Philips 27PC4326/37B Manuale utente

ANT.

AUDIOOUTAUDIOOUT

COAXIALCOAXIAL

OUT

CABLE BOX

CABLE TV SIGNAL

RF COAXIAL

CABLE

ANT.

ANTENNA or

CABLE TV SIGNAL

1Disconnect all equipment from the power outlets. Connect the equipment to the power outlets only after you

have finished hooking up everything. Never make or change connections with equipment connected to the power outlet.

2If you do not have a Cable Box, simply connect your Antenna or Cable TV signal directly to the ANT. (enna)

jack on the rear of the TV/VCR/DVD.

3If you do have a Cable Box or Satellite Receiver, first connect the Cable TV or Satellite signal to the IN jack

on the Cable Box or Satellite Receiver. Then, use an RF coaxial cable (not supplied) to connect the OUT

jack of the Cable Box or Satellite Receiver to the ANT. (enna) jack on the TV/VCR/DVD. To view any channel,

set the TV/VCR/DVD to the output channel of the Cable Box or Satellite Receiver (channel 3 or 4). Then, select channels at

the Cable Box or Satellite Receiver.

4When all connections are complete, plug the power cord of the TV/VCR/DVD into an active power

outlet.

5Press STANDBY-ONyon the TV/VCR/DVD or its remote to turn on the unit.

There are many ways to connect your new TV/VCR/DVD to your other equipment. This Quick Start Guide

shows the easiest, most common connections for the TV/VCR/DVD.

27PC4326

Printed in Malaysia

8239 300 47441

1EMN21841

T3221UB*****

T3221UB_QSG_EN 5/8/06 7:18 PM Page 1

123

456

STANDBY-ON OPEN/CLOSE

MODE

SELECT

DISPLAY

CH. VOL.

MUTE


/SLEEP

Quick Start Guide (cont’d)

Detailed playback features and additional functions are described in the

accompanying user manual.

Watching TV

1Press STANDBY-ONyto turn on the TV/VCR/DVD. The red VCR/TV light

will appear.

2This unit memorizes TV channels when you connect an Antenna or Cable TV signal

as described in this Quick Start Guide.

To watch TV, use CH. ▲/▼to select memorized channels. If a channel is skipped,

use the Number buttons to select it.To update your channels later, refer to the user

manual.

3Press VOL. X/Yto adjust the volume.

Playing a Videotape

1With the unit on, press SELECT to put the unit in TV/VCR mode. The red

VCR/TV light will appear.

2Insert a videotape in the cassette compartment. If playback does not start

automatically, press PLAY B.

3Press STOP Cto stop playback.

Playing a DVD

1With the unit on, press SELECT repeatedly to put the TV/VCR/DVD in

DVD mode. The green DVD light will appear on the front of the TV/VCR/DVD.

2Press OPEN/CLOSE Ato open the disc tray.

3Place a disc into the tray, with the label facing up and the shiny side facing

down.

Playable Discs

The TV/VCR/DVD will play the following discs.

Windows Media is a trademark of Microsoft Corporation.

DVDs must have a Region Code of ALL regions or Region 1.

DVDs must be recorded in the NTSC Color System.

ALL

VOLUME 20

PLAY

STOP

RETURN

MODE

SELECT

DISPLAY

CH. VOL.

MUTE

DISC SET-UP

SLOW PAUSE

TITLE

ENTER


/SLEEP

4Press PLAY B.The tray will close and playback will begin. If playback does

not start automatically, press PLAY Bagain.

If a DVD menu appears instead, use KLs B,ENTER or Number buttons to

choose features or start playing from the menu.

5Press STOP Cto stop playback.

is a trademark of DVD Format/Logo Licensing Corporation.

123

456

789

+10

+100

CLEAR

REC MODE REC

PLAY

STOP

RETURN

MODE

SELECT

DISPLAY

CH. VOL.

MUTE

DISC SET-UP

SLOW PAUSE

TITLE

STANDBY-ON OPEN/CLOSE

ENTER


/SLEEP

T3221UB_QSG_EN 4/6/06 1:09 PM Page 2
