Philips CDR930 Manuale utente

Audio CD-Recorder

CDR 930

Philips Mini component CD-Recorder CDR 930

• AD - DA convertor UDA1341TS (CODEC)

• Sample Rate Conversion (12-56 kHz)

• Direct Line Recording (DLR)

• Records HQ-CD format

• Analogue + digital (separate channel) record level control (64 steps)

• Continuous calibration (Running OPC)

• 2x CD text features (input & editing for max. 60 characters)

• Max. 99-track program

• CD Synchronised auto start recording from

all analogue and digital sources (disc & track)

• Text scrolling

• Standby (via RC) + hard on/off

• Music calendar

• Easy jog (Menu controlled user interface)

• High quality starbust FTD (display)

• Auto (un) finalise

• Erasing per track, selection of last tracks & whole disc

(takes max. 2 min.)

• Introscan

• Tray blocking (dealer function)

• Integrated remote control FW930R

• Digital coaxial connection to FW930R

Audio CD-Recorder

CDR 930

700+ series CD player

Technical Specifications CDR 930

General

• System Compact disc digital Audio (CD-recorder)

• Number of channels 2 (stereo)

• Applicable supply Multi voltage 100V -240V 50-60 Hz (/00 only) 117V (/17)

• Power consumption 15W (<= 6W in standby)

• Operating temperature 5-35°C

• Weight 4 kg

• Dimensions 264 x 305 x 86 mm (w x d x h)

Audio

• Digital frequency range 2 Hz - 22,05 kHz

• Playback S/N 100 dB (A- weighted)

• Playback dynamic range 95 dB

• Play back total harmonic distortion

+ noise 91 dB (0,0039%)

• Recording S/N (Analogue) 98 dB (A- weighted)

• Recording S/N (Digital) Recording quality equal to Source

• Recording dynamic range 92 dB

• Recording total harmonic distortion

+ noise 85 dB (0,0079%)

Output

• 1x Analogue line output 2Vrms +/- 2 dB / 0.2 kΩ

• 1x Digital coaxial output 0.5V(pp) / 75Ω

Input (level adjustment)

• Direct line recording (bypass SRC) for 44.1 kHz +/- 100 ppm

• 1x Digital coaxial input (SRC) 12 - 56 kHz / 0.5Vrms / 75Ω

• 1x Digital optical input (SRC) 12 - 56 kHz

• 1x Analogue input 500 mVrms / 50 kΩ= 0 dB

Recording functions

• Recording on CD-R & CD-RW disc

• Records from all home stereo analogue and digital sources

• Auto start recording per disc, track

• Soft mute insert function

• Multi track erase (CD-RW disc)

• Erase disc (CD-RW disc)

• Auto finalise / unfinalise disc (CD-RW disc)

• Manual / Auto track increment

• Remaining recording time display

• Double speed finalising (make disc compatible to CD-player)

• SCMS (Serial Copy management system)

• RID code (Recorder Unique identifier)

Playback functions

• Plays all Audio CD’s

(120 mm + 80 mm discs)

• Play - Introscan - Pause - Stop

• Direct track selection

• Track selection with easy jog

• Search forward / reverse

• Repeat (all / per track)

• Program play (99 tracks)

• Time display switching

• Permanent text option

The products and services described here are not necessarily to become available in the market. This document contains preliminary information. Due to continuous improvements this specification is subject to changes without notice. Printed in the Netherlands. 2/99

Accessories

• Remote control + batteries

(DR570 only)

• Audio cable (x2)

• Digital coaxial cable (x1)

• AC mains cord

,,,,

CDR 930

MINI AUDIO

CD RECORDER

OPEN/CLOSE

EASY JOG

ENTER

STOP

REC TYPE

CANCEL

SOURCE

PLAY/PAUSE

ERASE FINALIZE

SCROLL DISPLAY

ON/OFF

Recordable

SYNC

PROGRAM SHUFFLE REPEAT SCAN

ALL

MANUAL DISC

TRACK

123456789

REM TRACKREC TIME

DIGITAL

OPTICAL

ANALOG

CD RW

REMTOTAL TIME STEPTRACK FADE

10 11 12 13 14 15 16 17 18 19 20 +

MENU/STORE

REC START
