Pico Genie P100 Manuale utente
Pico Genie P100 LED Mini Projector Layout
1. 3.5mm earphone jack
2. USB charging port 5V
3. DC 12V/1.5A power input
4. HDMI port
5. Power switch
6. Projector Model
7. LED indicator
8. Volume control
9. Optical Lens
10. Focusing wheel
In The Box
Pico Genie P100 projector
HDMI Cable (Type A)
Charger + 3 international
blades
Bag
Tripod
Manual
Specification
Product dimensions: 99.5 x 99 x 22.5mm
Brightness of projection: 85 ANSI Lumens
Projection image size (recommended): 10" ~ 60"
Projection distance (recommended): 36mm~2200mm
Contrast: 1000:1
Resolution: 854 x 480（WVGA）
Screen aspect ratio: 16:9
Charger specification: DC 12V 1500mA
Built-in battery: 3.7V/3800mA
Battery projection time: up to 2 hours at full brightness
Built-in loudspeaker: 2 x 1W
Instruction Manual
The P100 supports HDMI signal input only. Any other form of signal will
need to be transformed through the HDMI port with an adapter E.g. Android
HDMI stick.
The P100 can be operated whilst connected to the mains and the battery
is being charged by the (DC12V) power supply.
The USB host port can be used to power USB devices such as Smartphones
(>5V/500mA) so that your phone and projector do not run out of power whilst
projecting. The USB port cannot be used for file transfer.
The touch panel on top of the device changes the contrast between 2
modes, Standard/ Presentation and controls the volume. To switch modes,
long press the “M” key in the centre. For volume control, slide your finger in a
clockwise/anti-clockwise direction to increase/reduce the volume
respectively.
To focus: Slowly turn the focus wheel until the image is in focus
When connected to mains (AC) power, a red LED light indicates the
projector is charging and will turn green when fully charged.
A battery icon will display on screen when the battery power is low. If the
projector will not switch on without mains power, the battery is not charged
enough to operate. Mains power must then be used to project.
To connect HDMI devices: Connect a HDMI cable to both devices and
power them both on. You may need an HDMI adapter (Type A). The device will
usually be recognized automatically. Sometimes you will need to toggle
between output monitors on your device (usually Fn + F7 on a laptop).
To connect to a non-Apple Smartphone, use an MHL adapter cable. See list
of compatible devices on our website.
To connect to an Apple iPhone you will need a Digital AV HDMI Adapter.
These are only available directly from Apple.
To connect to a MAC you will need to know the port that your MAC has
and source the appropriate HDMI adapter
Instructions for safety and use
Ensure that the product is kept in a room between 5 –35°C. Temperature
fluctuations may damage the product and cause instability.
This product cannot be exposed to humid environments and should be
kept away from water otherwise it may be damaged or cause explosion.
Do not use in smoke or dust filled areas as this may affect the
performance of the product or damage its components.
Keep out of reach of children. [Never allow any persons to look directly at
the LED beam as this may damage your eyes].
Never place items on top of the projector or cover vents.
Only qualified persons may perform technical work on the product. Do not
open or change the product if there is a fault as this will invalidate the
warranty. Please contact your retailer to receive official maintenance advice.
