Philips SHB5250BK Manuale utente

Philips

Bluetooth Headset

14.2mm drivers/ open-back

Earbud

Flat cable

SHB5250BK

Wireless freedom, powerful sound

Designed to fit ear geometry

Designed for wireless freedom on the go, these Philips MyJam FreshTones BT earphones

feature 14.2mm drivers for big bass and optimal fit designed around ear geometry.

Revel in quality sound

• 14.2mm speaker drivers for powerful sound and rich bass

• Powerful magnets enhance bass performance

Listen for longer

• Designed to fit ear geometry comfortably

• Tangle-free flat cable for convenience on the go

• Bluetooth version 4.1 and HSP/HFP/A2DP/AVRCP Support

Always ready to go

• Flex-grip cable relief enhances durability and connectivity

• Wireless control for music enjoyment and calls

Highlights

SHB5250BK/27

Bluetooth Headset

14.2mm drivers/ open-back Earbud, Flat cable

Specifications

Flex-grip cable relief

Using a rubberized Flex-grip cable relief between the

headphones and the cable, the connection is protected

from damage through repeated bending extending its

life.

Geometric comfort fit

A design based on ear geometry creates a

comfortable, snug fit for everyone.

Large speaker drivers

Quality 14.2mm speaker drivers with a bass vent

design on the earphones for rich bass.

Powerful magnets

Powerful magnets enhance bass performance

Supports Bluetooth version 4.1

Pair your smart device with your headphones using

Bluetooth and enjoy the freedom of crystal clear music

and phone calls - without the hassle of cables.

Tangle-free flat cable

Flat cable ensures that your cord stays smooth and

tangle free - always.

Wireless music and calls

Enjoy the freedom of listening to music and phone calls

- without the hassle of a cable. Change tracks, volume

control, and answer calls with an easy to use remote

control.

Design

• Color: Black

Sound

• Acoustic system: open

•Impedance:32ohm

• Maximum power input: 30 mW

• Sensitivity: 107 dB

• Speaker diameter: 14.2 mm

• Frequency response: 8 - 24 000 Hz

Connectivity

• Bluetooth profiles: A2DP, AVRCP, HFP, HSP

• Bluetooth version: 4.1

• Maximum range: 10 m

Power

• Talk time: 4.5* hours

• Battery weight: 2.5 g

•Batterytype:Li-Polymer

• Music playtime: 4.5* hr

• Standby time: Up to 55 hr

Convenience

• Call management: Answer / End call

•Volumecontrol

Outer Carton

• Gross weight: 0.584 lb

• Gross weight: 0.265 kg

• GTIN: 1 08 89446 00572 8

•Outercarton(Lx W x H): 19 x 9.5 x 13.3 cm

•Outercarton(Lx W x H): 7.5 x 3.7 x 5.2 inch

• Nett weight: 0.192 lb

• Nett weight: 0.087 kg

• Number of consumer packagings: 3

• Tare weight: 0.178 kg

• Tare weight: 0.392 lb

Packaging dimensions

• Packaging dimensions (W x H x D):

9.5 x 17.5 x 2.5 cm

• Packaging dimensions (W x H x D):

3.7 x 6.9 x 1.0 inch

• Gross weight: 0.067 kg

• Gross weight: 0.148 lb

• Nett weight: 0.064 lb

• Nett weight: 0.029 kg

• Number of products included: 1

• Packaging type: Carton

• Tare weight: 0.084 lb

• Tare weight: 0.038 kg

• Type of shelf placement: Both

• UPC: 8 89446 00572 1

Product dimensions

• Product dimensions (W x H x D):

1.6 x 3.1 x 0.8 inch

• Product dimensions (W x H x D): 4 x 8 x 2 cm

• Weight: 0.031 lb

• Weight: 0.0142 kg

•

Issue date 2017-08-27

Version: 6.0.4

12 NC: 8670 001 34757

UPC: 8 89446 00572 1

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com * Actual results may vary

www.philips.com/support

User manual

Always there to help you

SHB5250

Question?

Contact

Philips

1EN

Contents

1 Important safety instructions 2

Hearing Safety 2

General information 2

2 Your Bluetooth in-ear headphones 3

What's in the box 3

Other devices 3

Overview of your Bluetooth in-ear

headphones 3

3 Get started 4

Charge your headphones 4

Pair the headphones with your mobile

phone 4

4 Use your headphones 5

Connect the headphones to a

Bluetooth device 5

Manage your calls and music 5

5 Technical data 7

6 Notice 8

Notice of compliance 8

Disposal of your old product and battery 8

Trademarks 9

7 Frequently asked questions 10

2EN

1 Important safety

instructions

Hearing Safety

Danger

• To avoid hearing damage, limit the time you use

headphones at high volume and set the volume to a

safe level.The louder the volume, the shorter the safe

listening time is.

