Philips AZ330T Manuale utente

User manual

Always there to help you

www.philips.com/support

AZ330T

Question?

Contact

Philips

1EN

Contents

1 Important 2

Safety 2

Notice 2

2 Your CD Soundmachine 4

Introduction 4

What's in the box 4

Overview of the main unit 5

3 Get started 7

Connect power 7

Turn on 8

Turn off 8

4 Play 9

Play a CD 9

Play from USB devices 9

Tune to FM radio stations 10

Play from Bluetooth-enabled devices 10

Play from an external device 11

5 Play options 12

Control play 12

Program tracks 12

Adjust sound 12

6 Product information 13

Specications 13

Supported MP3 disc formats 14

USB playability informatio 14

Maintenance 14

7 Troubleshooting 15

About Bluetooth device 15

2EN

1 Important

Safety

• Read these instructions.

• Follow all instructions.

• Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or

otherapparatus(includingampliers)that

produce heat.

• Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the unit.

• Onlyuseattachments/accessoriesspecied

by the manufacturer.

• Unplug this unit during lightning storms or

when unused for long periods of time.

• Recording is permissible insofar as

are not infringed upon.

• Referallservicingtoqualiedservice

personnel. Servicing is required when the

unit has been damaged in any way, such

as power-supply cord or plug is damaged,

liquid has been spilled or objects have

fallen into the apparatus, the unit has been

exposed to rain or moisture, does not

operate normally, or has been dropped.

• Battery usage CAUTION –To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

unit:

• Install all batteries correctly, + and - as

marked on the unit.

• Do not mix batteries (old and new or

carbonandalkaline,etc.).

• Remove batteries when the unit is not

used for a long time.

• Batteries (battery pack or batteries

installed)shallnotbeexposedtoexcessive

heatsuchassunshine,reorthelike.

• CAUTION: Danger of explosion if battery

is incorrectly replaced. Replace only with

the same or equivalent type.

• The unit shall not be exposed to dripping

or splashing.

• Do not place any sources of danger on

theunit(e.g.liquidlledobjects,lighted

candles).

• Where the MAINS plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

•Never remove the casing of this apparatus.

•Never place this apparatus on other electrical

equipment.

•Never look into the laser beam inside this apparatus.

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

Notice

Anychangesormodicationsmadetothis

device that are not expressly approved by

WOOX Innovations may void the user’s

authority to operate the equipment.

Compliance

Anychangesormodicationsmadetothis

device that are not expressly approved by

3EN

WOOX Innovations may void the user’s

authority to operate the equipment. Hereby,

WOOX Innovation declares that this product is

compliance with the essential requirements and

other relevant provisions of Directive 1999/5/

EC.YoucanndtheDeclarationofConformity

on www.philips.com/support.

Care of the environment

Disposal of your old product

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

This symbol on a product means that the

product is covered by European Directive

2012/19/EU. Inform yourself about the local

separate collection system for electrical and

electronic products. Follow local rules and never

dispose of the product with normal household

waste. Correct disposal of old products

helps prevent negative consequences for the

environment and human health.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separateintothreematerials:cardboard(box),

paperpulp(buffer)andpolyethylene(bags,

protectivefoamsheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and old

equipment.

Trademark notice

The making of unauthorized copies of copy-

protected material, including computer

programs,les,broadcastsandsound

recordings, may be an infringement of

copyrights and constitute a criminal offence.

This equipment should not be used for such

purposes.

The USB-IF Logos are trademarks of Universal

Serial Bus Implementers Forum, Inc.

The Bluetooth® word mark and logos are

registered trademarks owned by Bluetooth

SIG, Inc. and any use of such marks by WOOX

Innovations is under license.

This apparatus includes these labels:

Class II equipment symbol

This symbol indicates that the apparatus has a

double insulation system.

Note

•The type plate is located on the bottom of the

apparatus.

4EN

2 Your CD

Soundmachine

Introduction

With this CD Soundmachine, you can:

• Listen to FM radio;

• Enjoy audio from discs, USB device,

Bluetooth devices, and other external

audio devices;

• Program the play sequence of tracks.

What's in the box

Check and identify the contents of the package:

• Main unit

• Power cord

• Short User Manual

• Safety sheet

5EN

Overview of the main unit

a CD/USB source selector

• Press to select CD or USB source.

• Stop playing.

c - ALBUM +

• Skip to the previous or next album.

nm o

BT FM OFF

CD/USB

d /

• Skip to the previous or next track.

• Search within a track.

e OPEN•CLOSE

• Open or close the disc compartment.

6EN

f Bluetooth indicator

• Indicate the status of Bluetooth

connection.

g /PAIRING

• Start or pause play.

• Press to wake up the unit from

standby mode.

• Press and hold to disconnect the

connected Bluetooth device and enter

pairing mode.

h PROG

• Program the play sequence of tracks.

i MODE

• Select a play mode.

j Display panel

• Display current status.

k FM antenna

• Improve FM reception.

l + TUNING -

• Tune to FM radio stations.

• USB socket.

n Source selector

• Select a source.

o + VOLUME -

• Adjust volume.

p AUDIO-IN

• Connect an external audio device.

q AC MAINS

7EN

3 Get started

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in

sequence.

If you contact Philips, you will be asked for the

model and serial number of your apparatus.The

model number and serial number are on the

bottom of your apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Connect power

The unit can be powered by either AC power

or batteries.

Option 1:AC power

Warning

•Risk of product damage! Make sure that the power

supply voltage corresponds to the voltage printed on

the back or the underside of the unit.

•Risk of electric shock! When you disconnect the AC

power, always pull the plug from the socket. Never pull

the cord.

Connect the AC power cord to the wall socket.

Tip

•To save energy, turn the unit off after use.

Option 2: Battery power

Caution

•Batteries contain chemical substances, so they should

be disposed of properly.

Note

•Batteries are not supplied with the accessories.

1 Open the battery compartment.

2 Insert 6 batteries (type: 1.5V R14/UM2/C

CELL)withcorrectpolarity(+/-)as

indicated.

3 Close the battery compartment.

AC~MAINS

8EN

Turn on

Switch the source selector to CD/USB/BT/FM.

Switch to standby mode

• The product switches to standby mode

automatically when there is no audio

detected for over 15 minutes.

• Press to wake up the product from

standby mode.

Turn off

Switch the source selector on the product to

OFF.
