INTRODUCTION

Congratulations on your purchase of the

WM400(D) wireless receiver, to be used

in conjunction with the WM60 or WM70

wireless transmitters. With either the stereo

or mono WM kits, you are now fast on your

way to becoming completely wireless in your

audio set up. The WM modules are not only

fantastic in style and convenience, however;

they are incredibly easy to use, as this

manual will no doubt prove.

Please have a thorough read of this user’s

manual before operating the WM modules.

Inside this guide you will nd information on

the ease of your wireless set up, as well as

some great troubleshooting tips and a com-

plete run-down on your modules’ features.

After reading, place the manual in an easy to

remember place so that you can come back

to it in future if ever necessary.

FEATURES

●

Working with the WM60 or WM70 trans-

mitter to form a wireless system for sav-

ing the audio cables between your mixer

and active speakers

●

Stand-alone UHF wireless receiver,

compatible with WM60 and WM70 trans-

mitters

●

12VDC external power supply (country

dependent)

●

16 user-selectable frequencies

●

RF carrier frequency range:

614.175 - 804.800 MHz (FCC)

614.175 - 864.800 MHz (CE)

●

Operating range: 210 ft. (70m, environ-

ment dependent)

●

Indicators for power on, AF and RF

●

Antenna: external, threaded connector

●

Audio output connectors: XLR out

●

M6, M8, M10 screws and Velcro strip

included for attaching WM400(D) to any

speakers

WM400D-L or WM400D-R plus:

●

300 ms digital delay processor for com-

pensation of different distance speakers

●

0.1 millisecond to 300.0 millisecond de-

lay range, delay adjustment may be

made with 0.1 millisecond precision

●

30 preset EQ curves and variable high

cut and low cut lters

●

4-digit display to indicate frequency

channel and delay, plus AF, RF and de-

lay bypass indicators

WM 400-R / 400D-R / 400-L / 400D-L

PRODUCT DESCRIPTION

These wireless receivers can be used in con-

junction with any active speaker. The receiver

can be attached to the speaker by screwing it

into the stand’s screw socket.

1. 4 Digit Display

(WM400D-L and WM400D-R only)

This display will allow users to see the

properties that are currently in use by

the WM400D, whether you are adjusting

the receiver channel (indicated by CH),

the EQ settings (indicated by EQ), the

delay time (indicated by only the delay

time in milliseconds) or the high and

low pass lters (indicated by a H or L,

respectively). When this unit is powered,

the 4 digit display will light up.

2. AF Indicators

When this LED is illuminated, it indicates

that there is an audio signal being

received by the WM400(D) receiver.

3. RF Indicators

When the RF indicator illuminates, it

shows that the transmitter’s signal is

being received successfully. If for some

reason this LED does not turn on, check

your DC power input and pre-set chan-

nel conguration and try again.

4. Bypass Indicator

(WM400D-L and WM400D-R only)

This LED will light up when the digital

processing feature of the WM400(D) re-

ceiver is off.

5. Power Button

hold this button down for 2 seconds to

power up the unit.

6. Bypass Button

(WM400D-L and WM400D-R only)

Push this button to turn the digital

processing feature on and off.

WM400

WM400D

567

6WM 400-R / 400D-R / 400-L / 400D-L

7. Up and Down Buttons

(WM400D-L and WM400D-R only)

These buttons are used to adjust the

properties of various features built-into

the WM400D’s. Pushing up or down will

initially simply allow users to adjust the

channel that the transmitter is using. If

you push both of these buttons at the

same time, it will jump to the next setting

that can be edited. You can then adjust

the properties by pushing the up and

down buttons. These settings will come

in the following order:

Channel Settings: CH 0 – CH 9,

CH A – CH F

Delay Settings: 0.0 – 300.0 milliseconds

EQ Mode: P1 – P30 (see the EQ table

for a full rundown on EQ presets)

Low Cut Filter: L 20 (Hz) – L 12 (kHz)

High Cut Filter: H 20 (kHz) – H 60 (Hz)

The high and low cut lters are adjusted in 1 Hz

increments; 10 Hz increments when over 1 kHz.

8. Channel Selector

(WM400-L and WM400-R only)

Adjusting this dial to one of the preset

channels allows the WM400 to know

which pre-set frequency to look for

the wireless information. The wireless

transmitter should be set to the identical

channel if transmission is to occur suc-

cessfully.

9. On Indicator

(WM400-L and WM400-R only)

This LED indicator illuminates when the

WM400(D) receiver is powered.

