Planet FNSW-4800 Manuale utente

48-Port 10/100Mbps Fast Ethernet Switch

Key Feature

Data Sheet

The Planet's FNSW-4800 is a 48-Port 10/100Mbps Fast Ethernet switch,

perfectly designed for low cost, high performance, and easy installation,

the PLANET 48-Port 10/100Base-TX Fast Ethernet Switch in your best

choice of switched networks.

With increasing bandwidth requirements for local area networks, PLANET's

FNSW-4800 Fast Ethernet Switch is the ideal option to alleviate bottlenecks

in Client / server and peer-to-peer environments in a cost-effective way.

The switch provides a combination of 48 Fast Ethernet Switching ports that

provide users with high-speed network connections.

With it's Auto-Negotiation capability, all the RJ-45/STP ports of FNSW-4800

can be configured to speeds of 10/20Mbps or 100/200Mbps automatically.

In addition, the product is equipped with the MDI/MDI-X auto detection

for easily plug and play connection, regardless of cabling types-straight

through or crossover.

The high-performance throughput at filtering / forwarding rate is up to

14880 packets per second in 10Mbps, and 148800 packets per second in

100Mbps. Along with its dynamic shared memory buffer, the FNSW-4800

can boost bandwidth, eliminate unnecessary traffic and relieve congestion

on your critical server path.

FNSW-4800

• Comply with IEEE 802.3 and IEEE 802.3u standards for

10/100Base-TX

• 48-Port 10/100Mbps Fast Ethernet Switch

• Each Switching ports support auto-negotiation-10/20,

100/200Mbps supported

• Auto-MDI/MDI-X detection on each RJ-45 port

• Prevents packet loss with back pressure (half-duplex) and

802.3x PAUSE frame flow control (full-duplex)

• High performance Store and Forward architecture, broadcast

storm control, runt/CRC filtering eliminates erroneous packets

to optimize network bandwidth

• 8K MAC address table, automatic source address learning

and ageing

• 2.5Mbit embedded memory for packet buffers

• Support up to 1522 bytes packet and 802.1Q VLAN

transparent

• 19-inch rack mount size

• Internal full-range power supply suitable for worldwide use

• EMI standards comply with FCC, CE class A

PLANET reserves the right to change specifications without prior notice. All brand names and trademarks are property or

09-06 C-FNSW4800-2

PLANET Technology Corporation

11F, No. 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan R.O.C.

Tel: 886-2-2219-9518 Fax: 886-2-2219-9528

Email: [email protected] www.planet.com.tw

VoIP Gateway: vip.planet.com.tw

48-Port 10/100Mbps Fast Ethernet Switch

FNSW-4800

48-Port 10/100Mbps Fast Ethernet Switch

Product

Specification

Applications

Ordering Information

Model

Hardware Specification

Ports

Switch Processing Scheme

Throughput (packet per second)

Switch fabric

Address Table

Share data Buffer

Flow Control

Dimensions

Weight

Power Requirement

Power Consumption / Dissipation

Temperature

Humidity Operating:

Standards Conformance

Regulation Compliance

Standards Compliance

FNSW-4800

48 10/100Base-TX RJ-45 Auto-MDI/MDI-X ports

Store-and-forward

6.6Mpps

8.8Gbps

8K entries

2.5Mbit

Back pressure for half duplex, IEEE 802.3x Pause Frame for full duplex

440 x 260 x 44 mm, 1U height

3.11kg

100~240V AC, 50-60 Hz, 0.6A

18 Watts maximum / 61 BTU / hr maximum

Operating: 0~50 Degree C, Storage -40~70 Degree C

10% to 90%, Storage: 5% to 95% (Non-condensing)

Standards Conformance

FCC Part 15 Class A, CE

IEEE 802.3 (Ethernet)

IEEE 802.3u (Fast Ethernet),

IEEE 802.3x (full-duplex flow control)

Workgroup Switch

With up to 8.8Gbps switching fabric, the FNSW-4800 can easily have the high bandwidth Fast Ethernet network backbone or your

workgroup's backbone.

Department Switch

Uplink directly using any straight or crossover cable to the backbone switch provides the connective to back plane yet segment the

network traffic of the department to your backbone.

Data Sheet

FNSW-4800
