MFT-***.****(.L)
Multifunction Terminal
Manual
With regard to the supply of products, the current issue of the following document is applicable:
The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central
Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most
recent version as well as the supplementary clause: "Expanded reservation of proprietorship"
Worldwide
Pepperl+Fuchs Group
Lilienthalstr. 200
68307 Mannheim
Germany
Phone: +49 621 776 - 0
E-mail: [email protected].com
North American Headquarters
Pepperl+Fuchs Inc.
1600 Enterprise Parkway
Twinsburg, Ohio 44087
USA
Phone: +1 330 425-3555
E-mail: sales@us.pepperl-fuchs.com
Asia Headquarters
Pepperl+Fuchs Pte. Ltd.
P+F Building
18 Ayer Rajah Crescent
Singapore 139942
Phone: +65 6779-9091
E-mail: sa[email protected]epperl-fuchs.com
https://www.pepperl-fuchs.com
3
Multifunction Terminal MFT-***.****(.L)
Contents
2020-03
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Content of this Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Target Group, Personnel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.3 Symbols Used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.3 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.4 Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.5 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1 Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2 Connecting the Plug-In Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.3 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1 Coding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5 Dismounting, Maintenance, and Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.1 Removing Plug-In Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.2 Dismounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6 Storage, Transport, and Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Multifunction Terminal MFT-***.****(.L)
Contents
4
2020-03
Multifunction Terminal MFT-***.****(.L)
Introduction
2020-03
5
1 Introduction
1.1 Content of this Document
This document contains information that you need in order to use your product throughout
the applicable stages of the product life cycle. These can include the following:
•Product identification
•Delivery, transport, and storage
•Mounting and installation
•Commissioning and operation
•Maintenance and repair
•Troubleshooting
•Dismounting
•Disposal
The documentation consists of the following parts:
•Present document
•Instruction manual
•Datasheet
Additionally, the following parts may belong to the documentation, if applicable:
•EU-type examination certificate
•EU declaration of conformity
•Attestation of conformity
•Certificates
•Control drawings
•Additional documents
Note
This document does not substitute the instruction manual.
Note
For full information on the product, refer to the instruction manual and further documentation
on the Internet at www.pepperl-fuchs.com.
2020-03
6
Multifunction Terminal MFT-***.****(.L)
Introduction
1.2 Target Group, Personnel
Responsibility for planning, assembly, commissioning, operation, maintenance,
and dismounting lies with the plant operator.
Only appropriately trained and qualified personnel may carry out mounting, installation,
commissioning, operation, maintenance, and dismounting of the product. The personnel
must have read and understood the instruction manual and the further documentation.
Prior to using the product make yourself familiar with it. Read the document carefully.
1.3 Symbols Used
This document contains symbols for the identification of warning messages and of informative
messages.
Warning Messages
You will find warning messages, whenever dangers may arise from your actions.
It is mandatory that you observe these warning messages for your personal safety and in order
to avoid property damage.
Depending on the risk level, the warning messages are displayed in descending order
as follows:
Informative Symbols
Action
This symbol indicates a paragraph with instructions. You are prompted to perform
an action or a sequence of actions.
Danger!
This symbol indicates an imminent danger.
Non-observance will result in personal injury or death.
Warning!
This symbol indicates a possible fault or danger.
Non-observance may cause personal injury or serious property damage.
Caution!
This symbol indicates a possible fault.
Non-observance could interrupt the device and any connected systems and plants,
or result in their complete failure.
Note
This symbol brings important information to your attention.
Multifunction Terminal MFT-***.****(.L)
Product Specifications
2020-03
7
2 Product Specifications
2.1 Function
Many applications in hazardous areas work with field devices that do not have
intrinsically safe connections. In these applications, protection methods such as type Ex e
protection (increased safety) are used. In contrast to intrinsically safe circuits,
increased safety connections are generally not accessible when energized. Disconnecting
these circuits for maintenance would therefore require either the plant to be shut down
or a hot work permit to be obtained.
The multifunction terminal offers the following options for disconnecting
non-intrinsically safe circuits or removing plug-in modules in hazardous areas:
•The multifunction terminals MFT-R.****, MFT-2R.****, MFT-D****(.L), MFT-2D.****,
MFT-F.****(.L), MFT-2F.****, MFT-2L.**** enable the non-intrinsically safe circuits
to be disconnected.
•The multifunction terminals MFT-FT.****, MFT-RNO.****, MFT-RNC.**** enable
the plug-in modules to be removed even in hazardous areas.
