EL2 Series

6 V, 12 W ARCHITECTURAL EMERGENCY LIGHTING

Page 1 of 2

Job Information Type:

Job Name:

Cat. No.:

Notes:

Features

Illumination: Two rotatable

reflector assemblies with

adjustable beam patterns. Unit

includes 6 VDC, 6 W halogen

lamps housed in impact-

resistant lamp covers*.

* Replacement lamping: No. 784, T2.25,

G-4 two pin base, 6 V, 6 W miniature

lamp.

Housing: Impact-resistant,

injection-molded UL 94-5VA

flame retardant thermoplastic

housing. UV-stabilized to resist

discoloration. White finish is

standard, black is optional. Unit

is ceiling or wall mountable.

Battery: Maintenance free,

sealed nickel metal hydride

battery with 10 year life.

NiMH battery is a non-toxic,

environmentally friendly

product which is recyclable.

Electronics: 120/277

VAC dual voltage input.

Microprocessor controlled

charge, transfer, and

monitoring system. Charging

system is complete with

low voltage disconnect,

AC lockout, and brownout

protection. Includes an AC

indicator/systems status lamp

and manual test switch.

Self-Testing Diagnostics

(standard): Unit runs an

internal test every five seconds

for secondary voltage, charge

current, battery voltage, and

LED illumination. Performs

automatic 1 minute discharge

test every 30 days and

30 minute discharge test

every 180 days meeting and

exceeding UL 924 and NFPA

101 requirements. The infrared

option allows a remote control

to initiate a 5 second and 30

minute self-test in addition to

the standard 1 minute and 90

minute manual test capability.

Electrical Specifications:

(120 VAC) .103 A, 11.3 W

(277 VAC) .044 A, 11.6 W

Code Compliance

UL 924 listed. NFPA 101

illumination standards.

Warranty

Three year full electronics

warranty. Five year full plus

five year prorated battery

warranty.

EL2WN

6.4"

(16.3 cm)

2.5"

(6.4 cm)

6.7"

(17.0 cm)

EL2 Series

6 V, 12 W ARCHITECTURAL EMERGENCY LIGHTING

Page 2 of 2

Philips Lightolier

e: [email protected]

t: (508) 679-8131

w: www.lightolier.com

EL2 Series September 19, 2011

Specifications are subject to change without notice.

Job Information Type:

Ordering Information

Series

EL2 = Thermoplastic

Emergency Unit

Note

1) For use with remote control which is ordered separately.

I= Infrared Remote Sensor1

TD = Time Delay

Factory Installed Options

Accessories (order as a separate item)

IREMOTE = Infrared Remote Control

EL2

W= White

B= Black

Housing Color

N= NiMH

Battery
