Philips Prestigo SRU8015/34 Manuale utente

SRU8015

www.philips.com/urc

EN Instructions for Use 3

FR Mode d’emploi 19

DE Bedienungsanleitung 37

ES Instrucciones de manejo 55

IT Istruzioni per l’uso 73

NL Gebruiksaanwijzing 89

SRU8015_IFU_Bundel1v4.qxd 16-05-2007 17:01 Pagina 1

SRU8015_IFU_Bundel1v4.qxd 16-05-2007 17:01 Pagina 2

3Contents

ENGLISH

Contents

1 Your Philips Prestigo SRU8015 4

1.1 What’s in the Box 4

1.2 Overview SRU8015 4

1.3 Overview Main Menu 5

2 Getting Started 5

2.1 Prepare 5

2.2 Install 6

3 UsingYour SRU8015 7

3.1 Selecting a Device or an Activity 8

3.2 Selecting a Favorite 8

3.3 Selecting More Functions 8

4 Getting the Most out of Your SRU8015 9

4.1 Devices 10

4.2 Activities 12

4.3 Favorites 13

4.4 More Functions 14

4.5 System Settings 15

4.6 Language 16

5 Frequently Asked Questions 17

6 Need help? 18

Only for US - FCC Compliancy 106

Only for Europe - WEEE Regulation 108

SRU8015_IFU_Bundel1v4.qxd 16-05-2007 17:01 Pagina 3

4Your Philips Prestigo SRU8015

1 Your Philips Prestigo SRU8015

Welcome to the growing family of owners of Philips products.The Philips

Prestigo SRU8015 universal remote control has been designed to control

your equipment.You can install up to 15 devices, 100 favorite channels

with their icons and up to 15 activities.

Select a device and operate the device with the SRU8015’s keys.

Select an activity and automatically start a sequence of key presses, for

instance, to watch a DVD or listen to a CD.

Select a favorite and immediately switch to your favorite channel.

1.1 What’s in the Box

• The SRU8015

• Quick Start Guide

• Instructions for Use in diverse languages

• Philips Alkaline batteries

Philips recommends Philips Alkaline batteries.

1.2 Overview SRU8015

The image on page 2 gives you a main overview of the SRU8015.

To prepare the SRU8015 for use, see ‘Getting Started’ on page 5.

Black keys for sending signals to your equipment

A Power key

B Transport keys

C Alphanumeric keys

D * – . / Clear key

E AV key

F Enter key

Silver keys for controlling the SRU8015

1 More key

2 Favorites key

3 Home / Setup key

4 Rotary wheel

5 Check Mark key

SRU8015_IFU_Bundel1v4.qxd 16-05-2007 17:01 Pagina 4

5Your Philips Prestigo SRU8015

1.3 Overview Main Menu

The Home menu is the starting point for using

the SRU8015.You can control your devices and

activities from the Home menu.

To select the different functions of the SRU8015,

see ‘UsingYour SRU8015’ on page 7.

2 Getting Started

2.1 Prepare

To insert the batteries in the SRU8015:

1Press the cover inwards and lift it up.

2Place the three LR6 AA type alkaline batteries into the battery

compartment, as shown.

3Position the cover and press ﬁrmly until you hear a click.

The SRU8015 displays the Philips logo for

3 seconds and continues with the Installation

Wizard to guide you through the installation.

When the batteries are almost empty, the

Battery Low icon blinks.This indicates a

critical battery level.You can still operate the

SRU8015 control for a short period.

Replace the batteries with new LR6 AA type

alkaline batteries and follow the local

regulations for disposal of the empty batteries.

DNote

If the Battery Low icon blinks, you are not able to enter the

Setup - Main menu anymore.

ENGLISH

123

Installation Wizard -

List of available

languages

SRU8015_IFU_Bundel1v4.qxd 16-05-2007 17:01 Pagina 5

6Getting Started

2.2 Install

1In the Installation Wizard, select your preferred language with the

rotary wheel.

2Press to conﬁrm the selected language.

The SRU8015 guides you through the remainder of the setup

process.

3Follow the instructions on the SRU8015 to add devices.

You can add any device from the following list.

