ICA-107_W_P

Wired / Wireless / PoE CMOS IP Camera

Key Feature

Data Sheet

Searching for a powerful and economical Internet Camera? PLANET is glad

to introduce our ICA-107/ICA-107W/ICA-107P. Those Internet Cameras

have an Integrated Microcomputer and a high quality CMOS digital-Image-

Sensor, enabling it to display high quality live streaming video over your

LAN and the Internet.

The motion detection in the ICA-107 series can notify users via email or ftp

when detecting any movement. With its admin software, no expertise

required, your first surveillance network can be easily, efficiently established

in few minutes.

ICA-107W support 802.11b/g wireless network, that will save your time

and cost for wiring. And ICA-107P has provided 802.3af standard PoE

interface. It can help you to locate the camera to the location that is no

power outlet. With the Windows based utility, IP Camera Viewer, the ICA-

107 series could take a snapshot, record and playback the video files.

• Easy Configuration

The network administrator can configure and manage the camera via

Windows-based utility or web interface based on 10BaseT/100BaseTX

Ethernet with Auto- MDIX or 802.11g wireless interface (ICA-107W).

Supporting TCP/IP networking, SMTP e-mail, and HTTP network

standards, PLANET ICA-107 series can be applied and utilized in the

mixed IP network environment

• Meeting SOHO

business, or public facilities surveillance needs. PLANET ICA-107 series

can be deployed in many different situations, such as library, train

station or factory production line to provide efficient, human-resource

reducing, and offers flexibility, affordability, and reliability for the

proper surveillance of manufacturing facilities

• Support Windows-based and Web-based Monitoring Utility

These tools allow users to access the Internet Camera from a remote

site via Intranet or Internet. They also provide users to make function

configuration including image monitoring, recording images to a hard

drive, viewing up to 32 cameras on one screen, snapshots and so on

• Simultaneous Viewing

This Internet Camera allows multiple users login to view live video

simultaneously. The advanced video compression produces a high-

quality, high-frame rate, VGA,QVGA video stream

• Motion Detection

Monitors any suspicious movement in front of the camera

• Supports DDNS & UPnP

The camera also supports UPnP and DDNS. DDNS allows the camera

to use an easier to remember naming format rather than an IP

address. UPnP will allow users of Windows XP to access the camera

with the click of a mouse without knowing IP address of the camera

PLANET reserves the right to change specifications without prior notice. All brand names and trademarks are property or

07-07 C-ICA107_W_P-1

PLANET Technology Corporation

11F, No. 96, Min Chuan Road, Hsin Tien, Taipei, Tawian R.O.C.

Tel: 886-2-2219-9518  Fax: 886-2-2219-9528

Email: [email protected] www.planet.com.tw

VoIP Gateway: vip.planet.com.tw

CMOS IP Camera

Wireless CMOS IP Camera

PoE CMOS IP Camera

ICA-107

ICA-107W

ICA-107P

Wired / Wireless / PoE CMOS IP Camera

Product

Specification

Ordering Information

Data Sheet

Model

Hardware

Sensor

Focus

LAN

Wireless

Encryption

PoE Interface

Image (Video Setting)

Image Compression

Video Resolution and Frame Rate

Image Quality

Environment

Operating Temperature

Power Requirement

EMC / EMI

Network and Configuration

Connection Type

Management

Remote monitoring application (Home)

Applications

ICA-107   ICA-107W   ICA-107P

Micron MI-360 300,000 Pixels CMOS Sensor

Manual Focus, F=1.8

1 x 10/100Base-TX RJ-45

-    802.11b/g   -

-    WEP, WPA-PSK, WPA2-PSK  -

-    -   802.3af

M-JPEG

640 x 480 (30fps), 320 x 240 (30fps), 176 x 144 (30fps)

5 Level

0~45 Degree C, 10~90% (Non-Condensing)

12V DC

CE, FCC

Static IP, DHCP

Web, Camera Utility

Office

ICA-107W ICA-107 ICA-107P

WAP-4035

PoE

Internet

ICA-107_W_P
