Philips FWV135 Manuale utente

FWV135

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

Remote control

( batteries not included)

Composite Video Cable MW antenna

Quick Start Guide

Quick start guide

User Manual

User manual

FWV135 QUG_Eng-98 16/2/06, 13:491

MW loop antenna

AC power cord

FM pigtail antenna

Speaker

(right)

Speaker

(left)

VIDEO OUT

Television

Important!

– Before connecting the AC power cord

to the wall outlet, make sure that the

VOLTAGE SELECTOR (located on the rear

of the system) is adjusted to match the

local power voltage.

Tip

–It is unnecessary to connect the FM

pigtail antenna since it is fixed to the

main unit.

Connect the speaker wires to the system’s SPEAKERS terminals.

Connect the supplied MW loop antenna.

Connect your FWV135 and TV using the supplied composite video cable.

Connect the power cord of the system to AC power outlet.

FWV135 QUG_Eng-98 16/2/06, 13:492

Setting the clock

In standby mode, press briefly CLOCK•TIMER (or press and hold CLOCK SET on the

remote).

When the clock digits flash, press ALBUM-/+ 1/¡( or ALBUM 3/4on the remote)

to set the hours; press TITLE -/+í/ë(or 4/ ¢on the remote) to set the minutes.

Press CLOCK•TIMER (or CLOCK SET on the remote) to confirm the clock setting.

Tip

–Press and hold PAL/NTSC on the remote

to switch between PAL and NTSC to match

yourTV system for clear disc viewing.

Setting up the TV

Press DISC (VCD/CD on the remote) to select disc source.

Turn on the TV and set it to the correct Video In channel.

PAL/

NTSC

DBB DSC

REPEAT SHUFFLE REPEAT

A-B

ZOOM

ALBUM ALBUM

DISPLAY

OSD

PBC RETURN DIGEST

GOTO RESUME SLOW AUDIO/VOCAL

CLOCK SET TIMER SLEEP MUTE

VCD/CD TUNER TAPE AUX

ECHO

KEY PROG

VCD/CD

PAL/

NTSC

PAL/

NTSC

DBB DSC

REPEAT SHUFFLE REPEAT

A-B

ZOOM

ALBUM ALBUM

DISPLAY

OSD

PBC RETURN DIGEST

GOTO RESUME SLOW AUDIO/VOCAL

CLOCK SET TIMER SLEEP MUTE

VCD/CD TUNER TAPE AUX

ECHO

KEY PROG

CLOCK SET

ALBUM

FWV135 QUG_Eng-98 16/2/06, 13:493

Press PROGRAM (PROG on the remote) again to confirm the setting.

“PROG” disappears from the display.

Press PRESETí/ë(S T on the remote) to allocate a number

(FM: 1 to 20;AM: 1 to 10)

Playing a disc

Programming and tuning to radio stations

Press TUNER/BAND (TUNER on the remote) to select tuner source (FM or MW).

PDCC-JH-0607

2006 CKoninklijie Philips Electronics

http://www.philips.com

Tip

Detailed playback features and

additional functions are described in the

accompanied owner's manual.

Notes for remote control:

– First, select the source you wish to

control by pressing one of the source select

keys on the remote control (VCD/CD or

TUNER, for example).

–Then select the desired function (

for example).

Press PRESETí/ë(S T on the remote) until the desired preset station is displayed.

Press and hold SEARCH 1or ¡ (4/ ¢on the remote) until the frequency on

the display starts running.The radio automatically tunes to a station of sufficient reception.

Press PROGRAM (PROG on the remote) to activate programming.

“PROG” flashes on the display.

Press PUSH on the top of the system to open the disc tray.

Playback will start automatically. If not, pressÉÅ.

To stop playback, press 9.

Load in a disc with the label side facing up, then close the disc door.

PUSH

FWV135 QUG_Eng-98 16/2/06, 13:494
