Philips MCM166/05 Manuale utente

MCM166

What’s in the Box?

You should nd these items upon opening the box.

Quick Start Guide

Remote Control

Quick Start Guide User Manual

1 x MP3 link cable

MCM166_05_QSG_Eng.indd 1 9/28/2009 11:05:39 AM

1

2

Connect the speaker cables.

Speaker

(right)

Speaker

(left)

FM antenna

AC power

Tip

See the User Manual on how to

connect other equipment to this

system.

Connect the AC power cord to the wall

socket.

5

3

7

6

4

2

Set clock

1

Press and hold CLOCK (or CLOCK/DISPLAY on the remote control) to activate the clock

setting mode.

The 12 hour or 24 hour format is displayed.

«

Press PROG repeatedly to select 12 hour or 24 hour format.

Press CLOCK (or CLOCK/DISPLAY on the remote control) to conrm.

The hour digits are displayed and begin to blink.

«

Press §/ ∞ (or 5/ 6 on the remote control) to set the hour.

Press CLOCK (or CLOCK/DISPLAY on the remote control) to conrm.

The minute digits are displayed and begin to blink.

«

Press §/ ∞ (or 5/ 6 on the remote control) to set the minute.

Press CLOCK (or CLOCK/DISPLAY on the remote control) to conrm.

MCM166_05_QSG_Eng.indd 2 9/28/2009 11:05:40 AM

4

3

2

1

Play disc

Press SOURCE (or DISC on the remote control) to select the disc source.

Lift the top panel to open the disc tray.

Insert a disc with the printed side facing up, then close the disc tray.

Press ÉÅ to start play.

To stop play, press 9.

5

1

2

3

Insert the USB device’s USB plug into the socket on the main unit.

Press SOURCE once or more (or USB on the remote control) to select USB.

Play the USB’s audio les as you do with the albums/tracks on a CD.

Play USB

With the Hi-Fi system, you can use USB ash memory (USB 2.0 or USB1.1),

USB ash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

MCM166_05_QSG_Eng.indd 3 9/28/2009 11:05:41 AM

1

2

3

Press SOURCE (or TUN on the remote control) repeatedly to select FM or MW.

Press PROG for more than two seconds to program all available stations in order of wave-

band.

Press PRESET/ALBUM +/- (or ABL/PRESET +/- on the remote control) to select a preset

number.

Listen to radio

MCM166_05_QSG_V1.0

Tip

Detailed play features and additional functions are described in the supplied user

manual.

C Royal Philips Electronics N.V. 2009

All rights reserved.

http://www.philips.com

MCM166_05_QSG_Eng.indd 4 9/28/2009 11:05:41 AM
