Pifco PE201 Manuale utente
Instruction manual
Portable Gas Heater
PE201
TO:
CUSTOMER SERVICES DEPARTMENT
PIFCO
SUTTON HOUSE
BERRYHILL ROAD
FENTON
STOKE ON TRENT
ST4 2NL
Please place post-
age stamp here
Testing gas for leaks:
If you suspect that the heater is leaking, turn off the gas supply and have the unit
inspected by a qualied technician.
Do not attempt to locate the source of leak with a naked ame.
Locate a leak by sound, smell or by applying soapy water,bubbles will form and
indicate the site of the leak.
Always change LPG cylinder in well ventilated area, and from any source of ignition
such as a lighten candle, cigarette eg.
Do not use ellectrical items such as kettles, lights cookers they may produce
electrical sparks
Please be advised
The regulator provided is the UK standard regulator and may require changing in
different countries as the connection on the gas bottle may be different to that of the
UK
If you have any doubt please contact your local gas bottle retailer for advice
Parts Identication
Technical Data
This product is guaranteed for 12 months from the date of the original purchase.
If any defect arises due to faulty materials or workmanship the faulty products must
be returned to the place of purchase. Refunds or replacement is at the discretion
of the store.
The following conditions apply:
The product must be returned to the retailer with the original proof of purchase.
The product must be installed and used in accordance with the instructions
contained in this instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
PFD has no responsibility for incidental or consequential loss or damage.
Valid in the UK and Eire only.
Guarantee.
Gas Heat Input 4100W
Gas Category LPG ( Liquid Propane -Butane Gas)
Gas Pressure (28-30) mbar
Pin Code 598 CL250
Recommend to use 50mm hose for connection, which should be certied according
to applicable EN-standard BS EN 3212/2;
Regulator should be certied according to EN12864 (from rate:max.1.5kg/h)
Product Helpline.
0871 221 3618 For all your product needs.
Imported & Distributed throughout the U.K.
By PFD. ST4 2NL www.pifco-products.co.uk
Product Helpline.
0871 221 3615 For all your product needs.
Lighting the Heater:
Before connecting the regulator to the gas cylinder. Check whether there is a
rubber washer in the gas bottle connector and the washer is in good condition.
Connect the regulator to the gas cylinder by turning the hand wheel anticlockwise.
Open the gas cylinder by turning the gas cylinder valve anticlockwise.
Turn the gas control knob on the heater to setting 1(g 4).
Press the control knob down and hold in the pressed condition. This will allow
gas to ow to the pilot and center burner.
While holding the control knob in the pressed position push the piezoelectric
ignition (g 4) button 2 or 3 tines. Each tine you strike this piezoelectric ignition
you will hear a clicking sound as well as see a spark on the pilot burner.
Once the pilot has lit, continue holding the gas control knob in the pressed
position for a further 10 to 15 seconds thus activating the ame failure safety
device.
The pilot and center burner should remain alight.
You may now adjust the heater setting to Low/Med/High as required.
Turning off the heater:
To turn off the heater, turn the control knob to position 1 and close the gas
cylinder valve by turning the knob on the cylinder clockwise.
Ensure that the pilot ame the center burner are extinguished.
Product Helpline.
0871 221 3615 For all your product needs.
Heat and ignition controls
Piezo Quartz Ignition Button
MAX HEAT
MIN HEAT MED HEAT
Installation
Put the cylinder into the gas heater then install the protection bafe to make
sure the cylinder cant' move when it is moved from room to room
connect the pipe to the gas valve with cap (make sure no leakage)
Connect another side of the pipe to the regulator with cap (make sure no leakage)
Open the gas valve before using the heater, and close the gas valve after using.
Safety Warnings:
Read the instructions in the manual carefully. it has important information both
for operation use and for your safety.
Do not use faulty appliances.
Your heater should be checked manually by a qualied person for safe operation
and to detect any fault.
Retain these instructions for future reference. if necessary, a new copy may
be obtained from your dealer.
Turn off the gas container valve after use
The appliance is suitable for 14.2kg/5.5kg LPG container, when change gas
container move the appliance to a ame-free well ventilated atmosphere.
Do not move the appliance when in operation or when cooling.
Avoid to twisting the gas hose as this may cause the hose to stress and fracture.
Turn off the regulator and disconnect the regulator from cylinder, allow
Turn heater to control fully off position before removing and replace the cylinder
Do not attempt to remove the regulator while the heater is still running.
Do not move the heater while it is in use.
Always face the heater towards the centre of the room.
Use it only in a well-ventilated room. Ventilated is vital for the efcient
performance of this heater and for safety of the occupants of the room in which
it is being used.
Allow plenty of fresh air in, never seal up the doorways and windows.
Prevent young children and the inrm from touching very hot surfaces.
The normal dress guard only protects against accidental clothing contact.
Do not place clothes or other material on the heater.
Keep all ammable materials at least one meter away from the heater.
Turn off the gas valve and gas supply after use.
Never use or store solvents and pressure pack cans near a gas heater-even
if the heater is turned off.
Never dispose of rubbish such as cigarette butts in a gas re-this can affect
Combustion and produce dangerous pollutants. and carbon monoxide
Always operate the gas control and cylinder valve from the side or rear of the
heater. Standing in front of the heater exposes you to the risk of burns
This product is not intended for commercial use
This product is not intended to be operated by children or the inrm unless adequate
supervision and/or training has been given by the responsible person.
IIn the event of a gas leak open all doors and windows and do not use electrical
equipment as these may produce a spark which could ignight the LPG vapours
Product Helpline.
0871 221 3615 For all your product needs.
Maintenance:
Maintenance and cleaning must be carried out with the gas supply turned off and the
heater cold. do not attempt to clean the heater while it is in use.
your heater should be checked annually by a qualied person for safe operation and
to detect any faults.
If any faults are detected in use, stop using the heater and contact your dealer or the
advice helpline for advice.
Disposal of Unit
Disposal instructions for warmlight items in accordance with the WEEE directive.
Appliances bearing the symbol shown here may not be disposed of in domestic
rubbish. You are required to dispose of old electrical and electronic appliances like
this separately. Please visit www.recyclemore.co.uk, or www.recylcenow.co.uk for
access to information about the recycling of electrical items. The WEEE directive,
introduced in August 2006, states that all electrical items must be recycled, rather
than taken to landll. Please arrange to take this appliance to your local Civic
Amenity site for recycling, once it has reached the end of its life.
Turning off the heater:
To turn off the heater, turn the control knob to position 1 and close the gas
cylinder valve by turning the knob on the cylinder clockwise.
Ensure that the pilot ame the center burner are extinguished.
The type of regulator that is use is dependant on the connection on the gas bottle
used and this may be,dependant on gas supplier and your geographical location
If you are unsure which type of regulator you will need seek advice from your gas
supplier
Please see below
Typical U.K. Regulators
Regulators
Other Types of Regulators which can
be used in countries such as Ireland
and Spain
Model no:
Serial no:
Batch no:
Name:
Address:
Date Purchased:
E-mail Address:
IMPORTANT
This warranty is invalid if alterations have been made to this certicate
Dealer Stamp/Details:
If you would NOT like to receive special offers and promotions from PFD and it’s associated
companies please tick this box
Product Helpline.
0871 221 3615 For all your product needs.
