall into ventilation holes or prevent proper cooling of the monitor's electronics.
Do not block the ventilation holes.
Do not knock or drop the monitor during operation or transportation.
Maintenance Guidelines
CAUTION
Do not place the monitor in rain, humid environment or open the monitor case to avoid any shock electrica hazards, and/
or mechanical hazards.
Before cleaning the monitor, unplug the monitor power cable from the electrical outlet.
Caring for Your Monitor
To clean your screen, slightly dampen a soft, clean cloth with water.
lf possible, use a special screen-cleaning tissue or solution. Do not use benzene, thinner, ammonia, abrasive cleaners,
or compressed air.
Use a slightly dampened, warm cloth to clean the frame. Avoid using detergent of any kind as some detergents might
leave a milky lm on the plastics.
Unplug the monitor if you are not going to use it for an extendedperiod of time.
To avoid the risk of shock or permanent damage to the set, do not expose the monitor to dust,rain, water, or excessive
moisture environment. If your monitor gets wet, wipe it with dry cloth as soon as possible.
1. Product Description
Packing list
Please check the following items in the packing case before installation:
lf any of above items is missing, please contact with the dealer.
Monitor×1
Wall mount screws×4
Stand stem×1
DP cable×1
Stand base×1
Power cable×1
Harness seat×1
Power Adaptor×1
Foot pad×1
User Manual×1
Screws×1
EN
9
2. Product Overview
2.1 Monitor Buttons
1
1
7
7
2
2
8
8
3
3
9
9
4
4
10
10
5
5
6
6
MMenu Button Press to display the OSD menu or enter sub-menus.
Down Button Press to move down in the menus.
Up Button Press to move up in the menus.
EExit Button Press to exit.
Power Button Press to turn the monitor on/off.
LED Indicator Changes colour according to status.
Power Connector Insert the power cable to supply power to the monitor.
HDMI Connectors Insert one end of the HDMl cable into the computer's HDMI
output and connect the other end to the monitor's HDMl port.
DP Connectors Insert one end of the DP cable into the computer's DP output
and connect the other end to the monitor's DP port.
Audio Output
Plug one end of the audio cable into the audio output interface,
and connect the speaker to receive the audio signal from the
monitor.
2.2 Monintor Ports
Connect the signal line to output interfaces signal of DP/HDMI signals of PC, and then connect the other end of
the signal line to the corresponding signal input port of the display.
DC DPHDMI2 HDMI1 AUDIO
OUT
EN
10
3. Stand Installation
3.1 Bracket installation
In the process of assembling/disassembling the base of the bracket, the display screen cannot be left under the polyol
foam to prevent the screen from being broken.
Open the packing box, take out the bracket and the base, use 2 screws to pass through the base to lock the bracket
and paste the foot pads, and then clip it into the cable harness seat.
Take the machine out of the box, lay it at, with the back facing up, snap the stand into the monitor, and push the
quick release button to complete the stand removal.
1
2
Screws Harness Seat
Quick release button
Foor Pad
