Pioneer VSX-520-K Manuale utente
AMPLIFICATION
››Power›Output:››110W›x›5›(1kHz,›THD›0.05%›@›8›ohms)
››80W›+›80W›(20Hz›–›20kHz,›THD›0.08%›@›8›ohms›FTC)
AUDIO FEATURES
››Texas›Instruments›Aureus™›DSP
››192›kHz/24-bit›DAC
››Dolby®›TrueHD
››Dolby›Pro›Logic›IIz
››Dolby›Digital›/›EX
››DTS-HD®›Master›Audio
››DTS®›96/24›/›DTS›Neo:6/DTS›Express
››Multi›PCM›Playback›(192›kHz)›via›HDMI
››SACD›Playback›via›HDMI›(2›ch)
››0.1›Step›Audio›Delay›(Lip›Sync)›(Max›9›Frame)
››Advanced›Surround›(Action,›Drama,›Entertainment›Show,›Advanced›
Game,›Sports,›Classical,›Rock/Pop,›Unplugged,›Extended›Stereo)
››Auto›Surround
››Stream›Direct
››Phase›Control›(bass›management›ensures›precision›low›frequency›
output)
››Front›Stage›Surround›Advance
››Advanced›Sound›Retriever›for›enhanced›PC›and›portable›audio›(2-ch)
››Midnight›Listening›Mode
››Auto›Level›Control›(2›ch.)
VIDEO FEATURES
››HDMI›(v.1.4›with›3D),›Deep›Color,›and›x.v.Color
CONVENIENCE
››30›Tuner›Presets
››SR›Remote›Control›Unit
››FL›Dimmer›(4›steps)
››Sleep›Timer›(30,›60,›90›minutes)
››Auto›Audio›Signal›Select
››LFE›Attenuator
CONNECTIVITY
››HDMI›(3›inputs›/›1›output)
››Bluetooth›Port›(Compatible›with›optional›Bluetooth›adapter›
AS-BT100)
››Front›Mini›Jack
››3›Digital›Inputs›(1›Coaxial,›2›Optical)
››Component›Video›Terminal›(2›Inputs,›1›Output)›Assignable
››Audio/Video›Inputs:›2A/4AV
››Audio/Video›Output:›1A/1AV›+›1V
››2.1›Preout›(Subwoofer›+›Surround›Back/Front›Height›Channels)
››Large›Speaker›Terminals›(FL/FR)
5.1-Channel A/V Receiver featuring HDMI®(v.1.4 with 3D),
Dolby®TrueHD & DTS-HD®Master Audio and
Bluetooth Capability*
VSX-520-K
*Optional›Bluetooth›Adapter›(AS-BT100)›required.
©›2010›Pioneer›Electronics›(USA)›Inc.
SPECIFICATIONS
››Power›Requirements:›AC›120›V/60›Hz
››Power›Consumption:›240›Watts
››Standby›Power›Consumption:›Less›than›0.4›Watts
››W›x›H›x›D:›16.55›x›6.23›x›13.71›inches
››Weight:›19.6›lbs
INTEGRATED TECHNOLOGIES
Specifications and design subject to modification without notice.
PIONEER and the Pioneer logo are registered trademarks of Pioneer Corporation.
The impedances indicated are actual values that speakers can present to an amplifier while playing
back music. They do not refer to the nominal rated impedances of speakers you use.
HDMI connection may not allow transmission of copyright protected material, depending on the
capability of the signal source.
DTS is a registered trademark & the DTS logos and Symbol are trademarks of DTS, Inc.
Bluetooth is a registered trademark of Bluetooth SIG, Inc. Bluetooth functionality requires a
compatible A2DP profile Bluetooth-enabled device. Certain Bluetooth features may not be supported
by all compatible Bluetooth-enabled devices, and/or the functionality of such features may be limited
in certain devices.
Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing, LLC.
“x.v.Color” is a trademark of Sony Corporation.
Texas Instruments, Aureus and design are trademarks of Texas Instruments Incorporated in the U.S.
or other countries.
CONNECTION DESCRIPTIONS
A. HDMI›A/V›Repeater›(3›in/1›out)
B. Bluetooth›Adapter›Port
C. 4›Composite›A/V›Inputs
D. 2›Assignable›Component›Video›Inputs
E. 3›Assignable›Digital›Inputs
F. Large›Speaker›Terminals›(Front›L/R)
CONNECTIONS
Rear›Panel
ABCDEF
5.1-Channel A/V Receiver featuring HDMI®(v.1.4 with 3D),
Dolby®TrueHD & DTS-HD®Master Audio and
Bluetooth Capability*
VSX-520-K
