Philips AZ5160/98 Manuale operativo

1 Choosing Power Supply

aConnect the AC power cord to the

AC~ Mains inlet and the wall socket.

-OR-

bOpen the battery door and insert 6

x C batteries (not included).

Å

90

33

22 2

Quick Use

Guide

Quick Use

Guide

Å

90

33

22 2

2 Listening to the Radio

aPush the source selector to

TUNER

.

b Adjust

BAND

to

MW

or

FM

.

cTurn TUNING to tune to a

station.

3 Playing a disc

This player plays Video CD,Audio

Discs including CD-R/CD-RW,

and MP3-CD.

For VCD playback:

•Connect the VIDEO OUT jack to

the video input jack on the TV

using the supplied video cable

(yellow).

•Turn on the TV and set it to the

correct Video In channel.

aAdjust the source selector to

CD.

bOpen the disc door.

cInsert a disc with the printed side

facing up and close the door.

dPress 38 to start playback.

eTo stop disc playback, press 9.

AZ5160

R-14,UM-2 or C-cells

(not included)

4 Playing a tape

aAdjust the source selector to TAPE/OFF.

bPress

9

/to open the cassette holder.

cInsert a cassette and close the door.

dPress

1

to start playback.

eTo stop the tape, press

9

/.

VIDEO

OUT

AUDIO

OUT AUDIO INVIDEO IN

2 x AAA R03

38

Press to start or pause

disc playback

Source selector

Slide to select

function: CD,Tuner

(FM/MW), or tape

VOLUME

Turn to adjust

volume level

TUNING

Turn to tune to a

station

LIFT TO OPEN

Lift to open the disc

door

9

Press to stop disc

playback, or erase a disc

program

DBB

T

urns the bass

enhancement on/off

∞,§

Briefly press to skip to the

beginning of the current /

previous / later disc track;

During disc playback, press

and hold to find a particular

passage backward/forward.

BAND

Switch to FM/MW band

Display

Shows disc functions

REPEAT

Press to select REPEAT

mode

CASSETTE

RECORDER keys

Press to operate a tape

VIDEO/AUDIO OUT

Connects to the VIDEO/AUDIO IN

on the

TV or VCR

AZ5160_QSG 2007.7.13 10:25 Page 1
