Introduction

1 Introduction to the Rapid Development Kit

This QuickStart provides:

•general information on the PHYTEC phyCORE-PXAG49 Single

Board Computer (SBC)

•an overview of the Tasking XA Embedded Development

Environment (EDE) evaluation version, and

•instructions on how to run example programs on the

phyCORE-PXAG49, mounted on the PHYTEC

phyCORE Development Board LD 5V, in conjunction with the

Tasking EDE

Please refer to the phyCORE-PXAGx Hardware Manual for specific

information on such board-level features as jumper configuration,

memory mapping and pin layout. Selecting the links on the electronic

version of this document links to the applicable section of the

phyCORE-PXAGx Hardware Manual.

1.1 Rapid Development Kit Documentation

This “Rapid Development Kit” (RDK) includes the following

electronic documentation on the enclosed “PHYTEC Spectrum

CD-ROM”:

•the PHYTEC phyCORE-PXAGx Hardware Manual and phyCORE

Development Board LD 5V Hardware Manual

•controller User's Manuals and Data Sheets

•this QuickStart Instruction with general “Rapid Development Kit”

description, software installation hints and three example programs

enabling quick out-of-the box start-up of the phyCORE-PXAG49

in conjunction with the Tasking software development tools

phyCORE-PXAG49 QuickStart Instructions

2© PHYTEC Meßtechnik GmbH 2002 L-481e_4

1.2 Overview of this QuickStart Instruction

This QuickStart Instruction gives a general “Rapid Development Kit”

description, as well as software installation hints and three example

programs enabling quick out-of-the box start-up of the

phyCORE-PXAG49 in conjunction with the Tasking XA software

development tools. It is structured as follows:

1) The “Getting Started” section uses two example programs:

•"Blinky" and "Hello" to demonstrate the download of user code

to the Flash device using PHYTEC FlashTools for on-chip

Flash (OCF).

2) The “Getting More Involved" section provides step-by-step

instructions on how to modify both examples, create and build

new projects and generate and download output files to the

phyCORE-PXAG49 using the Tasking tool chain and

FlashToolsOCF.

3) The "Debugging”section provides a third example program

- “Debug” - to demonstrate simple debug functions using the

Tasking XA EDE simulator debug environment.

In addition to dedicated data for this Rapid Development Kit, this

CD-ROM contains supplemental information on embedded

microcontroller design and development.

Introduction

1.3 System Requirements

Use of this “Rapid Development Kit” requires:

•the phyCORE-PXAG49 SBC module

•the phyCORE Development Board LD 5V with the included DB-9

serial cable and AC adapter supplying 5 VDC/min. 500 mA

•the PHYTEC Spectrum CD

•an IBM-compatible host-PC (486 or higher running at least

Windows95/98)

For more information and example updates, please refer to the

following sources:

http://www.phytec.com - or - http://www.phytec.de

support@phytec.com - or - support@phytec.de

http://www.tasking.com

tasking.support.na@altium.com (North America)

tasking.support.de@altium.com (Germany)

phyCORE-PXAG49 QuickStart Instructions

4© PHYTEC Meßtechnik GmbH 2002 L-481e_4

1.4 The PHYTEC phyCORE-PXAG49

The phyCORE-PXAG49 represents an affordable, yet highly

functional Single Board Computer (SBC) solution in subminiature

dimensions (55 x 47 mm). The standard board is populated with a

16-bit Philips PXAG49 controller featuring 64 kByte on-chip Flash.

All applicable data/address lines and applicable signals extend from

the underlying logic devices to standard-width (2.54 mm / 0.10 in.)

pin headers lining the circuit board edges. This enables the

phyCORE-PXAG49 to be plugged like a “big chip” into target

hardware.

The standard memory configuration of the phyCORE-PXAG49

features 64 kByte on-chip Flash, 256 kByte external SRAM and

256 kByte external Flash for additional code storage. Three Chip

Select signals are available for external I/O connectivity.

The module communicates by means of an RS-232 transceiver and

operates within a standard industrial range of 0 to +70 degrees C. It

requires only a 220 mA power source.

PHYTEC FlashToolsOCF enables easy on-board download of user

programs.

