Pentair Deck Jet II MagicStream Manuale utente

Kit (P/N 580003) Contents

• Deck Jet Body — (Qty 4)

• Nozzle Kit (P/N 590041) — (Qty 4)

• Deck Jet Cover (P/N 590042) — (Qty 4)

Note: Each kit contains parts for four (4) MagicStream Deck Jet II units.

Technical support

590043(RevA)2/1/2008

WARNING — FOR YOUR SAFETY: This product must be installed and serviced by

a professional pool/spa service technician. The procedures in this

manual must be followed exactly. Improper installation and/or

operation will void the warranty.

This document gives instructions for installing the Pentair

MagicStream Deck Jet II. Read through the instructions completely

before starting the procedure..

Sanford, North Carolina (8A.M. to 5 P.M. - ET)

Moorpark, California (8 A.M. to 5 P.M. - PT)

Phone: (800) 831-7133

Fax: (800) 284-4151

Web sites: www.pentairpool.com - www.staritepool.com

MagicStreamTM Deck Jet II

Installation Instructions

Figure 1

Overview

TheMagicStreamDeckJet IIis designedto beinstalled inthe deckor landscapingsurrounding thepool,

spa,fountain,or pond. TheDeck Jet’sswivel nozzle(Figure1) producesa5/16" streamof water. The

DeckJet bodyisequippedwithtwo, 3/16”drain holesto allowwatertodrainfrom thecup surroundingthe

nozzleintothe draincavity atthebase ofthebody (Figure1). Be sure tokeep thedrainholes clearof

debris. Toaid indraining, Pentairrecommends placinga gravellayer beneaththeDeckJet.

PentairrecommendsthateachDeckJetbefittedwitha¾"ballvalvetoallowflowcontrolforeachnozzle.

Forinstallationsinvolvingmultiplenozzles,werecommendinstallinga3-wayvalveonthemainlinenearthe

pumpforoveralladjustment.

TheDeckJet isdesignedfor amaximum flow rateof 5GPM at 11ft ofhead(See tablebelow).

Cup

Swivel nozzle

Drain holes

Drain cavity

Deck Jet cover (P/N 590042)

Swivel base

These 2 parts are

contained in the

nozzle kit (P/N

590041

Gallons (US GPM) 3.0 4.0 5.0

Feet of head 3..9 7.9 11.0

Height of jet 3.0 6.6 10.0

Water/Pressure Specifications

Waterdrains

intogravellayer

Gravel layer

Installation

TheDeckJetbodyisdesignedtobeconnectedtoa3/4”Sch40PVCpipe(Figure2). Afterthepipeis

pressuretested, solvent weldtheDeck Jetbodyto the3/4”supply pipe. NOTE: UsePVC/ABS glue only.

AnchortheDeckJetbody,withtheDeckJetcoverattached,sothecoverislevelwiththefinisheddeck

surface.

Oncethedeckisfinished,flushanydebrisfromthesupplypipeusingthepumpandfiltersystemthat

suppliestheDeckJet. ApplyTeflon®tapetothethreadsoftheswivelbase. Removeanydebrisfromthe

cupandscrewtheswivelbaseintotheDeckJetbody(Figure2).

Byhand,pushtheswivelnozzleuntilitsnapsontotheswivelbase(Figure3).

Operation

Startthepumpandadjusttheappropriatevalvesasnecessarytocreatethedesiredwatereffect.

Ifthestreamofwaterisdisrupted,removetheDeckJetCover,JetandJetSwivelBase.Checktoseeif

thereisanydebrisblockingtheJet.

Towinterize,removetheJetandJetSwivelBase.Blowthelinesclearwithair, andinstalla1/2”threaded

plug.

¾” Sch40 pipe slip

connection

Figure 2

¾” supply pipe

Figure 3

Solvent weld¾”supply

pipeto¾”Sch40 pipe

slipconnection

Swivel base

AttachTeflontapetotheswivel

baseandscrewtheswivel

baseintotheDeckJetbody

Byhand,pushtheswivel

nozzleontotheswivelbase

until itsnapsintoplace

Swivel nozzle

Swivel base

590043(RevA)

This document is subject to change without notice.

1620HawkinsAve.,Sanford,NC 27330• (919)566-8000

10951West LosAngelesAve., Moorpark, CA93021• (805)553-5000

Trademarks and Disclaimers:

MagicStream™and PentairWaterPooland Spa®aretrademarks and/orregistered trademarksof PentairWater

Pool and Spa, Inc. and/or its affiliated companies in the United States and/or other counties. Teflon®is a registered

trademarkof E.I.DuPont DeNemours andCompany Corporation. Unlessnoted, namesand brandsof othersthat

may be used in this document are not used to indicate an affiliation or endorsement between the proprietors of these

names and brands and Pentair Water Pool and Spa, Inc.Those names and brands may be the trademarks or

registeredtrademarks ofthose partiesor others.

Printed in U.S.A.
