Phonic Ear Silhouette Manuale utente
hands-free BTE inductor
for mobile phones
other resources online at www.phonicear.dk
GB user guide
SILHOUETTE function . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SILHOUETTE features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
SILHOUETTE instructions. . . . . . . . . . . . . . . . . . . . . . . . . . 5
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Test and approval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
table of contents
1
SILHOUETTE function
SILHOUETTE is a discreet and hands-free BTE inductor for
use with mobile phones. SILHOUETTE comes in two different
versions for use with either one or two hearing aids.
7carry bag
1 2.5mm jack
To connect to mobile
phone adaptor
2shirt clip
To attach to shirt to fix
microphone position
2
3microphone and
remote control
To pick up the voice from
speaker’s mouth and to
answer incoming calls or
to end calls (this function
may only work on some
mobile phones)
6adaptor
4BTE inductor
To transmit other party’s
voice
SILHOUETTE features
English
5second BTE
inductor
To transmit other
party’s voice
(binaural type only)
8carry purse
SILHOUETTE features
3
1
2
3
5
4
1
4
3
2
monaural
version binaural
version
English
SILHOUETTE features
4
6
7
8
5
SILHOUETTE instructions
installation
Attach the adaptor
matching the
mobile phone into
the mobile phone’s
socket.
Insert the 2.5mm
jack fully into the
adaptor.
1
NOTE: SILHOUETTE
connects to some
mobile phones without
use of an adaptor.
English
SILHOUETTE instructions
6
place inductor
Place the inductor
behind the hearing
aid fitted ear. If the
SILHOUETTE is of
binaural type place
the second induc-
tor behind the
other ear while
placing the wire
behind the neck.
The same signal is
transferred to both
hearing aids.
NOTE: The inductor
can be placed on
either side of a BTE
type hearing aid.
2
7
SILHOUETTE instructions
hearing aid setting
Set hearing aid to “T”
or “MT” position
when using the
SILHOUETTE.
3
8
English
SILHOUETTE instructions
adjust and attach shirt clip
4
Adjust the shirt clip
to the desired posi-
tion and attach it to
the shirt. The
microphone should
be hanging between
the inductor and
the shirt clip in
close proximity to
the speaker's
mouth.
The mobile phone
can now be stored
away for hands-free
operation.
