Philips Essence 5000 Series Manuale utente

DAB+ radio

Your FM/DAB radio

the main unit

Adjust the volume level

Kitchen Timer

Sleep Timer

Your FM/DAB radio

FM/DAB radio

Warranty leaflet

Quick start guide

Overview of the main unit

INFO/MENU

SCAN/SELECT

Preset stations (1, 2, 3)

Press to display information in

FM/DAB mode.

In working mode, press and hold

to access the top menu.

In Bluetooth mode : Press to skip to

the previous track .

In Tuner mode :Tune to a radio station

Navigate through the menu list .

In Bluetooth mode : Press to skip to

the next track .

In Tuner mode :Tune to a radio station

Navigate through the menu list .

auto scan

Connect to the supplied power adaptor .

Store /directly access preset 1, 2, or 3.

Display and select preset stations.

Option 1:AC power

You can use this radio player on AC power

or battery power.

Turn -VOL + repeatedly to adjust volume.

To increase battery life, you can turn off the unit

completely by press and hold button . Press and

hold button again to turn on the set again.

Adjust the volume level

Switch to standby mode

Turn on

Option 2: Battery power

Caution

• Batteries (battery pack or batteries installed) shall not

be exposed to excessive heat such as sunshine, or

the like.

• Danger of explosion if battery is incorrectly replaced.

Replace only with the same equivalent type.

• Do not mix batteries (old and new or carbon and

alkaline, etc.).

• Remove batteries if they are exhausted or if the unit is

not to be used for a long time.

1 Open the battery compartment at the

back of the unit.

2 Insert four R14/UM-2/C size batteries

(not supplied) with correct polarity

(+/-) as indicated, then close the battery

compartment.

The unit is ready to operate.

Caution

• A 'Battery low' Icon is shown when the battery

power is low. Replace batteries or connect to AC

power to ensure normal operation.

Note

•

Batteries contain chemical substances, so they should

be disposed of properly.

You can store a maximum of 20 preset DAB radio

stations.

At step 2, you can also press and hold preset key 1, 2 or

3 to save the current station to the corresponding

position directly.

To remove a preset DAB radio station, store another

station in its place.

Press the numeric key 1-3 directly.

set kitchen timer.

[ Clock ] : set time/date, select 12/24 hour,

and set time synchronization.

set sleep timer.

adjust backlight settings

adjust system settings:

Radio mode

Kitchen timer

Sleep timer

Dynamic Label Segment (DLS)

Signal strength

Program type (PTY)

Ensemble name

Frequency

Signal error rate

Bit rate and audio status

Time

Date

(3 options :Time out/ On level/ Dim level)

[ Language ] : set system language

(English/ Deutsch/ Italiano/ Francais/

Nederlands/ Norwegian)

[ System ] :

[ Backlight ] :

[ Sleep ] :

[ Prune ] :

[ DRC ] :

[ Manual tune ] :

[ Full scan ] :

[ Kitchen Timer ] :

[ Factory Reset ] : reset the unit.

[ SW version ] : view software version.

To store FM radio stations automatically

In FM mode, you have two ways to select a

preset radio station.

Option B:

Press the numeric key 1-3 directly.

Option A:

Radio mode

Kitchen timer

Sleep timer

Radio text messages

Program type

Frequency

Time

Date

While listening to FM radio, press

set kitchen timer.

[ Clock ] : set time/date, select 12/24 hour,

and set time synchronization

set sleep timer.

adjust backlight settings

adjust system settings:

(3 options :Time out/ On level/ Dim level)

[ Language ] : set system language

(English/ Deutsch/ Italiano/ Francais/

Nederlands/ Norwegian)

[ System ] :

[ Backlight ] :

[ Sleep ] :

[ Scan setting ] :

[ Kitchen Timer ] :

[ Factory Reset ] : reset the unit.

[ SW version ] : view software version.
