Philips DS1155/98 Manuale utente
www.philips.com/welcome
User manual
Always there to help you
Register your product and get support at
DS1155/98
Question?
Contact
Philips
1EN
Contents
1 Important 2
Safety 2
2 Your Docking Speaker 3
Introduction 3
What's in the box 3
Overview of the main unit 3
3 Get started 4
Connect power 4
Adjust time 4
Turn on 4
4 Play 5
Play from iPod/iPhone 5
Charge your mobile phone 5
Adjust volume 6
Adjust brightness 6
5 Product information 7
Specications 7
6 Troubleshooting 8
7 Notice 9
Disposal of your old product 9
2EN
1 Important
Safety
Important Safety Instructions
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or
otherapparatus(includingampliers)that
produce heat.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
• Onlyuseattachments/accessoriesspecied
by the manufacturer.
• Unplug this apparatus during lightning
storms or when unused for long periods
of time.
• Referallservicingtoqualiedservice
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
• Apparatus shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on the
apparatus(e.g.liquidlledobjects,lighted
candles).
• Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.
Warning
•Never remove the casing of this apparatus.
•Never lubricate any part of this apparatus.
•Never place this apparatus on other electrical
equipment.
•Keep this apparatus away from direct sunlight, naked
amesorheat.
•Make sure that you always have easy access to the
power cord, plug, or adaptor to disconnect the
apparatus from the power.
3EN
2 Your Docking
Speaker
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this docking speaker, you can:
• set time;
• enjoy audio from your iPod/iPhone.
What's in the box
Check and identify the contents of your
package:
• Main unit
• 1 x AC adaptor
• Short user manual
Overview of the main unit
a
b
g
f
e
d
c
a Dock for iPod/iPhone
b
• Adjust brightness of bottom light.
c CLOCK
• Adjust brightness of the display.
• Press and hold to set the clock.
d
• Charge your mobile phone through a
USB cable.
e DC IN
• Connect AC power.
f Display
g /
• Adjust volume.
4EN
3 Get started
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of this apparatus.The
model number and serial number are on the
bottom of the apparatus.Write the numbers
here:
Model No. __________________________
Serial No. ___________________________
Connect power
Caution
•Risk of product damage! Make sure that the power
supply voltage corresponds to the voltage printed on
the back of the unit.
•Risk of electric shock! When you unplug the AC
adaptor, always pull the plug from the socket. Never
pull the cord.
•Before connecting the AC adaptor, make sure that you
have completed all other connections.
Adjust time
1 In standby mode, press and hold CLOCK
to enter the clock setting mode.
» [24H] or [12H] hour format is
displayed.
2 Press +/- to select [24H] or [12H] hour
format, and then press CLOCK.
» The hour digits are displayed and begin
to blink.
3 Press +/- to set hour, and then press
CLOCK.
» The minute digits are displayed and
begin to blink.
4 Repeat step 3 to set minute.
Turn on
In standby mode, the docking speaker turns on
automatically when it detects an audio signal
from docked iPod/iPhone.
Switch to standby mode
The unit switches to standby mode if there is
no audio signal from docked iPod/iPhone over
15 minutes.
5EN
4 Play
Play from iPod/iPhone
You can enjoy audio from iPod/iPhone through
this docking speaker.
Compatible iPod/iPhone
The docking speaker supports the following
iPod/iPhone models.
Made for:
• iPhone 5
• iPodnano(7thgeneration)
• iPodtouch(5thgeneration)
Load the iPod/iPhone
Insert your iPod/iPhone into the dock.
» The docking speaker synchronizes time
from the docked iPod/iPhone.
To remove the iPod/iPhone:
• Pull your iPod/iPhone out of the dock.
Listen to the iPod/iPhone
Note
•Make sure that the iPod/iPhone is loaded correctly.
Start to play music from your iPod/iPhone.
» Music streams from the docking
speaker automatically.
Charge the iPod/iPhone
The docked iPod/iPhone begins to charge
automatically after connected to power.
Charge your mobile phone
You can charge your mobile phone through the
USB socket in this device with a USB cable (not
supplied)
6EN
Adjust volume
During play, press +/- repeatedly to increase or
decrease the volume.
Adjust brightness
• Press CLOCK repeatedly to select
different levels of display brightness.
• Press repeatedly to select different
levels of bottom light brightness.
7EN
5 Product
information
Note
•Product information is subject to change without prior
notice.
Specications
Amplier
Rated Output Power 2 x 3 W
RMS
Signal to Noise Ratio 77 dBA
General information
AC power adaptor Model: OH-
1018A0592400U
(Philips)
Input: 100-240 V, 50/60
Hz, 650 mA;
Output: 5.9 V 2400
mA;
Operation Power
Consumption
18 W
Charging(USB) ≤500mA
Dimensions: Main
Unit(WxHxD)
177 x 177 x 100 mm
Weight: Main Unit 0.88 kg
8EN
6 Troubleshooting
Warning
•Never remove the casing of this device.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips Web page (www.
philips.com/support).WhenyoucontactPhilips,
make sure that the device is nearby and the
model number and serial number are available.
No power
•Make sure that the AC power plug of the
unit is connected properly.
•Make sure that there is power at the AC
outlet.
No sound or poor sound
•Adjust the volume of your docking speaker.
•Adjust the volume of your iPod/iPhone or
external audio device.
No response from the unit
•Disconnect and reconnect the AC power
plug, and then turn on the docking speaker
again.
