Philips FWM154/05 Manuale utente

Quick start guide

Connect

Setup

Enjoy

Mini Hi-Fi System

FWM154

Play disc

1Press DISC to select the disc source.

2Press OPEN/CLOSE on the front panel

to open the disc tray.

3Insert a disc with the printed side facing up,

then close the disc tray.

» Play starts automatically.

• To pause/resume play, press .

• To stop play, press .

To skip to a track, press• / .

To search within a track, press and•

hold / . Release to resume

normal play.

Enjoy

Program radio stations

automatically

1In tuner mode, press and hold

PROGRAM for 2 seconds to activate

automatic program mode.

» [AUTO] (auto) begins to blink.

» All available stations are programmed

in the order of waveband reception

strength.

D Note

You can program a maximum of 20 preset

radio stations.

The first programmed radio station is

broadcast automatically.

Speciﬁcations are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

Printed in China

FWM154_05_QSG_V1.0

E Tip

Detailed features and additional functions are

described in the user manual.

FWM154_QSG_AEN_05_1.0.indd 2-3FWM154_QSG_AEN_05_1.0.indd 2-3 2009-4-23 14:30:372009-4-23 14:30:37

What’s in the box

Quick start guide

XXXXXX

Connect

Setup

2Enjoy

Eng

XXXXXXX

xxxxx

User Manual

Remote Control Quick start guideUser manual

Connect

Prepare the remote control

1Open the battery compartment.

2Insert 2 AAA batteries with correct

polarity (+/-) as indicated.

3Close the battery compartment.

MP3 link cable

D Note

• Before you press any function button on the remote

control, press a source button to select source with

the remote control.

Connect Speaker

D Note

• Ensure that the colors of the speaker wires

and terminals are matched.

1Connect the speaker wires to the matching

speaker terminals on the main unit.

E Tip

• See the User Manual for how to connect

other equipment to this system.

FMANT LOOP ANT

Speaker

(Right)

Speaker

(Left)

Connect

Setup

Set clock

1In standby mode, press and hold CLOCK.

» The hour digits are displayed and begin

to blink.

2Press / on the remote control to set

the hours.

3Press CLOCK.

» The minute digits are displayed and

begin to blink.

4Press / to set the minutes.

5Press CLOCK to conﬁrm the time.

Connect power

1Connect the power cord to the wall outlet.

C Caution

• Risk of product damage! Ensure that the

power supply voltage corresponds to the

voltage printed on the back or the underside

of the unit.

• Risk of electric shock! When you unplug the

AC power cord, always pull the plug from the

socket. Never pull the cord.

E Tip

• During play, you can press DISPLAY on the

remote control to view the clock.

FWM154_QSG_AEN_05_1.0.indd 4-5FWM154_QSG_AEN_05_1.0.indd 4-5 2009-4-23 14:30:422009-4-23 14:30:42
