Pelgrim PKS14088 Manuale utente

Instructions for use

Built-in refrigerator

PKS14088

PKS14102

PKS14122

PKD13102

PKS14140

PKS24088

PKS24102

PKS24122

PKD23102

PKS24140

715469

We thank you for the confidence you have shown by purchasing

our appliance which is designed to simplify your life. To make the use of the

product easier, we have supplied detailed instructions for use, and installation

instructions supplied on a separate sheet. The instructions should allow you to

learn about your new appliance as quickly as possible.

We wish you find a lot of pleasure in its use.

The appliance is intended solely for household use.

Please visit our website where you can enter your appliance model number,

indicated on the rating plate or the warranty sheet, to find detailed description

of your appliance, tips on use, troubleshooting, service information, instructions

for use etc.

www.pelgrim.nl

Important safety warning

General warnings and tips

Protecting the environment

Do not wash in the dishwasher

CONTENTS

715469

INTRODUCTION

APPLIANCE

DESCRIPTION

DEFROSTING

AND CLEANING

THE APPLIANCE

4 IMPORTANT NOTES AND PRECAUTIONS

4 BEFORE USING THE APPLIANCE FOR THE FIRST TIME

5 IMPORTANT SAFETY INSTRUCTIONS

7 IMPORTANT INFORMATION ON THE USE OF APPLIANCE

8 ENVIRONMENT PROTECTION

9 ADVICE FOR SAVING POWER WITH REFRIGERATION

APPLIANCES

10 INSTALLATION AND CONNECTION

12 APPLIANCE DESCRIPTION

14 OPERATING THE APPLIANCE

16 APPLIANCE INTERIOR EQUIPMENT

19 RECOMMENDED DISTRIBUTION OF FOOD IN THE

APPLIANCE

20 STORING FOOD IN THE REFRIGERATOR

21 DEFROSTING THE APPLIANCE

22 CLEANING THE APPLIANCE

23 TROUBLESHOOTING

25 INFORMATION ABOUT APPLIANCE NOISE

MISCELLANEOUS

STORING FOOD

IMPORTANT NOTES AND

PRECAUTIONS

Before connecting the appliance to the power mains, please

read carefully the instructions for use which describe the

appliance and its correct and safe use. The instructions

apply to several appliance types/models; thus, settings or

equipment may be described herein which is not available

in your appliance. We recommend saving this instruction

manual for future reference and attach it to the appliance if

it is sold in the future.

Check for any damage or irregularities on your appliance. If

you find your appliance is damaged, notify the retailer from

which you have purchased the appliance.

Before connecting the appliance to the power mains, let

the appliance rest in a vertical position for a minimum of 2

hours. This will reduce the possibility of operation faults due

to the effect of transport on the cooling system.

715469

BEFORE USING THE APPLIANCE FOR

THE FIRST TIME

715469

IMPORTANT SAFETY INSTRUCTIONS

The appliance must be connected to the power mains and

grounded in compliance with the effective standards and

regulations.

Before cleaning the appliance, unplug it from the power

mains (unplug the power cord from the wall outlet).

If the power cord is damaged, it must be replaced by a

service technician or other adequately trained person.

If LED lighting does not work, call a service technician. Do

not attempt a repair of the LED lighting yourself, as there is

danger of contact with high voltage!

WARNING! Do not use any electric devices inside the

appliance, except for those allowed by the manufacturer

of this refrigeration appliance.

WARNING! Do not use mechanical devices or other

means to accelerate the defrosting process, other than

those recommended by the manufacturer.

WARNING! To avoid any hazard resulting from poor

stability of the appliance, make sure it is installed as

instructed.

715469

Danger of frostbite

Never put frozen food in your mouth and avoid touching

frozen food as this may cause frostnip or frostbite.

Safety of children and vulnerable persons

This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or metal capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

Do not let the children play with the appliance.

Cleaning and user maintenance shall not be made by

children without supervision.

Remove the packaging intended to protect the appliance

or particular parts during transport and keep it outside the

reach of children.

It presents danger of injury or suffocation.

When removing a used appliance, disconnect the power cord,

remove the door, and leave the shelves in the appliance. This

will prevent children from locking themselves in the appliance.