Be sure to observe the following guidelines

when using your headset.

• Listen at reasonable volumes for

reasonable periods of time.

• Be careful not to adjust the volume

continuously upwards as your hearing

adapts.

• Do not turn up the volume so high that

you can’t hear what’s around you.

• You should use caution or temporarily

discontinue use in potentially hazardous

situations.

• Excessive sound pressure from earphones

and headphones can cause hearing loss.

• Using headphones with both ears covered

while driving is not recommended and may

be illegal in some areas while driving.

• For your safety, avoid distractions from

music or phone calls while in trafc or

other potentially dangerous environments.

General information

To avoid damage or malfunction:

Caution

• Do not expose headphones to excessive heat.

• Do not drop your headphones.

• Headphones shall not be exposed to dripping or

splashing.

• Do not allow your headphones to be submerged in

water.

• Do not use any cleaning agents containing alcohol,

ammonia, benzene, or abrasives.

• If cleaning is required use a soft cloth, if necessary

dampened with a minimum amount of water or diluted

mild soap, to clean the product.

• The integrated battery shall not be exposed to

excessive heat such as sunshine, re or the like.

• Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

About operating and storage temperatures

and humidity

• Operate or store in a place where

temperature is between -15ºC (5ºF) and

55ºC (131ºF) (up to 90% relative humidity.

• Battery life may be shorter in high or low

temperature conditions.

3EN

2 Your Bluetooth

in-ear

headphones

Congratulations on your purchase, and

welcome to Philips! To fully benet from the

support that Philips offers, register your product

at www.philips.com/welcome.

With this Philips wireless in-ear headphones,

you can:

• enjoy convenient wireless handsfree calls;

• enjoy and control wireless music;

• switch between calls and music.

What's in the box

Philips Bluetooth in-ear headphones SHB5250

USB charging cable (for charging only)

Quick start guide

Other devices

A mobile phone or device (e.g. notebook, PDA,

Bluetooth adapters, MP3 players etc) which

supports Bluetooth and is compatible to the

headphones (see 'Technical data' on page 7).

Overview of your Bluetooth

in-ear headphones

a Volume/Track control button

b Micro USB charging slot

c LED indicator

d On/off, music/call control button

e Microphone

4EN

3 Get started

Charge your headphones

Note

• Before you use your headphones for the rst time,

charge the battery for 5 hours for optimum battery

capacity and lifetime.

• Use only the original USB charging cable to avoid any

damage.

• Finish your call before charging the headphones, as

connecting the headphones for charging will power the

headphones off.

• You can operate the headphones normally during

charging.

Connect the supplied USB charging cable to:

• the micro USB charging slot on the

headphones and;

• the charger/USB port of a computer.

» LED turns white during charging and

turns off when the headphones is fully

charged.

Tip

• Normally, a full charge takes 2 hours.

Pair the headphones with

your mobile phone

Before you use the headphones with your

mobile phone for the rst time, pair it with a

mobile phone. A successful pairing establishes a

unique encrypted link between the headphones

and mobile phone.The headphones store the

last 4 devices in the memory. If you try to pair

more than 4 devices, the earliest paired device

is replaced by the new one.

1 Make sure that the headphones are fully

charged and turned off.

2 Press and hold the on/off button until the

blue and white LED ashes alternately.

» The headphones remain in pairing

mode for 5 minutes.

3 Make sure that the mobile phone is turned

on and its Bluetooth feature is activated.

4 Pair the headphones with the mobile

phone. For detailed information, refer to

the user manual of your mobile phone.

The following example shows you how to pair

the headphones with your mobile phone.

1 Activate the Bluetooth feature of your

mobile phone, select Philips SHB5250.

2 Enter the headset password "0000" (4

zeros) if prompted. For those mobile

phones featuring Bluetooth 3.0 or higher,

no need to enter a password.

Settings

Devices Found

Select

10:36

Settings Connectivity

Select

Back

10:37

Enter Password

****

0000

Settings

Bluetooth

Select

Back

10:35

Connectivity

Add

Bluetooth

device

Back

Philips SHB5250

5EN

4 Use your

headphones

Connect the headphones to a

Bluetooth device

1 Turn on your mobile phone/Bluetooth

device.

