Philips SWS2283W Manuale utente

Connect 3 devices to a TV

with this 3-way manual switcher

Depend on this switcher to connect up to 3 components to 1 TV.

Enjoy good picture quality

• Crafted with quality construction

• S-Video compatible

• Nickel-plated connectors for reliable contact

Easy installation

• Color coded connectors for instant recognition

• Non-slip ergonomic grip for easy use

• Color-coded inputs

Philips

A/V switcher

Manual

Composite A/V Connections

SWS2283W

SWS2283W/27

A/V switcher

Manual Composite A/V Connections

Specifications Product highlights

Packaging dimensions

•Packaging dimensions (W x H x D):

13.2 x 28.7 x 3.8 cm

•Nett weight: 0.230 kg

•Gross weight: 0.240 kg

•Tare weight: 0.010 kg

•UPC: 6 09585 15966 2

•Number of products included: 1

•Packaging type: Blister

Outer Carton

•Outer carton (L x W x H): 45.5 x 33.3 x 33.0 cm

•Nett weight: 5.519 kg

•Gross weight: 5.72 kg

•Tare weight: 0.200 kg

•GTIN: 2 06 09585 15966 6

•Number of consumer packagings: 24

Inner Carton

•Inner carton (L x W x H): 16.0 x 14.5 x 30.5 cm

•Nett weight: 0.920 kg

•Gross weight: 0.950 kg

•Tare weight: 0.030 kg

•GTIN: 1 06 09585 15966 9

•Number of consumer packagings: 4

•

Issue date 2008-11-17

Version: 1.1.4

12 NC: 8670 000 42053

UPC: 6 09585 15966 2

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

Color-coded connectors

Color coded connections make it easy to install your cable

into the correct inputs and outputs

Easy grip

This non-slip grip makes connecting your components easy

and ergonomically comfortable.

Color-coded inputs

Inputs are color coded to ensure correct connections.

Quality construction

Quality construction uses only top grade materials to create

products of extended durability.

Nickel-plated connectors

Nickel-plated connectors establish a clean contact between

the cable and connector for a reliable connection.