Warning regarding the refrigerant

The appliance contains a small amount of an

environmentally friendly yet flammable gas R600a. Make

sure that no parts of the cooling system are damaged. A

gas leak is not hazardous to the environment, but it could

cause eye injury or fire.

In case of a gas leak, ventilate the room thoroughly,

disconnect the appliance from the power mains, and call a

service technician.

715469

The appliance may not be used outdoors and it may not be

exposed to rain.

Do not store explosive substances such as aerosol cans

with a flammable propellant in this appliance.

If the appliance will be out of use for an extended period of

time, switch it off using the relevant button, and unplug it

from the power mains. Empty the appliance, defrost it, clean

it, and leave the door ajar.

In case of an error or power supply failure do not open the

freezer compartment unless the freezer has not operated

for over 16 hours. After this period, use the frozen food or

provide sufficient cooling (e.g. a replacement appliance).

Technical information on the appliance

WARNING! Keep ventilation openings, in the

appliance enclosure or in the built-in structure, clear of

obstruction.

IMPORTANT INFORMATION ON THE USE

OF APPLIANCE

Rating plate can be found in

the appliance interior (see

figure). It indicates data on

voltage, gross and net

volume, type and amount of

refrigerant, and information

on the climate classes.

715469

The symbol on the product or its packaging indicates that the product

should not be treated as normal household waste. The product should be

taken to an authorized collection centre for waste electric and electronic

equipment processing. Correct disposal of the product will help prevent

any negative effects on the environment and health of people which could

occur in case of incorrect product removal. For detailed information on

removal and processing of the product, please contact the relevant municipal

body in charge of waste management, your waste disposal service, or the

store where you bought the product.

Packaging is made of environmentally friendly materials

that can be recycled, disposed of, or destroyed without any

hazard to the environment.

!Removing an obsolete appliance

To protect the environment, take the obsolete appliance to

an authorized home appliance collection centre.

Before doing so, do the following:

• disconnect the appliance from the power mains;

• do not allow children to play with the appliance.

ENVIRONMENT PROTECTION

WARNING! Do not damage the refrigerant circuit.

This will also prevent pollution.

ADVICE FOR SAVING ENERGY

WITH REFRIGERATION

APPLIANCES

715469

• Install the appliance as specified in the instruction manual.

• Do not open the door more often than necessary.

• Occasionally make sure air circulation underneath the appliance is

unobstructed.

• Condenser unit on the rear wall should be kept clean (see chapter Cleaning

the appliance).

• If the gasket is damaged or does not provide a perfect seal for any reason,

have it replaced as soon as possible.

• Store the food in tightly sealed containers or appropriate packaging.

• Before placing the food in the refrigerator, allow it to cool down to room

temperature.

• Defrost frozen food in the refrigerator compartment.

• Make sure the layout of shelves in the compartment is uniform and that

the food is placed so that the air can freely circulate in the appliance

interior (observe the recommended placement of food as described in the

instructions).

• The lower the temperature is set the higher the energy consumption will be.

INSTALLATION AND

CONNECTION

715469

SELECTING THE ROOM

• Install the appliance in a dry and well ventilated room. The appliance will

operate correctly if the environment temperature is in the interval speciﬁed in

the table. The appliance class is indicated on the rating plate / label with the

basic information on the appliance.

Class Temperature Relative Humidity

SN (subnormal) from +10 °C to +32 °C

75%

N (normal) from +16 °C to +32 °C

ST (subtropical) from +16 °C to +38 °C

T (tropical) from +16 °C to +43 °C

• Do not place an appliance in a room where temperature can drop to

below 5 °C as this may cause abnormal appliance operation or failure!

• After the installation, the appliance mains plug should be accessible!

Note: Place the appliance in a suciently large room. There should be at least

1 m3of space per 8 grams of refrigerant. Amount of refrigerant is indicated on

the rating plate in the appliance interior.

• At the base of the kitchen unit intended for building in the integrated

appliance, there should be at least 200 cm2free space, for adequate air

circulation.

On the upper part of the appliance the air is coming out, so try not to cover

the opening for the outﬂ ow air. Ignoring this caution may result in damage to

the appliance.

Warning: when installing built-in appliances into a cupboard or cabinet in a

side-by-side layout, the dew prevention installation kit should also be purchased

and installed. For safety reasons, dew prevention kit may only be installed by

an authorized service technician!