Device Name Description

TV Traditional and ﬂat TVs

DVD DVD player and recorder

DVDR DVD player and recorder

VCR Video Cassette player and recorder

SAT Satellite set-top box with or without Hard Disk Drive (HDD)

DSS/DTT Satellite set-top box with or without Hard Disk Drive (HDD)

Cable Cable set-top box with or without Hard Disk Drive (HDD)

DVB-T/S Digital Video Broadcast - Terrestrial (T) or Satellite (S) with

or without Hard Disk Drive (HDD)

AMP Ampliﬁer

AudioSet Receiver = Ampliﬁer + Tuner

HTS Home Theater System = Ampliﬁer + DVD +Tuner +

Surround Sound Speakers

Tuner Radio Tuner

CD CD player and recorder

MD Mini Disk player and recorder

Tape Audio Cassette Tape player and recorder

DVR Digital Video Recorder = TV Tuner + Hard Disk Drive (HDD)

Tivo Digital Video Recorder = TV Tuner + Hard Disk Drive (HDD)

DMR Digital Media Receiver = device streaming media content

from a PC to a TV or Audio Receiver

TV-DVD combo TV with integrated DVD

TV-VCR combo TV with integrated VCR

TV-VCR-DVD combo TV with integrated DVD and VCR

DVD-VCR combo DVD and VCR combination

DVDR-HDD combo DVD recorder and Hard Disk Drive (HDD) combination

VCD, Laser Disk Video Compact Disk, Laser Disk, Karaoke

4 5

SRU8015_IFU_Bundel1v4.qxd 16-05-2007 17:01 Pagina 6

7Getting Started

Device Name Description

Projector Video Projector

PC PC (infrared only)

Game DVD player function of Game Console (Infrared only)

Satellite Radio Satellite Radio Receiver

Lighting Lighting, drapes and blinds (Infrared only)

HVAC & Fans Heating Ventilation and Airconditioning (HVAC) and fans

(Infrared only)

DNote

You can change the settings that you made during this initial

installation or install more function afterwards via the Setup menu.

See ‘Getting the Most out of Your SRU8015’ on page 9.

3 Using Your SRU8015

The SRU8015 has been designed to control your equipment with one

remote control. Simply add your devices, your activities, your favorites

and your extra functions to start enjoying the SRU8015.

A device is a part of your equipment.As soon as you have installed your

devices, you can control them with the keys on the SRU8015.

Devices can have extra functions in addition to the keys on the SRU8015.

You can select more functions on the display.

An activity is a sequence of key presses you can install. For example, to

watch a DVD you normally would have to:

• Turn on the TV;

• Turn on the DVD;

• Turn on the surround sound system;

• Select the right input on your TV and surround sound system;

• Press the Play button to start the DVD.

With an activity the SRU8015 executes all these steps with just one

press.

The SRU8015’s large color display allows you to recognize your

favorites easily and switch to those channels quickly.You do not have to

enter the channel number anymore since you can install favorites along

with their logo.

ENGLISH

SRU8015_IFU_Bundel1v4.qxd 16-05-2007 17:01 Pagina 7

8Using Your SRU8015

3.1 Selecting a Device or an Activity

To select your installed devices and activities:

1Press .

2Select a device or an activity with the

rotary wheel.

The SRU8015 is set to operate the selected

device.You can now control that device with

the black keys on the SRU8015.

-or-

Select an activity with the rotary wheel and

press to start the activity.

The SRU8015 sends out a sequence of key

presses for the selected activity.The SRU8015

is set to operate the device you selected for

this activity.

To setup your devices, see ‘Add a Device’ on page 10.

To setup your activities, see ‘Add an Activity’ on page 12.

3.2 Selecting a Favorite

To select your installed favorites:

1Press .

2Select a favorite with the rotary wheel and

press to conﬁrm your choice.

The SRU8015 sends out a signal and switches

to the selected channel.

To setup your favorites, see ‘Add a Favorite’ on

page 13.

3.3 Selecting More Functions

Devices can have extra functions in addition to the keys on the SRU8015.

To select more installed functions:

1Press .

2Select a function with the rotary wheel

and press to conﬁrm your choice.

The SRU8015 sends out the signal for the

selected function.

To setup more functions for your devices,

see ‘Add a Function’ on page 14.

List of installed

functions

List of installed

favorites

List of installed

devices and activities

SRU8015_IFU_Bundel1v4.qxd 16-05-2007 17:01 Pagina 8

9Getting the Most out of Your SRU8015

4 Getting the Most out of Your SRU8015

Via the Setup menu you have access to the various advanced features of

the SRU8015.

To enter the Setup menu:

Press and hold for 3 seconds.

DNote

You cannot enter the Setup menu if the

Battery Low icon blinks.

To navigate through the Setup menu:

Select an option in the Setup - Main menu with the rotary wheel

and press to conﬁrm your choice.

-or-

Select Back in the Setup submenus and press .

To exit the Setup menu:

Select Exit Setup in the Setup - Main menu and press .

-or-

Press again.

The following table gives you an overview of the options in the Setup

menu and the pages where you ﬁnd more information about these

options.

