MAINTENANCE

Maintenance

6:2

Changing the needle plate

Switch off the main switch

Removal

• Raise the presser foot. Position the needle plate changer (light bulb

changer) as shown and press the needle plate up on the right, then

on the left. It can now be easily removed.

Replacing

• Place the needle plate against the rear edge of the cut-out then press

down at the front until you hear it snap in place. Before you start

sewing, check that the needle plate is lying ﬂat.

Note: Lower the feed dogs to make removing the needle plate easier.

Cleaning

Switch off the main switch

• Remove the needle plate and lower the feed dogs. Clean the feed

dogs and hook area with the brush.

• Clean the sewing machine after every 10 - 15 hours of operation.

Cleaning the window

Wipe the window with a soft, lint-free dry cloth. DO NOT use abrasive

cleansers or solvents!

Maintenance

6:3

Changing the light bulb

Switch off the main switch

• Disconnect the lead cord and the foot control plug from the

machine.

• Remove the accessory tray. The light bulb is located inside the

sewing machine near the needle threader.

Bulb removal

Push the light bulb changer up as far as it will go. Now turn the bulb

half a rotation counter clock-wise and remove the bulb.

Insertion of the bulb

Important: Use a light bulb as indicated on the left side of the machine,

12 V max 5 W.

Insert the bulb in the light bulb changer. Guide the bulb into the

diagonal holder and turn it until the pins of the bulb engage. Push

the bulb upward into the holder as far as it will go and turn it half a

rotation in a clock-wise direction. Remove the light bulb changer from

the bulb. The bulb will be held ﬁrmly so you can remove it safely.

Bulbs can be purchased from your Pfaff dealer.

Maintenance

6:4

What to do if...?

In this chapter you are suggested solutions if you have a problem with your creative 2170. For further information please

contact your Pfaff dealer who will be pleased to help you.

Sewing

Problem/Cause Remedy

The machine skips stitches

Did you insert the needle properly? Push the needle fully upwards with its ﬂat side facing the

back.

Did you insert a wrong needle? Use needle system 130/705 H.

Is the needle bent or blunt? Insert a new needle.

Did you thread the machine properly? Check how the machine is threaded.

Is the needle too small for the thread? Change the needle.

Needle thread breaks

Did you insert the needle properly? Push the needle fully upwards with its ﬂat side facing the

back.

Did you insert a wrong needle ? Use needle system 130/705 H.

Is the needle bent or blunt? Insert a new needle.

Did you thread the machine properly? Check how the machine is threaded.

Is the needle too small for the thread? Change the needle.

Are you using poor thread with slubs or thread which has

become dry after overlong storage? Change the thread.

Bobbin thread breaks

Did you insert the bobbin properly? Check the bobbin thread.

The seam is sewn unevenly

Is the thread tension misadjusted? Check needle thread tension.

Are you using too thick or slubbed thread? Change the thread.

Is the bobbin thread evenly wound? Check bobbin winding.

The machine does not feed or feeds irregularly

Did you thread the machine properly? Check how the machine is threaded.

Has sewing lint collected between the feed dog teeth rows? Remove the needle plate and clean the feed dog with a brush.

The machine binds

Is the feed dog lowered? Engage the feed dog.

Incorrect or no display

Are there thread remnants in the hook ways? Remove the thread remnants.

Is the contrast control for the display

misadjusted? Set the contrast for the display.

Maintenance

6:5

Embroidery

Problem/Cause Remedy

The embroidery design is distorted

Did you hoop the fabric strongly enough? The fabric must be tightly hooped, in such a way that no

creases form.

Is the inner embroidery hoop completely attached to the

outer embroidery hoop? Hoop the fabric in such a way that the inner hoop always

exactly matches the outer hoop.

The embroidery design has contracted

Did you stabilize your fabric sufﬁciently? Place a sheet of Adhesive backed paper/stabilizer and/or

Water-soluble stabilizer onto the fabric.

Needle thread breaks

Did you use the right needle? Insert a needle with a larger eye

(System 130N).

Is the needle bent or blunt? Insert a new needle.

Is the thread too thick for the needle? Use the right needle size.

Did you insert the needle properly? Push the needle fully upwards with its ﬂat side facing the

back.

Did you thread the machine properly? Check how the machine is threaded.

Are you using poor thread with slubs or thread which has

become dry after overlong storage? Change the thread.

Non-original Parts and Accessories

The warranty does not cover any defect or damage caused by use of non-original accessories or

parts.
