Pioneer BDC-2202 Manuale utente

Thank you for buying this Pioneer product. See below for product information.

Pioneer BDC-2202

•Pioneer BDC-S02BK (black) BD-ROM & DVD/CD Writer

or Pioneer BDC-S02 (beige) BD-ROM & DVD/CD Writer

Website: http://www.pioneerelectronics.com/BDC2202support/

•Software from Corel Corporation®

Please contact Corel Corporation® for software-related issues

Website: www.corel.com/support

Telephone: 1-800-772-6735

Other support information (including e-mail):

http://www.corel.com/servlet/Satellite/us/en/Content/1152796559954

AFTER SALES SERVICE FOR PIONEER PRODUCTS

Please contact the dealer or distributor where you purchased this product for

its after-sale service (including warranty conditions) or any other information.

In case the necessary information is not available, please contact the Pioneer’s

subsidiaries (regional service headquarters) listed below.

PLEASE DO NOT SHIP YOUR PRODUCT TO THE COMPANIES

at the addresses listed below for repair without advance contact as these

locations are not repair facilities.

UNITED STATES

PIONEER ELECTRONICS SERVICE INC.

P.O. Box 1760

Long Beach, CA 90801-1760

United States of America

CANADA

PIONEER ELECTRONICS OF CANADA, INC.

Customer Support

300 Allstate Parkway

Markham, Ontario L 3 R – 0 P 2 Canada

® PIONEER CORPORATION Published by Pioneer Corporation

PIONEER CORPORATION

4-1, Meguro, 1-Chrome, Meguro-ku, Tokyo 153-8654, Japan

Pioneer Electronics (USA) Inc.

Home Entertainment & Business Solutions Grp

2265 E. 220th Street

Long Beach, CA 90810 USA

Pioneer Electronics of Canada, Inc.

Industrial Products Division

300 Allstate Parkway

Markham, Ontario, L3R-0P2 Canada

PIONEER ELECTRONICS SERVICE INC.

1925 East Dominquez Street, Long Beach, CA 90810 USA

Serial-ATA Drive Installation

Step 1: Prepare the Computer

1. Turn OFF the computer and disconnect the power cord.

2. Remove the bezel and the open drive bay cover from the PC’s front panel.

Note: Your computer may be a tower model as

shown on the left or a desktop model as

shown below. This drive works in either PC

chassis style.

Step 2: Prepare the Drive

3. Attach slide rails to the drive if required for your drive model.

Slide rails are sold separately through computer retailers.

4. Position the drive close to the open bay and carefully insert the drive.

Horizontal Installation Vertical Installation

Step 3:Connect the Cables

5. Connect the PC’s power cable to the

drive; checking the polarity of the cable.

6. Connect the PC’s Serial-ATA Interface

cable to the drive.

Note: The computer powers the drive. Do NOT use

a power supply other than the PC’s internal source

Step 4: Finish the Installation

7. Place the mounting screws in the appropriate holes and tighten by hand.

When mounting screws are loose, vibrations from the spinning disc may cause a

ripping sound.

8. Replace the bezel and power the computer ON

Serial-ATA Drives Use Direct-Only Communication.

There is NO Master/Slave Jumper.
