Phaser 6250 Manuale utente
Phaser® 6250 Color Laser Printer
Copyright © 2003 Xerox Corporation. All Rights Reserved.
2-9
Basic Printing
This topic includes:
■"Tray 1 (MPT) Paper Path" on page 2-9
■"Loading Paper in Tray 1 (MPT)" on page 2-10
■"Trays 2-4 Paper Path" on page 2-12
■"Loading Paper in Trays 2-4" on page 2-12
■"Factors Affecting Printer Performance" on page 2-17
Follow these steps to print jobs:
1. Load paper in the tray.
2. Confirm the paper type at the printer’s front panel.
3. Select File/Print to adjust the printing options in the printer driver. For more information
go to Reference/Printing/Adjusting Printing Options on the User Documentation CD-
ROM.
4. Send the job to the printer from the application’s Print dialog box.
Tray 1 (MPT) Paper Path
The following graphic displays the printer’s paper path:
6250-089
Basic Printing
Phaser® 6250 Color Laser Printer
2-10
Loading Paper in Tray 1 (MPT)
Use Tray 1 (MPT) for plain paper, envelopes, transparencies, custom size paper, labels,
business cards, greeting cards, CD/DVD labels, and CD/DVD inserts.
For more information on paper types, weights, and sizes, go to Reference/Printing/Supported
Papers on the User Documentation CD-ROM.
1. Open Tray 1 (MPT) by pushing the handle down and out.
d.
2. Adjust the paper guides to match the size of the paper.
Caution
If you change the type of paper in a tray, you
must change the paper type on the front
panel to match the paper that you loaded. If
you fail to do this, print-quality problems
can occur and the fuser can be damaged.
Caution
6250-045
Phaser 6250
6250-00
6
6250-007
Basic Printing
Phaser® 6250 Color Laser Printer
2-11
3. Fan the paper to release sheets that may stick together.
4. Insert the paper, transparencies, or envelopes into the tray. Place the side to be printed
facedown with the top of the page at the back of the tray. Do not load paper above the fill
line. Place envelopes with the flap side up and top of the envelope towards the right of the
printer.
5. If necessary, press the guides inward to match the size of the paper.
6250-072
6250-01
0
Basic Printing
Phaser® 6250 Color Laser Printer
2-12
When prompted by the front panel to confirm the paper type and size:
6. If you have not changed the type or size of paper, press the OK button to accept the current
setting for paper type and size.
7. If you have changed the paper type:
a. At the printer’s front panel, select Change, then press the OK button.
b. Select the appropriate paper type.
c. Press the OK button to save your selection.
8. If you have changed the paper size:
a. Select the appropriate paper size.
b. Press the OK button to save your selection.
Trays 2-4 Paper Path
The following graphic displays the printer’s paper path:
Loading Paper in Trays 2-4
For more information on paper types, weights, and sizes, go to Reference/Printing/Supported
Papers on the User Documentation CD-ROM.
Caution
DO NOT load card stock, photo paper, envelopes, business cards, greeting cards, CD/DVD
labels, and CD/DVD inserts in Trays 2-4. Do not load transparencies or labels in Trays 3
or 4. Use Tray 1 (MPT) or Tray 2 for printing these media types.
Caution
If you change the type of paper in a tray, you must
change the paper type on the front panel to match
the paper that you loaded. If you fail to do this,
print-quality problems can occur and the fuser
can be damaged.
6250-093
6250-0
4
Phaser 6250
Basic Printing
Phaser® 6250 Color Laser Printer
2-13
1. Pull out the tray.
2. If loading paper having a different width or length, adjust the width and length guides.
3. Fan the paper to release sheets that may stick together.
4. Insert paper into the tray.
6250-035
6250-001 6200-00
4
Basic Printing
Phaser® 6250 Color Laser Printer
2-14
■For one-sided prints, place the side to be printed faceup with the top of the page at the
front of the tray.
■For two-sided prints, place the side to be printed with the odd-numbered pages
facedown with the top of the page at the back of the tray.
6250-041
6250-074
Basic Printing
Phaser® 6250 Color Laser Printer
2-15
■If using paper with pre-punched holes, place the holes toward the right side of the
tray.
Note
Observe the fill lines on the side of the tray. Do not load paper above the fill line (1); it
may cause the printer to jam. Do not load transparencies or glossy-coated paper above
the transparency fill line (2). Place the paper under the front corner tabs and the tabs
on the back guide. Do not load transparencies in Trays 3 or 4.
5. If necessary, press the guides inward to match the size of the paper.
6250-058
PH
6250-003
1
2
6200-00
4
Basic Printing
Phaser® 6250 Color Laser Printer
2-16
6. Insert the paper tray into the printer and push the tray completely to the back of the printer.
When prompted by the front panel to confirm the paper type and size:
7. If you have not changed the type or size of paper, press the OK button to accept the current
setting for paper type and size.
8. If you have changed the paper type:
a. At the printer’s front panel, select Change, then press the OK button.
b. Select the appropriate paper type.
c. Press the OK button to save your selection.
9. If you have changed the paper size:
a. Select the appropriate paper size.
b. Press the OK button to save your selection.
Note
For more information about printing options and other selections, click the Help button on
the printer driver tab to view the online help.
6250-036
Basic Printing
Phaser® 6250 Color Laser Printer
2-17
Factors Affecting Printer Performance
Many factors affect a print job. They include the print speed (stated in number of pages per
minute), the media used, download time, and printer processing time.
The computer download time and printer processing time are affected by several factors
including:
■Printer memory
■Connection type (network, parallel or USB)
■Network operating system
■Printer configuration
■File size and type of graphics
■Computer speed
Note
Additional printer memory (RAM) may improve overall printer functions, but will not
increase the pages per minute (ppm) ability of the printer.