Setup - Main menu Submenu Description Page

Devices

Add Device Adds a new device 10

Fix a Key Fixes a key that is not working

correctly by copying the signal form

your original remote control 10

Copy Volume Copies the volume keys from one

device to another device 11

Rename Device Renames a device 12

Delete Device Deletes an installed device 12

Activities

Add Activity Adds a sequence of key presses

to operate different devices with

one press 12

Rename Activity Renames an activity 13

Delete Activity Deletes an installed activity 13

ENGLISH

SRU8015_IFU_Bundel1v4.qxd 16-05-2007 17:01 Pagina 9

10 Getting the Most out of Your SRU8015

Setup - Main menu Submenu Description Page

Favorites

Add Favorite Adds a new favorite 13

Rename Favorite Renames a favorite 14

Delete Favorite Deletes a favorite 14

More Functions

Add Function Adds an extra function by learning it

from your original remote control 14

Rename Function Renames a function 14

Delete Function Deletes an installed function 15

System Settings

Display Brightness Changes the brightness of the display 15

Backlight Time-Out Changes the time-out of the backlight

on the SRU8015 15

Key Backlight Turns the key backlight on or off 15

Full Reset Deletes all your personal settings

on SRU8015 16

Language

Changes the language of the

instructions on the SRU8015 16

Exit Setup

Leaves the Setup menu 9

4.1 Devices

4.1.1 Add a Device

To operate your speciﬁc devices with the SRU8015, you have to add those

devices.You can add up to 15 devices. For a list of devices, see page 6.

DNote

You can add a device more than once.A second TV will automatically

be named TV2.You can enter a different name if your wish to. See

‘Rename a Device’ on page 12.

1Go to Setup - Devices, select Add Device and press .

2Select the device you want to add.

3Follow the instructions on the SRU8015.

The selected device is installed and added to the SRU8015.

You can now operate your device with the SRU8015:

Press , select the device with the rotary wheel and

press .

4.1.2 Fix a Key

If a key or extra function is not working properly with your device, you

can copy that key’s signal from your original remote to the SRU8015.

BWarning

When you use the ‘Fix a Key’ option, new data overwrites the data

that is currently stored for that key.

SRU8015_IFU_Bundel1v4.qxd 16-05-2007 17:01 Pagina 10

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Philips Telecomando

Philips

Philips 29PT8423/12 Manuale utente

Philips

Philips Perfect replacement SRP5107/27 Manuale utente

Philips

Philips TSU7000 Manuale utente

Philips

Philips MC-110 Manuale utente

Philips

Philips SRU1060/10 Manuale utente

Philips

Philips TSU9400/93 Guida di sicurezza

Philips

Philips US2-PDVR8 Manuale utente

Philips

Philips Magnavox 50P8241 Manuale utente

Philips

Philips Perfect replacement SRP1003 Manuale utente

Philips

Philips SRU 520/86 Manuale utente

Philips

Philips 22AV1104 Manuale utente

Philips

Philips SRC3036 Manuale utente

Philips

Philips TSU9200/79 Guida di sicurezza

Philips

Philips SRU5100/27 Guida per l'amministratore

Philips

Philips US2-P335B Manuale utente

Philips

Philips G96SVC Manuale utente

Philips

Philips 22AV1125 Manuale utente

Philips

Philips SRP4004/55 Manuale utente

Philips

Philips SRP4004/86 Manuale utente

Philips

Philips TSU9600/93 Guida di sicurezza

Philips

Philips Elite SRP4219G/07 Manuale utente

Philips

Philips MELICONI Manuale utente

Philips

Philips Pronto TSU3000 Manuale utente

Philips

Philips Perfect replacement SRU5107WM Manuale utente

Manuali Telecomando popolari di altre marche

Panasonic

Panasonic EUR7622KB0 Manuale utente

Bang & Olufsen

Bang & Olufsen Beo4 Manuale utente

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuale utente

Multiplex

Multiplex PROFI TX 9 Manuale utente

One Remote

One Remote RMB4 Manuale utente

FUTABA

FUTABA 9ZAP - PART2 Manuale utente

HR Matic

HR Matic HR MULTI 3 Manuale utente

Yamaha

Yamaha ACC-GNRST-30-20 Manuale utente

EisSound

EisSound KBSOUND Manuale utente

Marantz

Marantz RC101 Manuale utente

Conrad

Conrad FS20 TC6 Manuale utente

Anritsu

Anritsu MP1777A Manuale utente

Niles

Niles WVC100 Guida alla risoluzione dei problemi

RCA

RCA RCU1300 Manuale utente

Bang & Olufsen

Bang & Olufsen BEO6 Manuale utente

GE 94901 Manuale utente

Onbon

Onbon YQ1-75 Manuale utente

FUTABA

FUTABA R7108SB Istruzioni per l'installazione
