Phonak TVLink II Manuale utente

User Guide

Phonak TVLink II

Contents

1. Welcome 5

2. Getting to know your TVLink II 6

3. Getting started 9

3.1 Setting up the power supply 9

3.2 Selecting the charging slot 10

3.3 Connecting the cables 11

3.4 Charging the streamer 19

3.5 Pairing TVLink II and the streamer 20

4. Daily use 24

4.1 Wearing the streamer 24

4.2 Connecting the devices 25

4.3 Adjusting the volume 28

4.4 Streaming pause and resume 30

4.5 TVLink II and phone calls 31

4.6 Switching o devices 32

4.7 Understanding the indicator light 33

5. Troubleshooting 34

5.1 Testing the audio transmission 34

5.2 Questions and answers 37

6. Service and warranty 40

6.1 Local warranty 40

6.2 International warranty 40

6.3 Warranty limitation 41

7. Compliance information 42

8. Information and explanation of symbols 46

9. Important safety information 50

10. Important notice 55

I will use the TVLink II along with the following streamer:

c ComPilot c ComPilot II c ComPilot Air II

Congratulations on choosing the Phonak TVLink II.

It expands the way you hear your world by wirelessly

connecting your hearing aids to your TV and other

entertainment or communication devices.

Please read this user guide carefully to discover how

to benet from all the features of your TVLink II.

If you have any questions, please consult your hearing

care professional or go to www.phonak-us.com/tvlink

Phonak – life is on www.phonak-us.com

1. Welcome

CE mark applied: 20140560

2. Getting to know your TVLink II

The intended use of the TVLink II basestation is to

connect your hearing aids to a TV (or any other audio

source). It sends audio signals wirelessly to the

hearing aids up to 30 meters (100 ft). It also serves as a

charging cradle for the Phonak streamer.

The system consists of three main elements:

Your hearing aids, a Phonak streamer and the TVLink II

basestation (“TVLink II”).

ComPilot Air II * TVLink II

basestation

Hearing

aid

Up to 30 meters

(100 ft)

The Bluetooth® word mark and logos are registered trademarks owned

by Bluetooth SIG, Inc. and any use of such marks by Phonak is under license.

*ComPilot or ComPilot II

are also compatible

2. Getting to know your TVLink II

2.1 Device description

Buttons

AVolume down

BPower on/off and

main indicator light

CVolume up

DPairing

Inputs

EPower supply

FDigital audio (optical)

GDigital audio (coaxial)

HAnalog audio (3.5 mm)

Others

IAudio indicator lights

JExchangable charging slot

B AC

H IF JG

1. 2.

3.1 Setting up the power supply

Select the adapter that corresponds to your country.

US UK AUS EU

JFirstly, insert the top round

end of the adapter into

the round corner of the power

supply.

JClick the bottom end of the

adapter in to lock it into place.

JTo remove, rst pull back the tab

on the power supply.

JPull the adapter upwards to

remove it.

3. Getting started

3.2 Selecting the charging slot

The stand-alone TVLink II is delivered with the charging

slot for Phonak ComPilot Air II clip-on streamer.

If you have ComPilot or ComPilot II, change the slot

using a Phillips head screwdriver no 1.

JUnscrew the bottom screw. Lift the charging slot as

shown.

JInsert the other slot completely. Insert and gently

tighten the screw.