Introduction

phyCORE-PXAG49 Technical Highlights

•SBC in subminiature dimensions (55 x 47 mm) achieved through

advanced SMD technology

•populated with an 44-pin packaged (PLCC) Philips

XA-compatible PXAG49 controller featuring 64 kByte on-chip

Flash

•minimal instruction cycle time of 102 ns at 29.4912 MHz clock

speed (standard)

•64 kByte on-chip Flash, enabling In-System Programming (ISP)

and In-Application Programming (IAP)

•256 kByte (up to 1 MByte) on-board SRAM

•256 kByte (up to 2 MByte) external Flash enabling In-System

Programming (ISP)

•4 to 32 kByte I²C EEPROM or 8 kByte FRAM

•I²C Real-Time Clock with internal quartz

•RS-232 serial interface

•three I/O Chip Select signals for connection to external peripherals

•requires only a +5 V / 220 mA power source

•operates in a temperature range of 0... 70°C

(optional -40... 85°C temperature range available)

phyCORE-PXAG49 QuickStart Instructions

6© PHYTEC Meßtechnik GmbH 2002 L-481e_4

The phyCORE Development Board LD 5V, in EURO-card

dimensions (160 x 100 mm), is fully equipped with all mechanical

and electrical components necessary for the speedy and secure

insertion, and subsequent programming, of PHYTEC

phyCORE series Single Board Computers with standard width

(2.54 mm/ 0.10 in.) pin header connectors. Simple jumper

configuration readies the Development Board’s connection to any

phyCORE module (standard header pins), which plug pins-down into

the contact strips mounted on the phyCORE Development

Board LD 5V.

phyCORE Development Board LD 5V Technical Highlights

•Reset signal controlled by push button or RS-232 control line

CTS0

•Boot signal controlled by push button or RS-232 control line

DSR0

•low voltage socket for supply with regulated input voltage 5 VDC

•additional supply voltage 3.3 VDC

•two DB-9 sockets (P1A, P1B) configurable as RS-232 interfaces

•two additional DB-9 plugs (P2A, P2B) configurable as

CAN interfaces, connector P2B optionally configurable as RS-485

interface

•simple jumper configuration allowing use of the

phyCORE Development Board LD 5V with various PHYTEC

phyCORE SBC’s

•one control LED D3 for quick testing of user software

•2 x 160-pin Molex connector (X2) enabling easy connectivity to

expansion boards (e.g. PHYTEC GPIO Expansion Board)

Indice

Altri manuali Phytec Hardware per computer

Phytec

Phytec i.MX7 PEB-D-RPI Manuale utente

Phytec

Phytec phyCORE-i.MX 8M Plus Manuale utente

Phytec

Phytec L-1009e.A2 phyCORE-i.MX 8M Plus Manuale utente

Phytec

Phytec ATOM phyCORE-Z500P(T) Manuale utente

Phytec

Phytec phyCORE-i.MX 8M Mini Manuale utente

Phytec

Phytec phyCORE MPC5676 Series Manuale utente

Phytec

Phytec phyCORE-MPC5554 Manuale utente

Phytec

Phytec L-863e.A2 phyCORE-i.MX 8M Manuale utente

Phytec

Phytec phyCORE-AM62Ax Manuale utente

Phytec

Phytec L-808e.A4 Manuale utente

Phytec

Phytec KEIL nanoMODUL-STM32F103 Manuale di programmazione

Phytec

Phytec phyCORE-AM335 Series Manuale utente

Phytec

Phytec PCAN-Dongle PK-001 Manuale di programmazione

Phytec

Phytec phyCORE-PXA270 Manuale di programmazione

Phytec

Phytec L-843e.A1 Manuale utente

Phytec

Phytec phyCORE-i.MX RT1170 Manuale utente

Phytec

Phytec L-1014e.A4 phyBOARD-Mira Manuale utente

Phytec

Phytec phyCORE-MPC5676/57 Series Manuale utente

Phytec

Phytec phyCORE-MPC555 Manuale di programmazione

Phytec

Phytec L-1029e.A1 Manuale utente

Phytec

Phytec L-1017e.A3 i.MX 8M Plus Manuale utente

Phytec

Phytec eGrabber-4plus Manuale utente

Phytec

Phytec phyGATE Tauri-L Manuale utente

Phytec

Phytec L-820e.A2 Manuale utente

Manuali Hardware per computer popolari di altre marche

EMC2

EMC2 VNX Series Manuale del proprietario

Panasonic

Panasonic DV0PM20105 Manuale utente

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuale utente

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuale utente

Raidon

Raidon iT2300 Manuale utente

National Instruments

National Instruments PXI-8186 Manuale utente

Hauppauge

Hauppauge WinTV-HVR-2250 Manuale utente

Kontron

Kontron CP6002 Manuale utente

Manhattan

Manhattan 702843 Manuale utente

Aphex

Aphex 230 Manuale utente

AMD

AMD Phenom II Manuale operativo

Intel

Intel NUC 12 Pro Manuale utente

dbx

dbx Zone Pro 1260 Manuale utente

Galaxy

Galaxy GHDX2-2430S-24F4D Manuale utente

Intel

Intel AXXRMFBU4 Manuale utente

Kontron

Kontron DIMM-PC/MD Manuale utente

ST X-NUCLEO-SAFEA1B Istruzioni operative

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuale utente

Phytec phyCORE-PXAG49 Manuale di programmazione

Manuali Hardware per computer popolari di altre marche