The non-intrinsically safe circuits are separated in 2 steps:
•Step 1
The electrical contacts between the base module and the plug-in module are separated
in areas protected by the type of protection Ex d.
In this position the sparks, that have formed within the contact area, can no longer ignite
the possibly existing surrounding atmosphere.
•Step 2
The plug-in module, which is now completely electrically isolated, can now be removed.
Possible ignition sources in the area of the electrical contacts are no longer present.
The electrical connections of the base module are protected and comply with degree
of protection IP30 according to IEC/EN 60529. After removal, the plug-in module
is de-energized.
•Once the plug-in module has been removed, the de-energized side is accessible.
This allows field devices that are connected to the de-energized side to be replaced,
while the remaining part of the system continues to be energized.
Typical applications for the multifunction terminal are:
•Fusing Ex d valves, signal lamps, acoustic sensors
•Diode decoupling of supply circuits
•Simple OR gate for Zone 1 mounting
•Visible disconnect of field devices
•Relay switch for power circuits
•Current limitation using resistors
•Optocoupler applications
2020-03
8
Multifunction Terminal MFT-***.****(.L)
Product Specifications
2.2 Assembly
The multifunction terminal consists of a base module and a plug-in module. The base module
is mounted on a DIN mounting rail. The plug-in module is connected to the base module.
The base module has a plastic housing that conforms to type of protection Ex e.
There are 2-pin and 4-pin base modules for connecting plug-in modules with 2 or 4 pins.
The plug-in module has a plastic housing with type of protection Ex d. The plug-in module has
pins. The pins form together with the plug-in module contacts a chamber in type of
protection Ex d.
The plug-in module can be equipped with various components, such as resistors, diodes,
fuses, or relays. The plug-in module can be removed or connected during operation.
Grooves of different widths ensure that the plug-in module is connected
to the base module correctly.
A coding strip in the base module and corresponding coding pins in the plug-in module enable
clear assignment of the plug-in modules to the base module.
Screw terminals and unused terminal openings can be covered with IP30 covers in the form
of terminal covers and terminal pins, so that no bare, conductive parts are left uncovered.
These covers will be fitted during installation and must not be removed during operation.
Figure 2.1 Base module, view from above
1Coding strips
2Screw terminals with steel screw M3
3Terminal pins for unused Ex e terminals, IP30 protection
4Terminal covers for IP30 protection
5Terminal pins for unused Ex e terminals, IP30 protection
6Lever for locking and unlocking the multifunction terminal
7Screw terminals with steel screw M3
43
12
5 6 7 1 2 3
4
Multifunction Terminal MFT-***.****(.L)
Product Specifications
2020-03
9
Figure 2.2 Base module and plug-in module, side view
2.3 Dimensions
Figure 2.3 Dimensions multifunction terminal
1Coding pin
2Coding strip
3Wide groove
4Terminal pins for unused Ex e terminals, IP30 protection
5Terminal pins for unused Ex e terminals, IP30 protection
6Narrow groove
7Lever for locking and unlocking the multifunction terminal
6
7
1
2
3
4
5
93
17.5
79
66
29.5 1.5
72.5
23 11.530
87.6
2020-03
10
Multifunction Terminal MFT-***.****(.L)
Product Specifications
2.4 Marking
2.5 Technical Data
Base module
2-pin MFT-BASE.2P
4-pin MFT-BASE.4P
Plug-in module
1 resistor MFT-R.0001 ... MFT-R.9999
2 resistors MFT-2R.0001 ... MFT-2R.9999
1 diode MFT-D.1000
2 diodes MFT-2D.0500
1 diode, 1 bridge MFT-D.1000.L
2 bridges MFT-2L.1600
1 bridge, 1 fuse MFT-F.0032.L ... MFT-F.6300.L
1 fuse MFT-F.0032 ... MFT-F.6300
2 fuses MFT-2F.0032 ... MFT-2F.6300
Terminator MFT-FT.0001
NO contact MFT-RNO.0006
NC contact MFT-RNC.0006
ATEX certificate: PTB 07 ATEX 1004 U
ATEX marking: II 2 G Ex d e IIC
IECEx certificate: BKI 08.0008U
IECEx marking: Ex d e IIC Gb
Pepperl+Fuchs Group
Lilienthalstraße 200, 68307 Mannheim, Germany
Internet: www.pepperl-fuchs.com
Note
See corresponding datasheets for further information.