10. Antenna

This is the WM400(D)’s antenna. Adjust

it so it sits in a vertical position when the

device is in use (change the position if

the wireless signal quality is poor). Push

the antenna in to release it before ad-

justing its position.

WM400D

567

WM400

11. DC In and clip

Plug DC end of the supplied DC power

adaptor (12V, 200mA) into this jack, and

the other end into a suitable AC power

source to allow the WM400(D) to be

powered. The accompanying clip en-

sures the DC head of the power supply

is kept securely in place.

12. XLR Output

This jack accepts XLR connectors to

feed the signal from the Wireless Re-

ceiver to the Speaker.

13. Fixing

Use this hole to secure the WM400(D)

receiver into the mounting socket of your

speaker by use of the accompanying

M6, M8 or M10 screws and a washer.

WM 400-R / 400D-R / 400-L / 400D-L

WM400(D) POWER MODES

Since some users will mount their WM400(D)

with a speaker in a high position, Phonic

thought it would be handy to make it so us-

ers could keep the power on constantly, as

long as power is supplied to the unit and thus

avoiding having to climb up high to push the

power button. To make this adjustment, users

are advised to follow the follow procedure:

1. Remove the two screws on the rear of the

WM400(D) receiver and the antenna.

2. Remove the screw on the bottom of the

WM400(D) beside the XLR output (the

screw closer to the rear panel)

3. Remove the rear section of the casing by

gripping the WM400(D) on both sides,

squeezing and lifting up, in the process

detaching the small clips within the cas-

ing.

4. A small switch should be visible on the

PCB. Flick it to the left to ensure the power

of the WM400(D) does not turn off without

you pushing the power button.

5. Be sure to replace the casing and screws

before using the WM400(D) receiver.

Unscrew the antenna

Unscrew the two screws

located on the rear panel

Unscrew the screw on

just below the XLR jack

Move the switch to the left to ensure the

power i s always on. T o the right, the

power button will need to be pushed and

held down to turn the unit on.

8WM 400-R / 400D-R / 400-L / 400D-L

High Cut Filter

The high cut lter allows users to remove

unwanted high-frequency sounds, which can

help to remove high frequency hiss and feed-

back, as well as make the audio signal more

suitable for use with subwoofer speakers.

The high cut lter’s cut off frequency is ad-

justed in 1 Hz increments (10 Hz increments

over 1kHz) between 20 kHz and 60 Hz. The

default setting is 20 kHz.

Channel Mode

The channel number of the WM400D will be

displayed in the 4 digit display, unless ad-

justments are being made to other feature’s

properties. The channel number set should

match that of the WM60 or WM70 transmit-

ter to allow the wireless system to work suc-

cessfully.

Delay Mode

Changing the delay allows audio engineers to

compensate for the distance between speak-

ers on stage and audience members at the

rear of the venue. Using the delay effect on a

speaker at the rear will ensure the audio from

the stage reaches audience members at the

rear at approximately the same time as the

audio from the rear-speaker. The delay time

is adjusted in 0.1 millisecond increments, be-

tween 0 and 300 milliseconds (holding the up

or down button down speeds up the adjust-

ment time)

EQ Mode

The different EQ modes allow users to adjust

various frequencies of audio to enhance cer-

tain instruments, remove sibilance, feedback

and other undesirable noises, and improve

the overall delity of sounds. There are 30

presets to choose from (check EQ Preset

page for more information), the titles of which

describe what the effect does to your audio.

The default setting, P0, is completely at.

Low Cut Filter

A low cut lter allows users to cut low fre-

quency sounds, ensuring stage rumble and

other unwanted low-frequency sounds are

removed from your audio. This can also help

adjust the frequency to be more suitable for

use with tweeters. The low cut lter’s cut off

frequency is adjusted in 1 Hz increments (10

Hz increments over 1kHz) between 10 Hz

and 12 kHz. The default setting is 40 Hz.

THE WM400D’S DIGITAL FEATURES

WM 400-R / 400D-R / 400-L / 400D-L

ATTACHING THE UNIT TO A SPEAKER

Users can connect the WM400(D) Receiver modules to an active speaker using a mounting

point or the included velcro strips, as indicated.

Mounting Point Velcro Strip

10 WM 400-R / 400D-R / 400-L / 400D-L

DIMENSIONS

* All measurements are shown in mm/inches.

79.25 / 3.1

128.35 / 5.1

35 / 1.4