2 Press and hold the on/off button to turn

the headphones on.

» The blue LED ashes.

» The headphones are reconnected

to the last connected mobile phone/

Bluetooth device automatically. If

the last one is not available, the

headphones try to reconnect to the

second last connected device.

Tip

• If you turn on the mobile phone/Bluetooth device or

activate the Bluetooth feature after turning on the

headphones, you have to reconnect the headphones

and mobile phone/Bluetooth device manually.

Note

• If the headphones fail to connect to any Bluetooth

device within range in 5 minutes, it will switch off

automatically to save the battery life.

Manage your calls and music

On/off

Task Button Operation

Turn the

headphones

on.

On/off,

music/call

control

Press and hold for 2

seconds.

Turn the

headphones

off.

On/off,

music/call

control

Press and hold for 4

seconds.

» The white

LED is on

and fades

out.

Music control

Task Button Operation

Play or pause

music.

On/off,

music/call

control

Press once.

Adjust volume. +/-Press once.

Skip forward. +Long press.

Skip backward. -Long press.

Call control

Task Button Operation

Pick up/hang

up a call.

On/off, music/

call control

Press once.

» 1 beep.

Switch caller

during a call.

On/off,

music/call

control

Press twice.

» 1 beep.

Other headphones indicator status

Headphones status Indicator

The headphones

are connected

to a Bluetooth

device, while the

headphones in

standby mode

or while you are

listening to music.

The blue LED ashes

for every 8 seconds.

The headphones are

ready for pairing.

The LED ashes blue

and white alternately.

The headphones are

on but not connected

to a Bluetooth device.

The blue LED ashes

quickly.

If no connection

can be made, the

headphones will turn

itself off within 5

minutes.

6EN

Low battery level. The white LED ashes

3 times for every 10

seconds until it is out

of power.

Battery is fully

charged.

White LED is off.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Philips Cuffie

Philips

Philips 2000 series Manuale utente

Philips

Philips SHG5100 Manuale utente

Philips

Philips SHE9503 Manuale utente

Philips

Philips SHC1300/00 Guida di riferimento

Philips

Philips SHC2000 Manuale utente

Philips

Philips SHB9250/00 Manuale utente

Philips

Philips SBCHC8300/05 Manuale utente

Philips

Philips SHE9500 Manuale utente

Philips

Philips O'Neill THE SPECKED SHO9551 Manuale utente

Philips

Philips TAH6506 Manuale utente

Philips

Philips UpBeat SHB2505 Manuale utente

Philips

Philips TAT2206WT/00 Manuale utente

Philips

Philips SPACE SWS4000/00 Manuale utente

Philips

Philips SHQ7900CL/00 Manuale utente

Philips

Philips TAA5205BK/00 Manuale utente

Philips

Philips TAT1138BK/97 Manuale utente

Philips

Philips Nike Sport SHJ066 Manuale utente

Philips

Philips SHE9551 Manuale utente

Philips

Philips PN402 Manuale utente

Philips

Philips SBCHN060/00 Manuale utente

Philips

Philips SHB5100 Manuale utente

Philips

Philips SHJ030 Manuale utente

Philips

Philips ActionFit SHQ4200 Manuale utente

Philips

Philips 8000 Series Manuale utente

Manuali Cuffie popolari di altre marche

Sony

Sony MDR-NC8 Manuale utente

AUSounds

AUSounds AU-Stream Manuale utente

ENERGY SISTEM

ENERGY SISTEM Style 7 Manuale utente

Insignia

Insignia NS-CAHBTSPORT Manuale utente

Movie Vision

Movie Vision HP-400 Manuale utente

MobiFren

MobiFren SM Pro Manuale utente

Motorola solutions

Motorola solutions PMLN8120 Manuale utente

Jaybird

Jaybird freedom Guida all'installazione

Sony

Sony MDR-ED12LP Manuale utente

HiFuture

HiFuture Tidy Buds Pro Manuale utente

Creative

Creative CB2530 Manuale utente

Renkforce

Renkforce RF FTVK-100 Manuale utente

Sennheiser

Sennheiser 500371 Manuale utente

Califone

Califone 2924AV Manuale utente

Technics

Technics EAH-AZ80 Manuale utente

Bose

Bose On-Ear Headphone Manuale d'uso e manutenzione

Aluratek

Aluratek ABH02F Manuale utente

Waterfi

Waterfi swimQ Manuale utente
